nearWallFields Class Reference
FunctionObjects » Field function objects

Samples near-patch volume fields within an input distance range. More...

Inheritance diagram for nearWallFields:
Inheritance graph
[legend]
Collaboration diagram for nearWallFields:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("nearWallFields")

 nearWallFields (const word &name, const Time &runTime, const dictionary &dict)

 nearWallFields (const nearWallFields &)=delete

void operator= (const nearWallFields &)=delete

virtual ~nearWallFields ()=default

virtual bool read (const dictionary &dict)

virtual bool execute ()

virtual bool write ()

- Public Member Functions inherited from fvMeshFunctionObject
 TypeName ("fvMeshFunctionObject")

 fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

 fvMeshFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual ~fvMeshFunctionObject ()=default

- Public Member Functions inherited from regionFunctionObject
 TypeName ("regionFunctionObject")

 regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

 regionFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual ~regionFunctionObject ()=default

template<class ObjectType >
const ObjectType * lookupObjectPtr (const word &fieldName) const

template<class ObjectType >
ObjectType * lookupObjectRefPtr (const word &fieldName) const

- Public Member Functions inherited from stateFunctionObject
 stateFunctionObject (const word &name, const Time &runTime)

virtual ~stateFunctionObject ()=default

dictionary & propertyDict ()

bool foundProperty (const word &entryName) const

void clearTrigger ()

label getTrigger () const

bool setTrigger (const label triggeri, bool increaseOnly=true)

bool getDict (const word &entryName, dictionary &dict) const

bool getObjectDict (const word &objectName, const word &entryName, dictionary &dict) const

template<class Type >
Type getProperty (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool getProperty (const word &entryName, Type &value) const

template<class Type >
void setProperty (const word &entryName, const Type &value)

template<class Type >
Type getObjectProperty (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool getObjectProperty (const word &objectName, const word &entryName, Type &value) const

template<class Type >
void setObjectProperty (const word &objectName, const word &entryName, const Type &value)

template<class Type >
void setResult (const word &entryName, const Type &value)

template<class Type >
void setObjectResult (const word &objectName, const word &entryName, const Type &value)

template<class Type >
Type getResult (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
Type getObjectResult (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool getObjectResult (const word &objectName, const word &entryName, Type &value) const

word resultType (const word &entryName) const

word objectResultType (const word &objectName, const word &entryName) const

wordList objectResultEntries () const

wordList objectResultEntries (const word &objectName) const

void writeResultEntries (Ostream &os) const

void writeResultEntries (const word &objectName, Ostream &os) const

void writeAllResultEntries (Ostream &os) const

- Public Member Functions inherited from timeFunctionObject
 timeFunctionObject (const word &name, const Time &runTime)

virtual ~timeFunctionObject ()=default

const Time & time () const

objectRegistry & storedObjects ()

const objectRegistry & storedObjects () const

- Public Member Functions inherited from functionObject
 declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

 functionObject (const word &name, const bool withNamePrefix=defaultUseNamePrefix)

autoPtr< functionObject > clone () const

virtual ~functionObject ()=default

virtual const word & type () const =0

const word & name () const noexcept

bool useNamePrefix () const noexcept

bool useNamePrefix (bool on) noexcept

virtual bool execute (const label subIndex)

virtual bool end ()

virtual bool adjustTimeStep ()

virtual bool filesModified () const

virtual void updateMesh (const mapPolyMesh &mpm)

virtual void movePoints (const polyMesh &mesh)


Protected Member Functions

void calcAddressing ()

template<class Type >
void createFields (PtrList< GeometricField< Type, fvPatchField, volMesh >> &) const

template<class Type >
void sampleBoundaryField (const interpolationCellPoint< Type > &interpolator, GeometricField< Type, fvPatchField, volMesh > &fld) const

template<class Type >
void sampleFields (PtrList< GeometricField< Type, fvPatchField, volMesh >> &) const

- Protected Member Functions inherited from fvMeshFunctionObject
 fvMeshFunctionObject (const fvMeshFunctionObject &)=delete

void operator= (const fvMeshFunctionObject &)=delete

- Protected Member Functions inherited from regionFunctionObject
virtual const objectRegistry & obr () const

template<class ObjectType >
bool foundObject (const word &fieldName) const

template<class ObjectType >
const ObjectType * cfindObject (const word &fieldName) const

template<class ObjectType >
const ObjectType * findObject (const word &fieldName) const

template<class ObjectType >
ObjectType * findObject (const word &fieldName)

template<class ObjectType >
ObjectType * getObjectPtr (const word &fieldName) const

template<class ObjectType >
const ObjectType & lookupObject (const word &fieldName) const

template<class ObjectType >
ObjectType & lookupObjectRef (const word &fieldName) const

template<class ObjectType >
bool store (word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)

template<class ObjectType >
bool storeInDb (const word &fieldName, const tmp< ObjectType > &tfield, const objectRegistry &obr)

bool writeObject (const word &fieldName)

bool clearObject (const word &fieldName)

void clearObjects (const wordList &objNames)

 regionFunctionObject (const regionFunctionObject &)=delete

void operator= (const regionFunctionObject &)=delete

- Protected Member Functions inherited from stateFunctionObject
const functionObjects::properties & stateDict () const

functionObjects::properties & stateDict ()

 stateFunctionObject (const stateFunctionObject &)=delete

void operator= (const stateFunctionObject &)=delete

- Protected Member Functions inherited from timeFunctionObject
void clearOutputObjects (const wordList &objNames)

 timeFunctionObject (const timeFunctionObject &)=delete

void operator= (const timeFunctionObject &)=delete

- Protected Member Functions inherited from functionObject
word scopedName (const word &name) const


Protected Attributes

List< Tuple2< word, word > > fieldSet_

labelHashSet patchSet_

scalar distance_

HashTable< word > fieldMap_

HashTable< word > reverseFieldMap_

labelListList cellToWalls_

List< List< point > > cellToSamples_

autoPtr< mapDistribute > getPatchDataMapPtr_

PtrList< volScalarField > vsf_

PtrList< volVectorField > vvf_

PtrList< volSphericalTensorField > vSpheretf_

PtrList< volSymmTensorField > vSymmtf_

PtrList< volTensorField > vtf_

- Protected Attributes inherited from fvMeshFunctionObject
const fvMesh & mesh_

- Protected Attributes inherited from regionFunctionObject
word subRegistryName_

const objectRegistry & obr_

const objectRegistry * obrPtr_

- Protected Attributes inherited from timeFunctionObject
const Time & time_


Additional Inherited Members

- Static Public Member Functions inherited from functionObject
static autoPtr< functionObject > New (const word &name, const Time &runTime, const dictionary &dict)

- Public Attributes inherited from functionObject
bool log

- Static Public Attributes inherited from functionObject
static int debug

static bool postProcess

static bool defaultUseNamePrefix

static word outputPrefix


Detailed Description

Samples near-patch volume fields within an input distance range.

Operands:

Operand Type Location
input vol<Type>Field $FOAM_CASE/<time>/<inpField>
output file - -
output field vol<Type>Field $FOAM_CASE/<time>/<outField>

where <Type>=Scalar/Vector/SphericalTensor/SymmTensor/Tensor.

Usage
Minimal example by using system/controlDict.functions:
nearWallFields1
{
    // Mandatory entries (unmodifiable)
    type            nearWallFields;
    libs            (fieldFunctionObjects);
    fields
    (
        (<field1> <outField1>)
        (<field2> <outField2>)
    );
    patches         (<patch1> <patch2> ... <patchN>);
    distance        0.01;

    // Optional (inherited) entries
    ...
}

where the entries mean:

Property Description Type Req'd Dflt
type Type name: nearWallFields word yes -
libs Library name: fieldFunctionObjects word yes -
fields Names of input-output fields wordHashTable yes -
patches Names of patches to sample wordList yes -
distance Wall-normal distance from patch to sample scalar yes -

The inherited entries are elaborated in:

Usage by the postProcess utility is not available.

See also
Source files

Definition at line 159 of file nearWallFields.H.

Constructor & Destructor Documentation

◆ nearWallFields() [1/2]

nearWallFields ( const word &  name,
const Time &  runTime,
const dictionary &  dict
)

Definition at line 239 of file nearWallFields.C.

References dict, and Foam::read().

Here is the call graph for this function:

◆ nearWallFields() [2/2]

nearWallFields ( const nearWallFields &  )
delete

◆ ~nearWallFields()

virtual ~nearWallFields ( )
virtualdefault

Member Function Documentation

◆ calcAddressing()

void calcAddressing ( )
protected

Definition at line 43 of file nearWallFields.C.

References fvMesh::boundary(), polyMesh::bounds(), nearWallFields::cellToSamples_, nearWallFields::cellToWalls_, tetrahedron::centre(), functionObject::debug, DebugInFunction, cloud::defaultName, nearWallFields::distance_, Foam::constant::electromagnetic::e, functionObject::end(), Foam::endl(), f(), polyMesh::FACE_DIAG_TRIS, mappedPatchBase::facePoint(), polyMesh::faces(), polyMesh::findTetFacePt(), forAll, nearWallFields::getPatchDataMapPtr_, PointIndexHit::hit(), PointIndexHit::hitPoint(), PointIndexHit::index(), InfoInFunction, boundBox::mag(), fvMeshFunctionObject::mesh_, OFstream::name(), primitiveMesh::nCells(), Foam::foamVersion::patch, nearWallFields::patchSet_, Time::path(), List::setSize(), globalIndex::size(), tetIndices::tet(), fvMesh::time(), Time::timeName(), globalIndex::toGlobal(), and OBJstream::write().

Here is the call graph for this function:

◆ createFields()

void createFields ( PtrList< GeometricField< Type, fvPatchField, volMesh >> &  sflds) const
protected

Definition at line 28 of file nearWallFieldsTemplates.C.

References Foam::endl(), fld, forAllConstIters(), Log, IOobject::readOpt(), IOobject::rename(), WarningInFunction, and IOobject::writeOpt().

Here is the call graph for this function:

◆ sampleBoundaryField()

void sampleBoundaryField ( const interpolationCellPoint< Type > &  interpolator,
GeometricField< Type, fvPatchField, volMesh > &  fld
) const
protected

Definition at line 85 of file nearWallFieldsTemplates.C.

References fld, forAll, and interpolationCellPoint< Type >::interpolate().

Here is the call graph for this function:

◆ sampleFields()

void sampleFields ( PtrList< GeometricField< Type, fvPatchField, volMesh >> &  sflds) const
protected

Definition at line 133 of file nearWallFieldsTemplates.C.

References fld, and forAll.

◆ TypeName()

TypeName ( "nearWallFields"  )

◆ operator=()

void operator= ( const nearWallFields &  )
delete

◆ read()

bool read ( const dictionary &  dict)
virtual

Reimplemented from regionFunctionObject.

Definition at line 254 of file nearWallFields.C.

References dict, Foam::endl(), forAll, Foam::Info, Foam::name(), regionFunctionObject::read(), and Foam::type().

Here is the call graph for this function:

◆ execute()

bool execute ( )
virtual

Implements functionObject.

Definition at line 302 of file nearWallFields.C.

References DebugInFunction, Foam::endl(), Log, Foam::name(), Foam::nl, and Foam::type().

Here is the call graph for this function:

◆ write()

bool write ( )
virtual

Implements functionObject.

Definition at line 343 of file nearWallFields.C.

References DebugInFunction, Foam::endl(), forAll, and Log.

Here is the call graph for this function:

Member Data Documentation

◆ fieldSet_

List<Tuple2<word, word> > fieldSet_
protected

Definition at line 170 of file nearWallFields.H.

◆ patchSet_

labelHashSet patchSet_
protected

Definition at line 173 of file nearWallFields.H.

Referenced by nearWallFields::calcAddressing().

◆ distance_

scalar distance_
protected

Definition at line 176 of file nearWallFields.H.

Referenced by nearWallFields::calcAddressing().

◆ fieldMap_

HashTable<word> fieldMap_
protected

Definition at line 179 of file nearWallFields.H.

◆ reverseFieldMap_

HashTable<word> reverseFieldMap_
protected

Definition at line 182 of file nearWallFields.H.

◆ cellToWalls_

labelListList cellToWalls_
protected

Definition at line 188 of file nearWallFields.H.

Referenced by nearWallFields::calcAddressing().

◆ cellToSamples_

List<List<point> > cellToSamples_
protected

Definition at line 191 of file nearWallFields.H.

Referenced by nearWallFields::calcAddressing().

◆ getPatchDataMapPtr_

autoPtr<mapDistribute> getPatchDataMapPtr_
protected

Definition at line 194 of file nearWallFields.H.

Referenced by nearWallFields::calcAddressing().

◆ vsf_

PtrList<volScalarField> vsf_
protected

Definition at line 199 of file nearWallFields.H.

◆ vvf_

PtrList<volVectorField> vvf_
protected

Definition at line 200 of file nearWallFields.H.

◆ vSpheretf_

PtrList<volSphericalTensorField> vSpheretf_
protected

Definition at line 201 of file nearWallFields.H.

◆ vSymmtf_

PtrList<volSymmTensorField> vSymmtf_
protected

Definition at line 202 of file nearWallFields.H.

◆ vtf_

PtrList<volTensorField> vtf_
protected

Definition at line 203 of file nearWallFields.H.

The documentation for this class was generated from the following files:

Copyright © 2011-2018  OpenFOAM | OPENFOAM® is a registered trademark of OpenCFD Ltd.

Generated by   doxygen 1.8.17
