Computes linear/angular momentum, reporting integral values and optionally writing the fields. More...

Inheritance diagram for momentum:

[legend]

Collaboration diagram for momentum:

[legend]

Public Member Functions
	TypeName ("momentum")

	momentum (const word &name, const Time &runTime, const dictionary &dict, const bool readFields=true)

	momentum (const word &name, const objectRegistry &obr, const dictionary &dict, const bool readFields=true)

	momentum (const momentum &)=delete

void	operator= (const momentum &)=delete

virtual	~momentum ()=default

virtual bool	read (const dictionary &)

virtual bool	execute ()

virtual bool	write ()

virtual void	updateMesh (const mapPolyMesh &)

virtual void	movePoints (const polyMesh &)

template<class GeoField >
Foam::autoPtr< GeoField >	newField (const word &baseName, const dimensionSet &dims, bool registerObject) const

Public Member Functions inherited from fvMeshFunctionObject
	TypeName ("fvMeshFunctionObject")

	fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

	fvMeshFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual	~fvMeshFunctionObject ()=default

Public Member Functions inherited from regionFunctionObject
	TypeName ("regionFunctionObject")

	regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

	regionFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual	~regionFunctionObject ()=default

template<class ObjectType >
const ObjectType *	lookupObjectPtr (const word &fieldName) const

template<class ObjectType >
ObjectType *	lookupObjectRefPtr (const word &fieldName) const

Public Member Functions inherited from stateFunctionObject
	stateFunctionObject (const word &name, const Time &runTime)

virtual	~stateFunctionObject ()=default

dictionary &	propertyDict ()

bool	foundProperty (const word &entryName) const

void	clearTrigger ()

label	getTrigger () const

bool	setTrigger (const label triggeri, bool increaseOnly=true)

bool	getDict (const word &entryName, dictionary &dict) const

bool	getObjectDict (const word &objectName, const word &entryName, dictionary &dict) const

template<class Type >
Type	getProperty (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getProperty (const word &entryName, Type &value) const

template<class Type >
void	setProperty (const word &entryName, const Type &value)

template<class Type >
Type	getObjectProperty (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getObjectProperty (const word &objectName, const word &entryName, Type &value) const

template<class Type >
void	setObjectProperty (const word &objectName, const word &entryName, const Type &value)

template<class Type >
void	setResult (const word &entryName, const Type &value)

template<class Type >
void	setObjectResult (const word &objectName, const word &entryName, const Type &value)

template<class Type >
Type	getResult (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
Type	getObjectResult (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getObjectResult (const word &objectName, const word &entryName, Type &value) const

word	resultType (const word &entryName) const

word	objectResultType (const word &objectName, const word &entryName) const

wordList	objectResultEntries () const

wordList	objectResultEntries (const word &objectName) const

void	writeResultEntries (Ostream &os) const

void	writeResultEntries (const word &objectName, Ostream &os) const

void	writeAllResultEntries (Ostream &os) const

Public Member Functions inherited from timeFunctionObject
	timeFunctionObject (const word &name, const Time &runTime)

virtual	~timeFunctionObject ()=default

const Time &	time () const

objectRegistry &	storedObjects ()

const objectRegistry &	storedObjects () const

Public Member Functions inherited from functionObject
	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const bool withNamePrefix=defaultUseNamePrefix)

autoPtr< functionObject >	clone () const

virtual	~functionObject ()=default

virtual const word &	type () const =0

const word &	name () const noexcept

bool	useNamePrefix () const noexcept

bool	useNamePrefix (bool on) noexcept

virtual bool	execute (const label subIndex)

virtual bool	end ()

virtual bool	adjustTimeStep ()

virtual bool	filesModified () const

Public Member Functions inherited from volRegion
	TypeName ("volRegion")

	volRegion (const fvMesh &mesh, const dictionary &dict)

virtual	~volRegion ()=default

regionTypes	regionType () const noexcept

const labelList &	cellIDs () const

label	nCells () const

scalar	V () const

bool	update ()

Public Member Functions inherited from writeFile
	writeFile (const objectRegistry &obr, const fileName &prefix, const word &name="undefined", const bool writeToFile=true)

	writeFile (const objectRegistry &obr, const fileName &prefix, const word &name, const dictionary &dict, const bool writeToFile=true)

	writeFile (const writeFile &wf)

virtual	~writeFile ()=default

virtual OFstream &	file ()

virtual bool	writeToFile () const

virtual bool	canWriteHeader () const

virtual label	charWidth () const

virtual void	writeCommented (Ostream &os, const string &str) const

virtual void	writeTabbed (Ostream &os, const string &str) const

virtual void	writeHeader (Ostream &os, const string &str) const

virtual void	writeCurrentTime (Ostream &os) const

virtual void	writeBreak (Ostream &os) const

template<class Type >
void	writeHeaderValue (Ostream &os, const string &property, const Type &value) const

Protected Member Functions
void	initialise ()

virtual void	writeFileHeader (Ostream &os)

void	writeValues (Ostream &os)

Protected Member Functions inherited from fvMeshFunctionObject
	fvMeshFunctionObject (const fvMeshFunctionObject &)=delete

void	operator= (const fvMeshFunctionObject &)=delete

Protected Member Functions inherited from regionFunctionObject
virtual const objectRegistry &	obr () const

template<class ObjectType >
bool	foundObject (const word &fieldName) const

template<class ObjectType >
const ObjectType *	cfindObject (const word &fieldName) const

template<class ObjectType >
const ObjectType *	findObject (const word &fieldName) const

template<class ObjectType >
ObjectType *	findObject (const word &fieldName)

template<class ObjectType >
ObjectType *	getObjectPtr (const word &fieldName) const

template<class ObjectType >
const ObjectType &	lookupObject (const word &fieldName) const

template<class ObjectType >
ObjectType &	lookupObjectRef (const word &fieldName) const

template<class ObjectType >
bool	store (word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)

template<class ObjectType >
bool	storeInDb (const word &fieldName, const tmp< ObjectType > &tfield, const objectRegistry &obr)

bool	writeObject (const word &fieldName)

bool	clearObject (const word &fieldName)

void	clearObjects (const wordList &objNames)

	regionFunctionObject (const regionFunctionObject &)=delete

void	operator= (const regionFunctionObject &)=delete

Protected Member Functions inherited from stateFunctionObject
const functionObjects::properties &	stateDict () const

functionObjects::properties &	stateDict ()

	stateFunctionObject (const stateFunctionObject &)=delete

void	operator= (const stateFunctionObject &)=delete

Protected Member Functions inherited from timeFunctionObject
void	clearOutputObjects (const wordList &objNames)

	timeFunctionObject (const timeFunctionObject &)=delete

void	operator= (const timeFunctionObject &)=delete

Protected Member Functions inherited from functionObject
word	scopedName (const word &name) const

Protected Member Functions inherited from volRegion
bool	useAllCells () const noexcept

void	writeFileHeader (const writeFile &wf, Ostream &file) const

Protected Member Functions inherited from writeFile
void	initStream (Ostream &os) const

fileName	baseFileDir () const

fileName	baseTimeDir () const

virtual autoPtr< OFstream >	createFile (const word &name, scalar timeValue) const

virtual autoPtr< OFstream >	createFile (const word &name) const

virtual void	resetFile (const word &name)

Omanip< int >	valueWidth (const label offset=0) const

void	operator= (const writeFile &)=delete

Protected Attributes
vector	sumMomentum_

vector	sumAngularMom_

word	UName_

word	pName_

word	rhoName_

scalar	rhoRef_

coordSystem::cylindrical	csys_

bool	hasCsys_

bool	writeMomentum_

bool	writeVelocity_

bool	writePosition_

bool	initialised_

Protected Attributes inherited from fvMeshFunctionObject
const fvMesh &	mesh_

Protected Attributes inherited from regionFunctionObject
word	subRegistryName_

const objectRegistry &	obr_

const objectRegistry *	obrPtr_

Protected Attributes inherited from timeFunctionObject
const Time &	time_

Protected Attributes inherited from volRegion
regionTypes	regionType_

word	regionName_

label	regionID_

Protected Attributes inherited from writeFile
const objectRegistry &	fileObr_

const fileName	prefix_

word	fileName_

autoPtr< OFstream >	filePtr_

label	writePrecision_

bool	writeToFile_

bool	updateHeader_

bool	writtenHeader_

bool	useUserTime_

scalar	startTime_

Additional Inherited Members
Public Types inherited from volRegion
enum	regionTypes { vrtAll = 0, vrtCellSet, vrtCellZone }

Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &runTime, const dictionary &dict)

Public Attributes inherited from functionObject
bool	log

Static Public Attributes inherited from functionObject
static int	debug

static bool	postProcess

static bool	defaultUseNamePrefix

static word	outputPrefix

Static Public Attributes inherited from volRegion
static const Enum< regionTypes >	regionTypeNames_

Static Public Attributes inherited from writeFile
static label	addChars = 8

Detailed Description

Computes linear/angular momentum, reporting integral values and optionally writing the fields.

Operands:

Operand	Type	Location
`input`	-	-
`output` file	dat	$FOAM_CASE/postProcessing/<FO>/<time>/<file>
`output` field	-	-

Usage

Minimal example by using system/controlDict.functions:

momentum1
{
    // Mandatory entries (unmodifiable)
    type            momentum;
    libs            (fieldFunctionObjects);

    // Optional entries (runtime modifiable)
    regionType      all;
    writeMomentum   yes;
    writePosition   yes;
    writeVelocity   yes;
    p               p;
    U               U;
    rho             rho;
    rhoRef          1.0;

    cylindrical     true;
    origin          (0 0 0);
    e1              (1 0 0);
    e3              (0 0 1);

    // Optional (inherited) entries
    ...
}

where the entries mean:

Property	Description	Type	Req'd	Dflt
`type`	Type name: momentum	word	yes	-
`libs`	Library name: fieldFunctionObjects	word	yes	-
`regionType`	Selection type: all/cellSet/cellZone	word	no	all
`writeMomentum`	Write (linear, angular) momentum fields	bool	no	no
`writePosition`	Write angular position component fields	bool	no	no
`writeVelocity`	Write angular velocity fields	bool	no	no
`p`	Pressure field name	word	no	p
`U`	Velocity field name	word	no	U
`rho`	Density field name	word	no	rho
`rhoRef`	Reference density (incompressible)	scalar	no	1.0
`cylindrical`	Use cylindrical coordinates	bool	no	no
`origin`	Origin for cylindrical coordinates	vector	conditional	-
`name`	Name of cellSet/cellZone if required	word	conditional	-

The inherited entries are elaborated in:

Usage by the postProcess utility is not available.

Note

For incompressible cases, the value of rhoRef is used.
When specifying the cylindrical coordinate system, the rotation can be specified directly with e1/e2/e3 axes, or via a rotation sub-dictionary For example,
```
    origin      (0 0 0);
    rotation
    {
        type    cylindrical;
        axis    (0 0 1);
    }
```

See also

Foam::functionObject
Foam::functionObjects::fvMeshFunctionObject
Foam::functionObjects::volRegion
Foam::functionObjects::writeFile
ExtendedCodeGuide::functionObjects::field::momentum

Source files

Definition at line 243 of file momentum.H.

Constructor & Destructor Documentation

◆ momentum() [1/3]

momentum	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict,
		const bool	readFields = `true`
	)

Definition at line 342 of file momentum.C.

References dict, Foam::endl(), Log, and Foam::read().

Here is the call graph for this function:

◆ momentum() [2/3]

momentum	(	const word &	name,
		const objectRegistry &	obr,
		const dictionary &	dict,
		const bool	readFields = `true`
	)

Definition at line 374 of file momentum.C.

References dict, Foam::endl(), Log, and Foam::read().

Here is the call graph for this function:

◆ momentum() [3/3]

momentum ( const momentum & )

delete

◆ ~momentum()

virtual ~momentum ( )

virtualdefault

Member Function Documentation

◆ initialise()

void initialise ( )

protected

Definition at line 265 of file momentum.C.

References Foam::dimPressure, Foam::exit(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ writeFileHeader()

void writeFileHeader ( Ostream & os )

protectedvirtual

Definition at line 221 of file momentum.C.

References Foam::endl(), os(), volRegion::useAllCells(), and Foam::writeHeader().

Here is the call graph for this function:

◆ writeValues()

void writeValues ( Ostream & os )

protected

Definition at line 298 of file momentum.C.

References Foam::endl(), Foam::Info, Foam::name(), Foam::nl, os(), Foam::tab, Foam::type(), volRegion::useAllCells(), and volRegion::V().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "momentum" )

◆ operator=()

void operator= ( const momentum & )

delete

◆ read()

bool read ( const dictionary & dict )

virtual

Reimplemented from volRegion.

Definition at line 407 of file momentum.C.

References dict, Foam::dimMass, Foam::dimVelocity, Foam::endl(), Foam::Info, Foam::name(), Foam::nl, volRegion::read(), regionFunctionObject::read(), writeFile::read(), and Foam::type().

Here is the call graph for this function:

◆ execute()

bool execute ( )

virtual

Implements functionObject.

Definition at line 477 of file momentum.C.

References Foam::endl(), Log, and UPstream::master().

Here is the call graph for this function:

◆ write()

bool write ( )

virtual

Implements functionObject.

Definition at line 503 of file momentum.C.

References Foam::dimLength, Foam::dimless, forAll, Log, Foam::nl, and p.

◆ updateMesh()

void updateMesh ( const mapPolyMesh & mpm )

virtual

Reimplemented from volRegion.

Definition at line 585 of file momentum.C.

References volRegion::updateMesh().

Here is the call graph for this function:

◆ movePoints()

void movePoints ( const polyMesh & pm )

virtual

Reimplemented from volRegion.

Definition at line 592 of file momentum.C.

References volRegion::movePoints().

Here is the call graph for this function:

◆ newField()

Foam::autoPtr<GeoField> newField	(	const word &	baseName,
		const dimensionSet &	dims,
		bool	registerObject
	)		const

Definition at line 54 of file momentum.C.

References autoPtr::New(), IOobject::NO_READ, IOobject::NO_WRITE, and Foam::Zero.

Here is the call graph for this function:

Member Data Documentation

◆ sumMomentum_

vector sumMomentum_

protected

Definition at line 272 of file momentum.H.

◆ sumAngularMom_

vector sumAngularMom_

protected

Definition at line 275 of file momentum.H.

◆ UName_

word UName_

protected

Definition at line 281 of file momentum.H.

◆ pName_

word pName_

protected

Definition at line 285 of file momentum.H.

◆ rhoName_

word rhoName_

protected

Definition at line 288 of file momentum.H.

◆ rhoRef_

scalar rhoRef_

protected

Definition at line 291 of file momentum.H.

◆ csys_

coordSystem::cylindrical csys_

protected

Definition at line 294 of file momentum.H.

◆ hasCsys_

bool hasCsys_

protected

Definition at line 297 of file momentum.H.

◆ writeMomentum_

bool writeMomentum_

protected

Definition at line 300 of file momentum.H.

◆ writeVelocity_

bool writeVelocity_

protected

Definition at line 303 of file momentum.H.

◆ writePosition_

bool writePosition_

protected

Definition at line 306 of file momentum.H.

◆ initialised_

bool initialised_

protected

Definition at line 309 of file momentum.H.

The documentation for this class was generated from the following files:

src/functionObjects/field/momentum/momentum.H
src/functionObjects/field/momentum/momentum.C

Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ momentum() [1/3]

◆ momentum() [2/3]

◆ momentum() [3/3]

◆ ~momentum()

Member Function Documentation

◆ initialise()

◆ writeFileHeader()

◆ writeValues()

◆ TypeName()

◆ operator=()

◆ read()

◆ execute()

◆ write()

◆ updateMesh()

◆ movePoints()

◆ newField()

Member Data Documentation

◆ sumMomentum_

◆ sumAngularMom_

◆ UName_

◆ pName_

◆ rhoName_

◆ rhoRef_

◆ csys_

◆ hasCsys_

◆ writeMomentum_

◆ writeVelocity_

◆ writePosition_

◆ initialised_
