Limits input fields to user-specified min and max bounds. More...

Inheritance diagram for limitFields:

Collaboration diagram for limitFields:

[legend]

Public Types
enum	limitType : unsigned { MIN = 0x1, MAX = 0x2, BOTH = (MIN \| MAX) }

Public Member Functions
	TypeName ("limitFields")

	limitFields (const word &name, const Time &runTime, const dictionary &dict)

	limitFields (const limitFields &)=delete

void	operator= (const limitFields &)=delete

virtual	~limitFields ()=default

virtual bool	read (const dictionary &dict)

virtual bool	execute ()

virtual bool	write ()

Public Member Functions inherited from fvMeshFunctionObject
	TypeName ("fvMeshFunctionObject")

	fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

	fvMeshFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual	~fvMeshFunctionObject ()=default

Public Member Functions inherited from regionFunctionObject
	TypeName ("regionFunctionObject")

	regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

	regionFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual	~regionFunctionObject ()=default

template<class ObjectType >
const ObjectType *	lookupObjectPtr (const word &fieldName) const

template<class ObjectType >
ObjectType *	lookupObjectRefPtr (const word &fieldName) const

Public Member Functions inherited from stateFunctionObject
	stateFunctionObject (const word &name, const Time &runTime)

virtual	~stateFunctionObject ()=default

dictionary &	propertyDict ()

bool	foundProperty (const word &entryName) const

void	clearTrigger ()

label	getTrigger () const

bool	setTrigger (const label triggeri, bool increaseOnly=true)

bool	getDict (const word &entryName, dictionary &dict) const

bool	getObjectDict (const word &objectName, const word &entryName, dictionary &dict) const

template<class Type >
Type	getProperty (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getProperty (const word &entryName, Type &value) const

template<class Type >
void	setProperty (const word &entryName, const Type &value)

template<class Type >
Type	getObjectProperty (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getObjectProperty (const word &objectName, const word &entryName, Type &value) const

template<class Type >
void	setObjectProperty (const word &objectName, const word &entryName, const Type &value)

template<class Type >
void	setResult (const word &entryName, const Type &value)

template<class Type >
void	setObjectResult (const word &objectName, const word &entryName, const Type &value)

template<class Type >
Type	getResult (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
Type	getObjectResult (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getObjectResult (const word &objectName, const word &entryName, Type &value) const

word	resultType (const word &entryName) const

word	objectResultType (const word &objectName, const word &entryName) const

wordList	objectResultEntries () const

wordList	objectResultEntries (const word &objectName) const

void	writeResultEntries (Ostream &os) const

void	writeResultEntries (const word &objectName, Ostream &os) const

void	writeAllResultEntries (Ostream &os) const

Public Member Functions inherited from timeFunctionObject
	timeFunctionObject (const word &name, const Time &runTime)

virtual	~timeFunctionObject ()=default

const Time &	time () const

objectRegistry &	storedObjects ()

const objectRegistry &	storedObjects () const

Public Member Functions inherited from functionObject
	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const bool withNamePrefix=defaultUseNamePrefix)

autoPtr< functionObject >	clone () const

virtual	~functionObject ()=default

virtual const word &	type () const =0

const word &	name () const noexcept

bool	useNamePrefix () const noexcept

bool	useNamePrefix (bool on) noexcept

virtual bool	execute (const label subIndex)

virtual bool	end ()

virtual bool	adjustTimeStep ()

virtual bool	filesModified () const

virtual void	updateMesh (const mapPolyMesh &mpm)

virtual void	movePoints (const polyMesh &mesh)

Protected Member Functions
bool	limitScalarField (const word &fieldName)

template<class Type >
bool	limitField (const word &fieldName)

Protected Member Functions inherited from fvMeshFunctionObject
	fvMeshFunctionObject (const fvMeshFunctionObject &)=delete

void	operator= (const fvMeshFunctionObject &)=delete

Protected Member Functions inherited from regionFunctionObject
virtual const objectRegistry &	obr () const

template<class ObjectType >
bool	foundObject (const word &fieldName) const

template<class ObjectType >
const ObjectType *	cfindObject (const word &fieldName) const

template<class ObjectType >
const ObjectType *	findObject (const word &fieldName) const

template<class ObjectType >
ObjectType *	findObject (const word &fieldName)

template<class ObjectType >
ObjectType *	getObjectPtr (const word &fieldName) const

template<class ObjectType >
const ObjectType &	lookupObject (const word &fieldName) const

template<class ObjectType >
ObjectType &	lookupObjectRef (const word &fieldName) const

template<class ObjectType >
bool	store (word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)

template<class ObjectType >
bool	storeInDb (const word &fieldName, const tmp< ObjectType > &tfield, const objectRegistry &obr)

bool	writeObject (const word &fieldName)

bool	clearObject (const word &fieldName)

void	clearObjects (const wordList &objNames)

	regionFunctionObject (const regionFunctionObject &)=delete

void	operator= (const regionFunctionObject &)=delete

Protected Member Functions inherited from stateFunctionObject
const functionObjects::properties &	stateDict () const

functionObjects::properties &	stateDict ()

	stateFunctionObject (const stateFunctionObject &)=delete

void	operator= (const stateFunctionObject &)=delete

Protected Member Functions inherited from timeFunctionObject
void	clearOutputObjects (const wordList &objNames)

	timeFunctionObject (const timeFunctionObject &)=delete

void	operator= (const timeFunctionObject &)=delete

Protected Member Functions inherited from functionObject
word	scopedName (const word &name) const

Protected Attributes
limitType	limit_

volFieldSelection	fieldSet_

scalar	min_

scalar	max_

Protected Attributes inherited from fvMeshFunctionObject
const fvMesh &	mesh_

Protected Attributes inherited from regionFunctionObject
word	subRegistryName_

const objectRegistry &	obr_

const objectRegistry *	obrPtr_

Protected Attributes inherited from timeFunctionObject
const Time &	time_

Static Protected Attributes
static const Enum< limitType >	limitTypeNames_

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &runTime, const dictionary &dict)

Public Attributes inherited from functionObject
bool	log

Static Public Attributes inherited from functionObject
static int	debug

static bool	postProcess

static bool	defaultUseNamePrefix

static word	outputPrefix

Detailed Description

Limits input fields to user-specified min and max bounds.

Operands:

Operand	Type	Location
`input`	vol<Type>Field	$FOAM_CASE/<time>/<inpField>
`output` file	-	-
`output` field	vol<Type>Field	$FOAM_CASE/<time>/<outField>

where <Type>=Scalar/Vector/SphericalTensor/SymmTensor/Tensor.

Note: For non-scalar types of input field, the user limit is used to create a scaling factor using the field magnitudes.

Usage

Minimal example by using system/controlDict.functions:

limitFields1
{
    // Mandatory entries (unmodifiable)
    type            limitFields;
    libs            (fieldFunctionObjects);

    // Mandatory entries (runtime modifiable)
    fields          (U);
    limit           max;
    max             100;

    // Optional (inherited) entries
    ...
}

where the entries mean:

Property	Description	Type	Req'd	Dflt
`type`	Type name: limitFields	word	yes	-
`libs`	Library name: fieldFunctionObjects	word	yes	-
`fields`	List of fields to process	wordList	yes	-
`limit`	Bound to limit - see below	word	yes	-
`min`	Min limit value	scalar	conditional	-
`max`	Max limit value	scalar	conditional	-

Options for the limit entry:

        min  : specify a minimum value
        max  : specify a maximum value
        both : specify a minimum value and a maximum value

The inherited entries are elaborated in:

functionObject.H

Usage by the postProcess utility is not available.

See also

Foam::functionObject
Foam::functionObjects::fvMeshFunctionObject
ExtendedCodeGuide::functionObjects::field::limitFields

Source files

Definition at line 173 of file limitFields.H.

Member Enumeration Documentation

◆ limitType

enum limitType : unsigned

Enumerator
MIN	limit by minimum value
MAX	limit by maximum value
BOTH	limit by both minimum and maximum values

Definition at line 181 of file limitFields.H.

Constructor & Destructor Documentation

◆ limitFields() [1/2]

limitFields	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

Definition at line 82 of file limitFields.C.

References dict, and Foam::blockMeshTools::read().

Here is the call graph for this function:

◆ limitFields() [2/2]

limitFields ( const limitFields & )

delete

◆ ~limitFields()

virtual ~limitFields ( )

virtualdefault

Member Function Documentation

◆ limitScalarField()

bool limitScalarField ( const word & fieldName )

protected

Definition at line 51 of file limitFields.C.

References field(), Foam::gMax(), Foam::gMin(), and Log.

Here is the call graph for this function:

◆ limitField()

bool limitField ( const word & fieldName )

protected

Definition at line 27 of file limitFieldsTemplates.C.

References field(), Foam::gMax(), Foam::gMin(), limitFields::limit_, Log, Foam::mag(), limitFields::MAX, GeometricField::max(), limitFields::max_, limitFields::MIN, GeometricField::min(), and limitFields::min_.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "limitFields" )

◆ operator=()

void operator= ( const limitFields & )

delete

◆ read()

bool read ( const dictionary & dict )

virtual

Reimplemented from regionFunctionObject.

Definition at line 100 of file limitFields.C.

References dict, Foam::endl(), limitFields::fieldSet_, Enum::get(), Foam::Info, limitFields::limit_, limitFields::limitTypeNames_, limitFields::MAX, limitFields::max_, limitFields::MIN, limitFields::min_, functionObject::name(), Foam::nl, fieldSelection::read(), regionFunctionObject::read(), and functionObject::type().

Here is the call graph for this function:

◆ execute()

bool execute ( )

virtual

Implements functionObject.

Definition at line 131 of file limitFields.C.

References Foam::BitOps::count(), Foam::expressions::patchExpr::debug, Foam::endl(), Log, Foam::name(), Foam::nl, and Foam::type().

Here is the call graph for this function:

◆ write()

bool write ( )

virtual

Implements functionObject.

Definition at line 165 of file limitFields.C.

Member Data Documentation

◆ limitTypeNames_

const Foam::Enum< Foam::functionObjects::limitFields::limitType > limitTypeNames_

staticprotected

Definition at line 194 of file limitFields.H.

Referenced by limitFields::read().

◆ limit_

limitType limit_

protected

Definition at line 197 of file limitFields.H.

Referenced by limitFields::limitField(), and limitFields::read().

◆ fieldSet_

volFieldSelection fieldSet_

protected

Definition at line 200 of file limitFields.H.

Referenced by limitFields::read().

◆ min_

scalar min_

protected

Definition at line 203 of file limitFields.H.

Referenced by limitFields::limitField(), and limitFields::read().

◆ max_

scalar max_

protected

Definition at line 206 of file limitFields.H.

Referenced by limitFields::limitField(), and limitFields::read().

The documentation for this class was generated from the following files:

src/functionObjects/field/limitFields/limitFields.H
src/functionObjects/field/limitFields/limitFields.C
src/functionObjects/field/limitFields/limitFieldsTemplates.C

Public Types

Public Member Functions

Protected Member Functions

Protected Attributes

Static Protected Attributes

Additional Inherited Members

Detailed Description

Member Enumeration Documentation

◆ limitType

Constructor & Destructor Documentation

◆ limitFields() [1/2]

◆ limitFields() [2/2]

◆ ~limitFields()

Member Function Documentation

◆ limitScalarField()

◆ limitField()

◆ TypeName()

◆ operator=()

◆ read()

◆ execute()

◆ write()

Member Data Documentation

◆ limitTypeNames_

◆ limit_

◆ fieldSet_

◆ min_

◆ max_
