Calculates and outputs the pressure fields p_rgh and ph_rgh. More...

Inheritance diagram for hydrostaticPressure:

Collaboration diagram for hydrostaticPressure:

Public Member Functions
	TypeName ("hydrostaticPressure")

	hydrostaticPressure (const word &name, const Time &runTime, const dictionary &dict)

virtual	~hydrostaticPressure ()=default

virtual bool	read (const dictionary &dict)

virtual bool	execute ()

virtual bool	write ()

Public Member Functions inherited from fvMeshFunctionObject
	TypeName ("fvMeshFunctionObject")

	fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

	fvMeshFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual	~fvMeshFunctionObject ()=default

Public Member Functions inherited from regionFunctionObject
	TypeName ("regionFunctionObject")

	regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

	regionFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual	~regionFunctionObject ()=default

template<class ObjectType >
const ObjectType *	lookupObjectPtr (const word &fieldName) const

template<class ObjectType >
ObjectType *	lookupObjectRefPtr (const word &fieldName) const

Public Member Functions inherited from stateFunctionObject
	stateFunctionObject (const word &name, const Time &runTime)

virtual	~stateFunctionObject ()=default

dictionary &	propertyDict ()

bool	foundProperty (const word &entryName) const

void	clearTrigger ()

label	getTrigger () const

bool	setTrigger (const label triggeri, bool increaseOnly=true)

bool	getDict (const word &entryName, dictionary &dict) const

bool	getObjectDict (const word &objectName, const word &entryName, dictionary &dict) const

template<class Type >
Type	getProperty (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getProperty (const word &entryName, Type &value) const

template<class Type >
void	setProperty (const word &entryName, const Type &value)

template<class Type >
Type	getObjectProperty (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getObjectProperty (const word &objectName, const word &entryName, Type &value) const

template<class Type >
void	setObjectProperty (const word &objectName, const word &entryName, const Type &value)

template<class Type >
void	setResult (const word &entryName, const Type &value)

template<class Type >
void	setObjectResult (const word &objectName, const word &entryName, const Type &value)

template<class Type >
Type	getResult (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
Type	getObjectResult (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getObjectResult (const word &objectName, const word &entryName, Type &value) const

word	resultType (const word &entryName) const

word	objectResultType (const word &objectName, const word &entryName) const

wordList	objectResultEntries () const

wordList	objectResultEntries (const word &objectName) const

void	writeResultEntries (Ostream &os) const

void	writeResultEntries (const word &objectName, Ostream &os) const

void	writeAllResultEntries (Ostream &os) const

Public Member Functions inherited from timeFunctionObject
	timeFunctionObject (const word &name, const Time &runTime)

virtual	~timeFunctionObject ()=default

const Time &	time () const

objectRegistry &	storedObjects ()

const objectRegistry &	storedObjects () const

Public Member Functions inherited from functionObject
	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const bool withNamePrefix=defaultUseNamePrefix)

autoPtr< functionObject >	clone () const

virtual	~functionObject ()=default

virtual const word &	type () const =0

const word &	name () const noexcept

bool	useNamePrefix () const noexcept

bool	useNamePrefix (bool on) noexcept

virtual bool	execute (const label subIndex)

virtual bool	end ()

virtual bool	adjustTimeStep ()

virtual bool	filesModified () const

virtual void	updateMesh (const mapPolyMesh &mpm)

virtual void	movePoints (const polyMesh &mesh)

Protected Member Functions
dimensionedScalar	pRef () const

void	calculateAndWrite ()

Protected Member Functions inherited from fvMeshFunctionObject
	fvMeshFunctionObject (const fvMeshFunctionObject &)=delete

void	operator= (const fvMeshFunctionObject &)=delete

Protected Member Functions inherited from regionFunctionObject
virtual const objectRegistry &	obr () const

template<class ObjectType >
bool	foundObject (const word &fieldName) const

template<class ObjectType >
const ObjectType *	cfindObject (const word &fieldName) const

template<class ObjectType >
const ObjectType *	findObject (const word &fieldName) const

template<class ObjectType >
ObjectType *	findObject (const word &fieldName)

template<class ObjectType >
ObjectType *	getObjectPtr (const word &fieldName) const

template<class ObjectType >
const ObjectType &	lookupObject (const word &fieldName) const

template<class ObjectType >
ObjectType &	lookupObjectRef (const word &fieldName) const

template<class ObjectType >
bool	store (word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)

template<class ObjectType >
bool	storeInDb (const word &fieldName, const tmp< ObjectType > &tfield, const objectRegistry &obr)

bool	writeObject (const word &fieldName)

bool	clearObject (const word &fieldName)

void	clearObjects (const wordList &objNames)

	regionFunctionObject (const regionFunctionObject &)=delete

void	operator= (const regionFunctionObject &)=delete

Protected Member Functions inherited from stateFunctionObject
const functionObjects::properties &	stateDict () const

functionObjects::properties &	stateDict ()

	stateFunctionObject (const stateFunctionObject &)=delete

void	operator= (const stateFunctionObject &)=delete

Protected Member Functions inherited from timeFunctionObject
void	clearOutputObjects (const wordList &objNames)

	timeFunctionObject (const timeFunctionObject &)=delete

void	operator= (const timeFunctionObject &)=delete

Protected Member Functions inherited from functionObject
word	scopedName (const word &name) const

Protected Attributes
word	p_rghName_

word	ph_rghName_

word	pRefName_

scalar	pRefValue_

word	rhoName_

word	UName_

word	ghName_

word	ghfName_

label	nCorrectors_

Protected Attributes inherited from fvMeshFunctionObject
const fvMesh &	mesh_

Protected Attributes inherited from regionFunctionObject
word	subRegistryName_

const objectRegistry &	obr_

const objectRegistry *	obrPtr_

Protected Attributes inherited from timeFunctionObject
const Time &	time_

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &runTime, const dictionary &dict)

Public Attributes inherited from functionObject
bool	log

Static Public Attributes inherited from functionObject
static int	debug

static bool	postProcess

static bool	defaultUseNamePrefix

static word	outputPrefix

Detailed Description

Calculates and outputs the pressure fields p_rgh and ph_rgh.

Usage

Example of function object specification to calculate hydrostatic pressure:

hydrostaticPressure1
{
    type        hydrostaticPressure;
    libs        (initialisationFunctionObjects);
    ...
}

Where the entries comprise:

Property	Description	Required	Default value
`log`	Log to standard output	no	yes
`p_rgh`	Name of p_rgh field	no	p_rgh
`ph_rgh`	Name of ph_rgh field	no	ph_rgh
`pRef`	Name of pressure ref field	no	pRef
`pRefValue`	Value of pressure ref	when pRef set to pInf	0
`rho`	Name of density field	no	rho
`U`	Name of velocity field	no	U
`gh`	Name of gravity*height volume field	no	gh
`ghf`	Name of gravity*height surface field	no	ghf
`nCorrectors`	Number of correctors when solving ph_rgh	no	5

Note: Calculates the hydrostatic pressure on construction/re-initialisation; the execute and write functions are not used.

Source files

Definition at line 138 of file hydrostaticPressure.H.

Constructor & Destructor Documentation

◆ hydrostaticPressure()

hydrostaticPressure	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

Definition at line 158 of file hydrostaticPressure.C.

References IOobject::AUTO_WRITE, dict, IOobject::MUST_READ, Foam::read(), and runTime.

Here is the call graph for this function:

◆ ~hydrostaticPressure()

virtual ~hydrostaticPressure ( )

virtualdefault

Member Function Documentation

◆ pRef()

Foam::dimensionedScalar pRef ( ) const

protected

Definition at line 52 of file hydrostaticPressure.C.

References Foam::dimPressure, objectRegistry::lookupObject(), fvMeshFunctionObject::mesh_, hydrostaticPressure::pRefName_, hydrostaticPressure::pRefValue_, and Foam::Zero.

Here is the call graph for this function:

◆ calculateAndWrite()

void calculateAndWrite ( )

protected

Definition at line 69 of file hydrostaticPressure.C.

References Foam::constrainPressure(), polyMesh::defaultRegion, basicThermo::dictName, Foam::fvc::div(), Foam::endl(), gh, ghf, Foam::Info, Foam::fvc::interpolate(), Foam::fvm::laplacian(), Log, Foam::max(), Foam::min(), Foam::nl, p, p_rgh, phig(), fvMatrix::relax(), rho, rhof(), Foam::fvc::snGrad(), fvMatrix::solve(), and U.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "hydrostaticPressure" )

◆ read()

bool read ( const dictionary & dict )

virtual

Reimplemented from regionFunctionObject.

Definition at line 206 of file hydrostaticPressure.C.

References dict, and regionFunctionObject::read().

Here is the call graph for this function:

◆ execute()

bool execute ( )

virtual

Implements functionObject.

Definition at line 232 of file hydrostaticPressure.C.

◆ write()

bool write ( )

virtual

Implements functionObject.

Definition at line 238 of file hydrostaticPressure.C.

Member Data Documentation

◆ p_rghName_

word p_rghName_

protected

Definition at line 147 of file hydrostaticPressure.H.

◆ ph_rghName_

word ph_rghName_

protected

Definition at line 150 of file hydrostaticPressure.H.

◆ pRefName_

word pRefName_

protected

Definition at line 154 of file hydrostaticPressure.H.

Referenced by hydrostaticPressure::pRef().

◆ pRefValue_

scalar pRefValue_

protected

Definition at line 157 of file hydrostaticPressure.H.

Referenced by hydrostaticPressure::pRef().

◆ rhoName_

word rhoName_

protected

Definition at line 160 of file hydrostaticPressure.H.

◆ UName_

word UName_

protected

Definition at line 163 of file hydrostaticPressure.H.

◆ ghName_

word ghName_

protected

Definition at line 166 of file hydrostaticPressure.H.

◆ ghfName_

word ghfName_

protected

Definition at line 169 of file hydrostaticPressure.H.

◆ nCorrectors_

label nCorrectors_

protected

Definition at line 172 of file hydrostaticPressure.H.

The documentation for this class was generated from the following files:

src/functionObjects/initialisation/hydrostaticPressure/hydrostaticPressure.H
src/functionObjects/initialisation/hydrostaticPressure/hydrostaticPressure.C
