Function object that generates or modifies a field based on expressions. More...

Inheritance diagram for fvExpressionField:

Collaboration diagram for fvExpressionField:

[legend]

Public Types
enum	actionType : unsigned char { opNone = 0, opNew, opModify }

Public Member Functions
	TypeName ("exprField")

	fvExpressionField (const word &name, const Time &runTime, const dictionary &dict, const bool loadFromFiles=false)

	fvExpressionField (const fvExpressionField &)=delete

void	operator= (const fvExpressionField &)=delete

virtual	~fvExpressionField ()

virtual word	fieldName () const

virtual bool	read (const dictionary &dict)

virtual bool	execute ()

virtual bool	write ()

Public Member Functions inherited from fvMeshFunctionObject
	TypeName ("fvMeshFunctionObject")

	fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

	fvMeshFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual	~fvMeshFunctionObject ()=default

Public Member Functions inherited from regionFunctionObject
	TypeName ("regionFunctionObject")

	regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

	regionFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual	~regionFunctionObject ()=default

template<class ObjectType >
const ObjectType *	lookupObjectPtr (const word &fieldName) const

template<class ObjectType >
ObjectType *	lookupObjectRefPtr (const word &fieldName) const

Public Member Functions inherited from stateFunctionObject
	stateFunctionObject (const word &name, const Time &runTime)

virtual	~stateFunctionObject ()=default

dictionary &	propertyDict ()

bool	foundProperty (const word &entryName) const

void	clearTrigger ()

label	getTrigger () const

bool	setTrigger (const label triggeri, bool increaseOnly=true)

bool	getDict (const word &entryName, dictionary &dict) const

bool	getObjectDict (const word &objectName, const word &entryName, dictionary &dict) const

template<class Type >
Type	getProperty (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getProperty (const word &entryName, Type &value) const

template<class Type >
void	setProperty (const word &entryName, const Type &value)

template<class Type >
Type	getObjectProperty (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getObjectProperty (const word &objectName, const word &entryName, Type &value) const

template<class Type >
void	setObjectProperty (const word &objectName, const word &entryName, const Type &value)

template<class Type >
void	setResult (const word &entryName, const Type &value)

template<class Type >
void	setObjectResult (const word &objectName, const word &entryName, const Type &value)

template<class Type >
Type	getResult (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
Type	getObjectResult (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getObjectResult (const word &objectName, const word &entryName, Type &value) const

word	resultType (const word &entryName) const

word	objectResultType (const word &objectName, const word &entryName) const

wordList	objectResultEntries () const

wordList	objectResultEntries (const word &objectName) const

void	writeResultEntries (Ostream &os) const

void	writeResultEntries (const word &objectName, Ostream &os) const

void	writeAllResultEntries (Ostream &os) const

Public Member Functions inherited from timeFunctionObject
	timeFunctionObject (const word &name, const Time &runTime)

virtual	~timeFunctionObject ()=default

const Time &	time () const

objectRegistry &	storedObjects ()

const objectRegistry &	storedObjects () const

Public Member Functions inherited from functionObject
	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const bool withNamePrefix=defaultUseNamePrefix)

autoPtr< functionObject >	clone () const

virtual	~functionObject ()=default

virtual const word &	type () const =0

const word &	name () const noexcept

bool	useNamePrefix () const noexcept

bool	useNamePrefix (bool on) noexcept

virtual bool	execute (const label subIndex)

virtual bool	end ()

virtual bool	adjustTimeStep ()

virtual bool	filesModified () const

virtual void	updateMesh (const mapPolyMesh &mpm)

virtual void	movePoints (const polyMesh &mesh)

Static Public Attributes
static const Enum< actionType >	actionNames_

Static Public Attributes inherited from functionObject
static int	debug

static bool	postProcess

static bool	defaultUseNamePrefix

static word	outputPrefix

Protected Member Functions
template<class FieldType >
bool	loadAndStore (const IOobject &io)

template<class Type >
bool	loadField (const IOobject &io)

label	loadFields (const UList< word > &fieldSet_)

template<class GeoField >
bool	setField (GeoField &output, const GeoField &evaluated, const boolField &cond)

bool	performAction (bool doWrite)

Protected Member Functions inherited from fvMeshFunctionObject
	fvMeshFunctionObject (const fvMeshFunctionObject &)=delete

void	operator= (const fvMeshFunctionObject &)=delete

Protected Member Functions inherited from regionFunctionObject
virtual const objectRegistry &	obr () const

template<class ObjectType >
bool	foundObject (const word &fieldName) const

template<class ObjectType >
const ObjectType *	cfindObject (const word &fieldName) const

template<class ObjectType >
const ObjectType *	findObject (const word &fieldName) const

template<class ObjectType >
ObjectType *	findObject (const word &fieldName)

template<class ObjectType >
ObjectType *	getObjectPtr (const word &fieldName) const

template<class ObjectType >
const ObjectType &	lookupObject (const word &fieldName) const

template<class ObjectType >
ObjectType &	lookupObjectRef (const word &fieldName) const

template<class ObjectType >
bool	store (word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)

template<class ObjectType >
bool	storeInDb (const word &fieldName, const tmp< ObjectType > &tfield, const objectRegistry &obr)

bool	writeObject (const word &fieldName)

bool	clearObject (const word &fieldName)

void	clearObjects (const wordList &objNames)

	regionFunctionObject (const regionFunctionObject &)=delete

void	operator= (const regionFunctionObject &)=delete

Protected Member Functions inherited from stateFunctionObject
const functionObjects::properties &	stateDict () const

functionObjects::properties &	stateDict ()

	stateFunctionObject (const stateFunctionObject &)=delete

void	operator= (const stateFunctionObject &)=delete

Protected Member Functions inherited from timeFunctionObject
void	clearOutputObjects (const wordList &objNames)

	timeFunctionObject (const timeFunctionObject &)=delete

void	operator= (const timeFunctionObject &)=delete

Protected Member Functions inherited from functionObject
word	scopedName (const word &name) const

Protected Attributes
dictionary	dict_

word	fieldName_

wordList	preloadFields_

expressions::exprString	maskExpr_

expressions::exprString	valueExpr_

dimensionSet	dimensions_

actionType	action_

bool	autowrite_

bool	store_

bool	hasDimensions_

bool	loadFromFiles_

autoPtr< expressions::volumeExprDriver >	driver_

Protected Attributes inherited from fvMeshFunctionObject
const fvMesh &	mesh_

Protected Attributes inherited from regionFunctionObject
word	subRegistryName_

const objectRegistry &	obr_

const objectRegistry *	obrPtr_

Protected Attributes inherited from timeFunctionObject
const Time &	time_

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &runTime, const dictionary &dict)

Public Attributes inherited from functionObject
bool	log

Detailed Description

Function object that generates or modifies a field based on expressions.

Usage

A minimal example:

<name1>
{
    type    exprField;
    libs    (fieldFunctionObjects);
    field   pTotal;

    expression  "p + 0.5*(rho*magSqr(U))";
    dimensions  [ Pa ];
}

// Modify an existing field
<name2>
{
    type    exprField;
    libs    (fieldFunctionObjects);
    field   pTotal;
    action  modify;

    // Static pressure only in these regions
    fieldMask   "(mag(pos()) < 0.05) && (pos().y() > 0)";
    expression  "p";
}

where the entries mean:

Property	Description	Type	Reqd	Dflt
`type`	Type name: exprField	word	yes
`libs`	Libraries: fieldFunctionObjects	wordList	yes
`field`	Name of input or output field	word	yes
`expression`	Field evaluation expression	string	yes
`action`	Type of operation: see below	word	no	new
`autowrite`	Add AUTO_WRITE to created field	bool	no	false
`store`	Store calculated field	bool	no	true
`fieldMask`	Masking as logical expression	string	no	""
`dimensions`	Apply specified dimensions to created field	dim-spec	no
`readFields`	Preload named fields (post-process mode)	wordList	no
`useNamePrefix`	Add prefix scoping to output name	bool	no	false

Options for the action entry:

none	:	No operation
new	:	Define field based on expression (default)
modify	:	Adjust field according to expression and fieldMask

Note: The useNamePrefix entry is always ignored for the modify action.

Source files

Definition at line 191 of file fvExpressionField.H.

Member Enumeration Documentation

◆ actionType

enum actionType : unsigned char

Enumerator
opNone	No operation.
opNew	Create/overwrite field (default)
opModify	Modify existing field.

Definition at line 200 of file fvExpressionField.H.

Constructor & Destructor Documentation

◆ fvExpressionField() [1/2]

fvExpressionField	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict,
		const bool	loadFromFiles = `false`
	)

Definition at line 294 of file fvExpressionField.C.

References dict, and Foam::read().

Here is the call graph for this function:

◆ fvExpressionField() [2/2]

fvExpressionField ( const fvExpressionField & )

delete

◆ ~fvExpressionField()

~fvExpressionField ( )

virtual

Definition at line 320 of file fvExpressionField.C.

Member Function Documentation

◆ loadAndStore()

bool loadAndStore ( const IOobject & io )

protected

Definition at line 125 of file fvExpressionField.C.

References Foam::endl(), IOobject::headerClassName(), Log, fvMeshFunctionObject::mesh_, and IOobject::name().

Here is the call graph for this function:

◆ loadField()

bool loadField ( const IOobject & io )

protected

|| loadAndStore<IntVolFieldType>(io)

Definition at line 142 of file fvExpressionField.C.

◆ loadFields()

Foam::label loadFields ( const UList< word > & fieldSet_ )

protected

Definition at line 158 of file fvExpressionField.C.

References DebugInfo, Foam::endl(), IOobject::headerClassName(), IOobject::MUST_READ, IOobject::NO_WRITE, and IOobject::typeHeaderOk().

Here is the call graph for this function:

◆ setField()

bool setField	(	GeoField &	output,
		const GeoField &	evaluated,
		const boolField &	cond
	)

protected

Definition at line 220 of file fvExpressionField.C.

References Foam::doCorrectBoundaryConditions(), Foam::endl(), forAll, Foam::Info, Foam::name(), IOstream::name(), Foam::nl, Foam::output(), Foam::reduce(), and Foam::returnReduce().

Here is the call graph for this function:

◆ performAction()

bool performAction ( bool doWrite )

protected

Definition at line 441 of file fvExpressionField.C.

References IOobject::AUTO_WRITE, doLocalCode, Foam::exit(), Foam::expressions::FACE_DATA, Foam::FatalError, FatalErrorInFunction, Foam::fieldGeoType(), autoPtr::get(), Foam::name(), Foam::nl, Foam::expressions::NO_DATA, Foam::expressions::POINT_DATA, autoPtr::release(), autoPtr::reset(), Foam::type(), Foam::expressions::VOLUME_DATA, and WarningInFunction.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "exprField" )

◆ operator=()

void operator= ( const fvExpressionField & )

delete

◆ fieldName()

Foam::word fieldName ( ) const

virtual

Definition at line 326 of file fvExpressionField.C.

References word::null.

◆ read()

bool read ( const dictionary & dict )

virtual

Reimplemented from regionFunctionObject.

Definition at line 348 of file fvExpressionField.C.

References dict, Foam::endl(), Log, Foam::name(), Foam::nl, regionFunctionObject::read(), exprDriver::SEARCH_FILES, exprDriver::SEARCH_REGISTRY, and Foam::type().

Here is the call graph for this function:

◆ execute()

bool execute ( )

virtual

Implements functionObject.

Definition at line 677 of file fvExpressionField.C.

◆ write()

bool write ( )

virtual

Implements functionObject.

Definition at line 683 of file fvExpressionField.C.

Member Data Documentation

◆ actionNames_

const Foam::Enum< Foam::functionObjects::fvExpressionField::actionType > actionNames_

static

Definition at line 208 of file fvExpressionField.H.

◆ dict_

dictionary dict_

protected

Definition at line 216 of file fvExpressionField.H.

◆ fieldName_

word fieldName_

protected

Definition at line 219 of file fvExpressionField.H.

◆ preloadFields_

wordList preloadFields_

protected

Definition at line 222 of file fvExpressionField.H.

◆ maskExpr_

expressions::exprString maskExpr_

protected

Definition at line 225 of file fvExpressionField.H.

◆ valueExpr_

expressions::exprString valueExpr_

protected

Definition at line 228 of file fvExpressionField.H.

◆ dimensions_

dimensionSet dimensions_

protected

Definition at line 231 of file fvExpressionField.H.

◆ action_

actionType action_

protected

Definition at line 234 of file fvExpressionField.H.

◆ autowrite_

bool autowrite_

protected

Definition at line 237 of file fvExpressionField.H.

◆ store_

bool store_

protected

Definition at line 240 of file fvExpressionField.H.

◆ hasDimensions_

bool hasDimensions_

protected

Definition at line 243 of file fvExpressionField.H.

◆ loadFromFiles_

bool loadFromFiles_

protected

Definition at line 246 of file fvExpressionField.H.

◆ driver_

autoPtr<expressions::volumeExprDriver> driver_

protected

Definition at line 248 of file fvExpressionField.H.

The documentation for this class was generated from the following files:

src/functionObjects/field/expressions/fvExpressionField.H
src/functionObjects/field/expressions/fvExpressionField.C

Public Types

Public Member Functions

Static Public Attributes

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Member Enumeration Documentation

◆ actionType

Constructor & Destructor Documentation

◆ fvExpressionField() [1/2]

◆ fvExpressionField() [2/2]

◆ ~fvExpressionField()

Member Function Documentation

◆ loadAndStore()

◆ loadField()

◆ loadFields()

◆ setField()

◆ performAction()

◆ TypeName()

◆ operator=()

◆ fieldName()

◆ read()

◆ execute()

◆ write()

Member Data Documentation

◆ actionNames_

◆ dict_

◆ fieldName_

◆ preloadFields_

◆ maskExpr_

◆ valueExpr_

◆ dimensions_

◆ action_

◆ autowrite_

◆ store_

◆ hasDimensions_

◆ loadFromFiles_

◆ driver_
