Helper class to describe what form of averaging to apply. A set will be applied to each base field in Foam::fieldAverage, of the following form. More...

Collaboration diagram for fieldAverageItem:

[legend]

Public Types
enum	baseType { ITER, TIME }

enum	windowType { NONE, APPROXIMATE, EXACT }

Public Member Functions
	fieldAverageItem ()

	fieldAverageItem (Istream &)

	fieldAverageItem (const fieldAverageItem &)

	~fieldAverageItem ()

bool	active () const

bool &	active ()

const word &	fieldName () const

bool	mean () const

bool &	mean ()

const word &	meanFieldName () const

void	setMeanFieldName (const word &name)

bool	prime2Mean () const

bool &	prime2Mean ()

const word &	prime2MeanFieldName () const

void	setPrime2MeanFieldName (const word &name)

const word &	base () const

label	totalIter () const

scalar	totalTime () const

scalar	window () const

const word &	windowName () const

const FIFOStack< scalar > &	windowTimes () const

const FIFOStack< word > &	windowFieldNames () const

bool	allowRestart () const

scalar	dt (const scalar deltaT) const

scalar	Dt () const

word	windowFieldName (const word &prefix) const

bool	inWindow (const scalar t) const

bool	storeWindowFields () const

bool	writeWindowFields () const

void	addToWindow (const word &fieldName, const scalar deltaT)

void	evolve (const objectRegistry &obr)

void	clear (const objectRegistry &obr, const bool fullClean)

bool	readState (const dictionary &dict)

void	writeState (dictionary &dict) const

template<class Type >
bool	calculateMeanField (const objectRegistry &obr) const

template<class Type1 , class Type2 >
bool	calculatePrime2MeanField (const objectRegistry &obr) const

void	operator= (const fieldAverageItem &)

Static Public Attributes
static const word	EXT_MEAN

static const word	EXT_PRIME2MEAN

Friends
bool	operator== (const fieldAverageItem &a, const fieldAverageItem &b)

bool	operator!= (const fieldAverageItem &a, const fieldAverageItem &b)

Istream &	operator>> (Istream &, fieldAverageItem &)

Ostream &	operator<< (Ostream &, const fieldAverageItem &)

Detailed Description

Helper class to describe what form of averaging to apply. A set will be applied to each base field in Foam::fieldAverage, of the following form.

Usage

<field1>
{
    mean            on;
    prime2Mean      on;
    base            time; // iteration
    window          200;  // optional averaging window
    windowName      w1;   // optional window name (default = "")
    windowType      approximate; // window type

    allowRestart    yes;  // optional, used for windowType 'exact'
}

where the entries mean:

Property	Description	Type	Req'd	Dflt
`mean`	Flag to calculate average	bool	yes	-
`prime2Mean`	Flag to calculate prime-square average	bool	yes	-
`base`	Type of averaging interval	word	yes	-
`window`	Averaging window	scalar	no
`windowName`	Name of the averaging window	word	no	""
`windowType`	Type of averaging window	word	no
`allowRestart`	Flag to allow restart for windowType=exact	bool	no

Options for the base entry:

      time | Averaging interval is based on time
      iter | Averaging interval is based on iterations

Options for the windowType entry:

      none  | no windowing
      exact | allow additional files will be stored and written
      approximate | disallow additional files will be stored and written

Note: To employ the prime2Mean option, the mean option must be enabled.

Source files

Definition at line 155 of file fieldAverageItem.H.

Member Enumeration Documentation

◆ baseType

enum baseType

strong

Enumerator
ITER
TIME

Definition at line 171 of file fieldAverageItem.H.

◆ windowType

enum windowType

strong

Enumerator
NONE
APPROXIMATE
EXACT

Definition at line 178 of file fieldAverageItem.H.

Constructor & Destructor Documentation

◆ fieldAverageItem() [1/3]

fieldAverageItem ( )

Definition at line 63 of file fieldAverageItem.C.

◆ fieldAverageItem() [2/3]

fieldAverageItem ( Istream & is )

Definition at line 28 of file fieldAverageItemIO.C.

◆ fieldAverageItem() [3/3]

fieldAverageItem ( const fieldAverageItem & faItem )

Definition at line 85 of file fieldAverageItem.C.

◆ ~fieldAverageItem()

~fieldAverageItem ( )

Definition at line 110 of file fieldAverageItem.C.

Member Function Documentation

◆ active() [1/2]

bool & active ( ) const

inline

Definition at line 23 of file fieldAverageItemI.H.

Referenced by fieldAverage::addMeanFieldType().

Here is the caller graph for this function:

◆ active() [2/2]

bool& active ( )

inline

◆ fieldName()

const Foam::word & fieldName ( ) const

inline

Definition at line 35 of file fieldAverageItemI.H.

Referenced by fieldAverage::addMeanFieldType(), fieldAverage::addMeanSqrToPrime2MeanType(), fieldAverage::addPrime2MeanField(), fieldAverage::addPrime2MeanFieldType(), fieldAverage::restoreWindowFieldsType(), and fieldAverage::storeWindowFieldType().

Here is the caller graph for this function:

◆ mean() [1/2]

bool & mean ( ) const

inline

Definition at line 41 of file fieldAverageItemI.H.

Referenced by fieldAverage::addMeanField(), fieldAverage::addMeanFieldType(), fieldAverage::addPrime2MeanField(), and fieldAverage::writeFields().

Here is the caller graph for this function:

◆ mean() [2/2]

bool& mean ( )

inline

◆ meanFieldName()

const Foam::word & meanFieldName ( ) const

inline

Definition at line 54 of file fieldAverageItemI.H.

Referenced by fieldAverage::addMeanFieldType(), fieldAverage::addMeanSqrToPrime2MeanType(), fieldAverage::addPrime2MeanFieldType(), and fieldAverage::writeFields().

Here is the caller graph for this function:

◆ setMeanFieldName()

void setMeanFieldName ( const word & name )

inline

Definition at line 61 of file fieldAverageItemI.H.

References Foam::name().

Here is the call graph for this function:

◆ prime2Mean() [1/2]

bool & prime2Mean ( ) const

inline

Definition at line 69 of file fieldAverageItemI.H.

Referenced by fieldAverage::addMeanSqrToPrime2Mean(), fieldAverage::addPrime2MeanField(), fieldAverage::addPrime2MeanFieldType(), and fieldAverage::writeFields().

Here is the caller graph for this function:

◆ prime2Mean() [2/2]

bool& prime2Mean ( )

inline

◆ prime2MeanFieldName()

const Foam::word & prime2MeanFieldName ( ) const

inline

Definition at line 82 of file fieldAverageItemI.H.

Referenced by fieldAverage::addMeanSqrToPrime2MeanType(), fieldAverage::addPrime2MeanFieldType(), and fieldAverage::writeFields().

Here is the caller graph for this function:

◆ setPrime2MeanFieldName()

void setPrime2MeanFieldName ( const word & name )

inline

Definition at line 89 of file fieldAverageItemI.H.

References Foam::name().

Here is the call graph for this function:

◆ base()

const Foam::word & base ( ) const

inline

Definition at line 97 of file fieldAverageItemI.H.

◆ totalIter()

Foam::label totalIter ( ) const

inline

Definition at line 103 of file fieldAverageItemI.H.

◆ totalTime()

Foam::scalar totalTime ( ) const

inline

Definition at line 109 of file fieldAverageItemI.H.

◆ window()

Foam::scalar window ( ) const

inline

Definition at line 115 of file fieldAverageItemI.H.

Referenced by fieldAverage::restoreWindowFields().

Here is the caller graph for this function:

◆ windowName()

const Foam::word & windowName ( ) const

inline

Definition at line 121 of file fieldAverageItemI.H.

◆ windowTimes()

const Foam::FIFOStack< Foam::scalar > & windowTimes ( ) const

inline

Definition at line 128 of file fieldAverageItemI.H.

◆ windowFieldNames()

const Foam::FIFOStack< Foam::word > & windowFieldNames ( ) const

inline

Definition at line 135 of file fieldAverageItemI.H.

Referenced by fieldAverage::restoreWindowFieldsType(), and fieldAverage::writeFields().

Here is the caller graph for this function:

◆ allowRestart()

bool allowRestart ( ) const

inline

Definition at line 141 of file fieldAverageItemI.H.

◆ dt()

Foam::scalar dt ( const scalar deltaT ) const

inline

Definition at line 148 of file fieldAverageItemI.H.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ Dt()

Foam::scalar Dt ( ) const

inline

Definition at line 174 of file fieldAverageItemI.H.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ windowFieldName()

Foam::word windowFieldName ( const word & prefix ) const

inline

Definition at line 199 of file fieldAverageItemI.H.

References Foam::name().

Referenced by fieldAverage::storeWindowFieldType().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ inWindow()

bool inWindow ( const scalar t ) const

inline

Definition at line 207 of file fieldAverageItemI.H.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ storeWindowFields()

bool storeWindowFields ( ) const

inline

Definition at line 232 of file fieldAverageItemI.H.

Referenced by fieldAverage::storeWindowFields().

Here is the caller graph for this function:

◆ writeWindowFields()

bool writeWindowFields ( ) const

inline

Definition at line 238 of file fieldAverageItemI.H.

Referenced by fieldAverage::writeFields().

Here is the caller graph for this function:

◆ addToWindow()

void addToWindow	(	const word &	fieldName,
		const scalar	deltaT
	)

Definition at line 117 of file fieldAverageItem.C.

Referenced by fieldAverage::storeWindowFieldType().

Here is the caller graph for this function:

◆ evolve()

void evolve ( const objectRegistry & obr )

Definition at line 127 of file fieldAverageItem.C.

References objectRegistry::checkOut(), TimeState::deltaTValue(), forAllIters, and objectRegistry::time().

Here is the call graph for this function:

◆ clear()

void clear	(	const objectRegistry &	obr,
		const bool	fullClean
	)

Definition at line 156 of file fieldAverageItem.C.

References objectRegistry::checkOut().

Here is the call graph for this function:

◆ readState()

bool readState ( const dictionary & dict )

Definition at line 186 of file fieldAverageItem.C.

References dict.

◆ writeState()

void writeState ( dictionary & dict ) const

Definition at line 202 of file fieldAverageItem.C.

References dict.

◆ calculateMeanField()

bool calculateMeanField ( const objectRegistry & obr ) const

Definition at line 26 of file fieldAverageItemTemplates.C.

References Foam::abort(), beta(), TimeState::deltaTValue(), Foam::FatalError, FatalErrorInFunction, objectRegistry::findObject(), objectRegistry::lookupObject(), objectRegistry::lookupObjectRef(), n, and objectRegistry::time().

Referenced by fieldAverage::calculateMeanFields().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ calculatePrime2MeanField()

bool calculatePrime2MeanField ( const objectRegistry & obr ) const

Definition at line 161 of file fieldAverageItemTemplates.C.

References Foam::abort(), beta(), TimeState::deltaTValue(), Foam::FatalError, FatalErrorInFunction, objectRegistry::findObject(), objectRegistry::lookupObject(), objectRegistry::lookupObjectRef(), Foam::sqr(), and objectRegistry::time().

Referenced by fieldAverage::calculatePrime2MeanFields().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator=()

void operator= ( const fieldAverageItem & rhs )

Definition at line 220 of file fieldAverageItem.C.

Friends And Related Function Documentation

◆ operator==

bool operator==	(	const fieldAverageItem &	a,
		const fieldAverageItem &	b
	)

friend

Definition at line 371 of file fieldAverageItem.H.

◆ operator!=

bool operator!=	(	const fieldAverageItem &	a,
		const fieldAverageItem &	b
	)

friend

Definition at line 393 of file fieldAverageItem.H.

◆ operator>>

Istream& operator>>	(	Istream &	,
		fieldAverageItem &
	)

friend

◆ operator<<

Ostream& operator<<	(	Ostream &	,
		const fieldAverageItem &
	)

friend

Member Data Documentation

◆ EXT_MEAN

const Foam::word EXT_MEAN

static

Definition at line 164 of file fieldAverageItem.H.

Referenced by Foam::functionObjects::operator>>().

◆ EXT_PRIME2MEAN

const Foam::word EXT_PRIME2MEAN

static

Definition at line 167 of file fieldAverageItem.H.

Referenced by Foam::functionObjects::operator>>().

The documentation for this class was generated from the following files:

src/functionObjects/field/fieldAverage/fieldAverageItem/fieldAverageItem.H
src/functionObjects/field/fieldAverage/fieldAverageItem/fieldAverageItem.C
src/functionObjects/field/fieldAverage/fieldAverageItem/fieldAverageItemI.H
src/functionObjects/field/fieldAverage/fieldAverageItem/fieldAverageItemIO.C
src/functionObjects/field/fieldAverage/fieldAverageItem/fieldAverageItemTemplates.C

Public Types

Public Member Functions

Static Public Attributes

Friends

Detailed Description

Member Enumeration Documentation

◆ baseType

◆ windowType

Constructor & Destructor Documentation

◆ fieldAverageItem() [1/3]

◆ fieldAverageItem() [2/3]

◆ fieldAverageItem() [3/3]

◆ ~fieldAverageItem()

Member Function Documentation

◆ active() [1/2]

◆ active() [2/2]

◆ fieldName()

◆ mean() [1/2]

◆ mean() [2/2]

◆ meanFieldName()

◆ setMeanFieldName()

◆ prime2Mean() [1/2]

◆ prime2Mean() [2/2]

◆ prime2MeanFieldName()

◆ setPrime2MeanFieldName()

◆ base()

◆ totalIter()

◆ totalTime()

◆ window()

◆ windowName()

◆ windowTimes()

◆ windowFieldNames()

◆ allowRestart()

◆ dt()

◆ Dt()

◆ windowFieldName()

◆ inWindow()

◆ storeWindowFields()

◆ writeWindowFields()

◆ addToWindow()

◆ evolve()

◆ clear()

◆ readState()

◆ writeState()

◆ calculateMeanField()

◆ calculatePrime2MeanField()

◆ operator=()

Friends And Related Function Documentation

◆ operator==

◆ operator!=

◆ operator>>

◆ operator<<

Member Data Documentation

◆ EXT_MEAN

◆ EXT_PRIME2MEAN
