Computes ensemble- and/or time-based field averages, with optional windowing, for a user-specified selection of volumetric and/or surface fields. More...

Inheritance diagram for fieldAverage:

[legend]

Collaboration diagram for fieldAverage:

[legend]

Public Member Functions
	TypeName ("fieldAverage")

	fieldAverage (const word &name, const Time &runTime, const dictionary &)

	fieldAverage (const fieldAverage &)=delete

void	operator= (const fieldAverage &)=delete

virtual	~fieldAverage ()=default

virtual bool	read (const dictionary &)

virtual bool	execute ()

virtual bool	write ()

Public Member Functions inherited from fvMeshFunctionObject
	TypeName ("fvMeshFunctionObject")

	fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

	fvMeshFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual	~fvMeshFunctionObject ()=default

Public Member Functions inherited from regionFunctionObject
	TypeName ("regionFunctionObject")

	regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

	regionFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)

virtual	~regionFunctionObject ()=default

template<class ObjectType >
const ObjectType *	lookupObjectPtr (const word &fieldName) const

template<class ObjectType >
ObjectType *	lookupObjectRefPtr (const word &fieldName) const

Public Member Functions inherited from stateFunctionObject
	stateFunctionObject (const word &name, const Time &runTime)

virtual	~stateFunctionObject ()=default

dictionary &	propertyDict ()

bool	foundProperty (const word &entryName) const

void	clearTrigger ()

label	getTrigger () const

bool	setTrigger (const label triggeri, bool increaseOnly=true)

bool	getDict (const word &entryName, dictionary &dict) const

bool	getObjectDict (const word &objectName, const word &entryName, dictionary &dict) const

template<class Type >
Type	getProperty (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getProperty (const word &entryName, Type &value) const

template<class Type >
void	setProperty (const word &entryName, const Type &value)

template<class Type >
Type	getObjectProperty (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getObjectProperty (const word &objectName, const word &entryName, Type &value) const

template<class Type >
void	setObjectProperty (const word &objectName, const word &entryName, const Type &value)

template<class Type >
void	setResult (const word &entryName, const Type &value)

template<class Type >
void	setObjectResult (const word &objectName, const word &entryName, const Type &value)

template<class Type >
Type	getResult (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
Type	getObjectResult (const word &objectName, const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
bool	getObjectResult (const word &objectName, const word &entryName, Type &value) const

word	resultType (const word &entryName) const

word	objectResultType (const word &objectName, const word &entryName) const

wordList	objectResultEntries () const

wordList	objectResultEntries (const word &objectName) const

void	writeResultEntries (Ostream &os) const

void	writeResultEntries (const word &objectName, Ostream &os) const

void	writeAllResultEntries (Ostream &os) const

Public Member Functions inherited from timeFunctionObject
	timeFunctionObject (const word &name, const Time &runTime)

virtual	~timeFunctionObject ()=default

const Time &	time () const

objectRegistry &	storedObjects ()

const objectRegistry &	storedObjects () const

Public Member Functions inherited from functionObject
	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const bool withNamePrefix=defaultUseNamePrefix)

autoPtr< functionObject >	clone () const

virtual	~functionObject ()=default

virtual const word &	type () const =0

const word &	name () const noexcept

bool	useNamePrefix () const noexcept

bool	useNamePrefix (bool on) noexcept

virtual bool	execute (const label subIndex)

virtual bool	end ()

virtual bool	adjustTimeStep ()

virtual bool	filesModified () const

virtual void	updateMesh (const mapPolyMesh &mpm)

virtual void	movePoints (const polyMesh &mesh)

Protected Member Functions
void	initialize ()

void	restart ()

template<class Type >
void	addMeanFieldType (fieldAverageItem &item)

template<class Type >
void	addMeanField (fieldAverageItem &item)

template<class Type1 , class Type2 >
void	addPrime2MeanFieldType (fieldAverageItem &item)

template<class Type1 , class Type2 >
void	addPrime2MeanField (fieldAverageItem &item)

virtual void	calcAverages ()

template<class Type >
void	calculateMeanFields () const

template<class Type1 , class Type2 >
void	calculatePrime2MeanFields () const

template<class Type1 , class Type2 >
void	addMeanSqrToPrime2MeanType (const fieldAverageItem &item) const

template<class Type1 , class Type2 >
void	addMeanSqrToPrime2Mean () const

template<class Type >
void	storeWindowFieldType (fieldAverageItem &item)

template<class Type >
void	storeWindowFields ()

template<class Type >
void	restoreWindowFieldsType (const fieldAverageItem &item)

template<class Type >
void	restoreWindowFields (const fieldAverageItem &item)

virtual void	writeAverages () const

template<class Type >
void	writeFieldType (const word &fieldName) const

template<class Type >
void	writeFields () const

void	writeAveragingProperties ()

void	readAveragingProperties ()

Protected Member Functions inherited from fvMeshFunctionObject
	fvMeshFunctionObject (const fvMeshFunctionObject &)=delete

void	operator= (const fvMeshFunctionObject &)=delete

Protected Member Functions inherited from regionFunctionObject
virtual const objectRegistry &	obr () const

template<class ObjectType >
bool	foundObject (const word &fieldName) const

template<class ObjectType >
const ObjectType *	cfindObject (const word &fieldName) const

template<class ObjectType >
const ObjectType *	findObject (const word &fieldName) const

template<class ObjectType >
ObjectType *	findObject (const word &fieldName)

template<class ObjectType >
ObjectType *	getObjectPtr (const word &fieldName) const

template<class ObjectType >
const ObjectType &	lookupObject (const word &fieldName) const

template<class ObjectType >
ObjectType &	lookupObjectRef (const word &fieldName) const

template<class ObjectType >
bool	store (word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)

template<class ObjectType >
bool	storeInDb (const word &fieldName, const tmp< ObjectType > &tfield, const objectRegistry &obr)

bool	writeObject (const word &fieldName)

bool	clearObject (const word &fieldName)

void	clearObjects (const wordList &objNames)

	regionFunctionObject (const regionFunctionObject &)=delete

void	operator= (const regionFunctionObject &)=delete

Protected Member Functions inherited from stateFunctionObject
const functionObjects::properties &	stateDict () const

functionObjects::properties &	stateDict ()

	stateFunctionObject (const stateFunctionObject &)=delete

void	operator= (const stateFunctionObject &)=delete

Protected Member Functions inherited from timeFunctionObject
void	clearOutputObjects (const wordList &objNames)

	timeFunctionObject (const timeFunctionObject &)=delete

void	operator= (const timeFunctionObject &)=delete

Protected Member Functions inherited from functionObject
word	scopedName (const word &name) const

Protected Attributes
label	prevTimeIndex_

bool	initialised_

Switch	restartOnRestart_

Switch	restartOnOutput_

Switch	periodicRestart_

scalar	restartPeriod_

scalar	restartTime_

List< fieldAverageItem >	faItems_

List< label >	totalIter_

List< scalar >	totalTime_

label	periodIndex_

Protected Attributes inherited from fvMeshFunctionObject
const fvMesh &	mesh_

Protected Attributes inherited from regionFunctionObject
word	subRegistryName_

const objectRegistry &	obr_

const objectRegistry *	obrPtr_

Protected Attributes inherited from timeFunctionObject
const Time &	time_

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &runTime, const dictionary &dict)

Public Attributes inherited from functionObject
bool	log

Static Public Attributes inherited from functionObject
static int	debug

static bool	postProcess

static bool	defaultUseNamePrefix

static word	outputPrefix

Detailed Description

Computes ensemble- and/or time-based field averages, with optional windowing, for a user-specified selection of volumetric and/or surface fields.

Fields are entered as a list of sub-dictionaries, which indicate the type of averages to perform, and can be updated during the calculation. The current options include:

mean: arithmetic mean
$\overline{x} = \frac{1}{N}\displaystyle\sum\limits_{i=0}^N x_i$
prime2Mean: prime-squared mean
$\overline{x'}^2 = \frac{1}{N}\displaystyle\sum\limits_{i=0}^N (x_i - \overline{x})^2$
base: average over 'time', or 'iteration' (N in the above)
window: optional averaging window, specified in 'base' units

Average field names are constructed by concatenating the base field with the averaging type, e.g. when averaging field 'U', the name of resultant fields becomes:

arithmetic mean field, UMean
prime-squared field, UPrime2Mean

Information regarding the number of averaging steps, and total averaging time are written on a per-field basis to the "<functionObject name>Properties" dictionary, located in <time>/uniform.

When restarting form a previous calculation, the averaging is continuous or may be restarted using the restartOnRestart option.

The averaging process may be restarted after each calculation output time using the restartOnOutput option or restarted periodically using the periodicRestart option and setting restartPeriod to the required averaging period.

With the subRegion option, also supports fields on function object surface output (e.g., sampledSurfaces).

Operands:

Operand	Type	Location
`input`	{vol,surface}<Type>Field(s)	$FOAM_CASE/<time>/<inpField>s
`output` file	-	-
`output` field	{vol,surface}<Type>Field(s)	$FOAM_CASE/<time>/<outField>s

where <Type>=Scalar/Vector/SphericalTensor/SymmTensor/Tensor.

Usage

Minimal example by using system/controlDict.functions:

fieldAverage1
{
    // Mandatory entries (unmodifiable)
    type                fieldAverage;
    libs                (fieldFunctionObjects);

    // Mandatory entries (runtime modifiable)
    fields
    (
        <field1>
        {
            // Optional (inherited) entries
            ...
        }

        ...

        <fieldN>
        {
            ...
        }
    );

    // Optional entries (runtime modifiable)
    restartOnRestart    false;
    restartOnOutput     false;
    periodicRestart     false;
    restartPeriod       0.002;

    // Optional (inherited) entries
    ...
}

where the entries mean:

Property	Description	Type	Req'd	Dflt
`type`	Type name: fieldAverage	word	yes	-
`libs`	Library name: fieldFunctionObjects	word	yes	-
`fields`	Names of the operand fields and averaging options	dict	yes	-
`restartOnRestart`	Restart the averaging on restart	bool	no	false
`restartOnOutput`	Restart the averaging on output	bool	no	false
`periodicRestart`	Periodically restart the averaging	bool	no	false
`restartPeriod`	Periodic restart period	scalar	conditional	-
`restartTime`	One-shot reset of the averaging	scalar	no	GREAT
`subRegion`	Name for alternative objectRegistry	word	no	""

The inherited entries are elaborated in:

Usage by the postProcess utility is not available.

See also

Foam::functionObject
Foam::functionObjects::fieldAverageItem
Foam::functionObjects::fvMeshFunctionObject
ExtendedCodeGuide::functionObjects::field::fieldAverage

Source files

Definition at line 255 of file fieldAverage.H.

Constructor & Destructor Documentation

◆ fieldAverage() [1/2]

fieldAverage	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

Definition at line 264 of file fieldAverage.C.

References dict, and Foam::read().

Here is the call graph for this function:

◆ fieldAverage() [2/2]

fieldAverage ( const fieldAverage & )

delete

◆ ~fieldAverage()

virtual ~fieldAverage ( )

virtualdefault

Member Function Documentation

◆ initialize()

void initialize ( )

protected

Definition at line 41 of file fieldAverage.C.

References Foam::endl(), fieldAverage::faItems_, fieldAverage::initialised_, Log, functionObject::name(), Foam::nl, regionFunctionObject::obr(), fieldAverage::prevTimeIndex_, functionObject::type(), and WarningInFunction.

Here is the call graph for this function:

◆ restart()

void restart ( )

protected

Definition at line 97 of file fieldAverage.C.

References Foam::endl(), Log, and Foam::nl.

Here is the call graph for this function:

◆ addMeanFieldType()

void addMeanFieldType ( fieldAverageItem & item )

protected

Definition at line 32 of file fieldAverageTemplates.C.

References fieldAverageItem::active(), Foam::endl(), fieldAverageItem::fieldName(), found, Log, fieldAverageItem::mean(), fieldAverageItem::meanFieldName(), startTime, and timeName.

Here is the call graph for this function:

◆ addMeanField()

void addMeanField ( fieldAverageItem & item )

protected

Definition at line 90 of file fieldAverageTemplates.C.

References fieldAverageItem::mean().

Here is the call graph for this function:

◆ addPrime2MeanFieldType()

void addPrime2MeanFieldType ( fieldAverageItem & item )

protected

Definition at line 179 of file fieldAverageTemplates.C.

References Foam::endl(), fieldAverageItem::fieldName(), found, Log, fieldAverageItem::meanFieldName(), Foam::nl, fieldAverageItem::prime2Mean(), fieldAverageItem::prime2MeanFieldName(), Foam::sqr(), startTime, and timeName.

Here is the call graph for this function:

◆ addPrime2MeanField()

void addPrime2MeanField ( fieldAverageItem & item )

protected

Definition at line 234 of file fieldAverageTemplates.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, fieldAverageItem::fieldName(), fieldAverageItem::mean(), Foam::nl, and fieldAverageItem::prime2Mean().

Here is the call graph for this function:

◆ calcAverages()

void calcAverages ( )

protectedvirtual

Definition at line 112 of file fieldAverage.C.

References Foam::endl(), forAll, Log, Foam::name(), Foam::nl, and Foam::type().

Here is the call graph for this function:

◆ calculateMeanFields()

void calculateMeanFields

protected

Definition at line 324 of file fieldAverageTemplates.C.

References fieldAverageItem::calculateMeanField().

Here is the call graph for this function:

◆ calculatePrime2MeanFields()

void calculatePrime2MeanFields

protected

Definition at line 340 of file fieldAverageTemplates.C.

References fieldAverageItem::calculatePrime2MeanField().

Here is the call graph for this function:

◆ addMeanSqrToPrime2MeanType()

void addMeanSqrToPrime2MeanType ( const fieldAverageItem & item ) const

protected

Definition at line 364 of file fieldAverageTemplates.C.

References fieldAverageItem::fieldName(), fieldAverageItem::meanFieldName(), fieldAverageItem::prime2MeanFieldName(), and Foam::sqr().

Here is the call graph for this function:

◆ addMeanSqrToPrime2Mean()

void addMeanSqrToPrime2Mean

protected

Definition at line 384 of file fieldAverageTemplates.C.

References fieldAverageItem::prime2Mean().

Here is the call graph for this function:

◆ storeWindowFieldType()

void storeWindowFieldType ( fieldAverageItem & item )

protected

Definition at line 265 of file fieldAverageTemplates.C.

References fieldAverageItem::addToWindow(), DebugInfo, Foam::endl(), fieldAverageItem::fieldName(), Foam::name(), startTime, timeName, and fieldAverageItem::windowFieldName().

Here is the call graph for this function:

◆ storeWindowFields()

void storeWindowFields

protected

Definition at line 305 of file fieldAverageTemplates.C.

References fieldAverage::faItems_, and fieldAverageItem::storeWindowFields().

Here is the call graph for this function:

◆ restoreWindowFieldsType()

void restoreWindowFieldsType ( const fieldAverageItem & item )

protected

Definition at line 109 of file fieldAverageTemplates.C.

References DebugInfo, Foam::endl(), fieldAverageItem::fieldName(), fieldNames(), forAllConstIters(), Foam::name(), startTime, timeName, IOobject::typeHeaderOk(), WarningInFunction, and fieldAverageItem::windowFieldNames().

Here is the call graph for this function:

◆ restoreWindowFields()

void restoreWindowFields ( const fieldAverageItem & item )

protected

Definition at line 160 of file fieldAverageTemplates.C.

References fieldAverageItem::window().

Here is the call graph for this function:

◆ writeAverages()

void writeAverages ( ) const

protectedvirtual

Definition at line 185 of file fieldAverage.C.

References Foam::endl(), and Log.

Here is the call graph for this function:

◆ writeFieldType()

void writeFieldType ( const word & fieldName ) const

protected

Definition at line 411 of file fieldAverageTemplates.C.

References f().

Here is the call graph for this function:

◆ writeFields()

void writeFields

protected

Definition at line 424 of file fieldAverageTemplates.C.

References fieldNames(), forAllConstIters(), fieldAverageItem::mean(), fieldAverageItem::meanFieldName(), fieldAverageItem::prime2Mean(), fieldAverageItem::prime2MeanFieldName(), fieldAverageItem::windowFieldNames(), and fieldAverageItem::writeWindowFields().

Here is the call graph for this function:

◆ writeAveragingProperties()

void writeAveragingProperties ( )

protected

Definition at line 199 of file fieldAverage.C.

References propsDict().

Here is the call graph for this function:

◆ readAveragingProperties()

void readAveragingProperties ( )

protected

Definition at line 210 of file fieldAverage.C.

References Foam::endl(), Foam::Info, and Foam::nl.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "fieldAverage" )

◆ operator=()

void operator= ( const fieldAverage & )

delete

◆ read()

bool read ( const dictionary & dict )

virtual

Reimplemented from regionFunctionObject.

Definition at line 287 of file fieldAverage.C.

References dict, Foam::endl(), Foam::Info, Foam::name(), Foam::nl, regionFunctionObject::read(), and Foam::type().

Here is the call graph for this function:

◆ execute()

bool execute ( )

virtual

Implements functionObject.

Definition at line 367 of file fieldAverage.C.

◆ write()

bool write ( )

virtual

Implements functionObject.

Definition at line 375 of file fieldAverage.C.

Member Data Documentation

◆ prevTimeIndex_

label prevTimeIndex_

protected

Definition at line 264 of file fieldAverage.H.

Referenced by fieldAverage::initialize().

◆ initialised_

bool initialised_

protected

Definition at line 267 of file fieldAverage.H.

Referenced by fieldAverage::initialize().

◆ restartOnRestart_

Switch restartOnRestart_

protected

Definition at line 270 of file fieldAverage.H.

◆ restartOnOutput_

Switch restartOnOutput_

protected

Definition at line 273 of file fieldAverage.H.

◆ periodicRestart_

Switch periodicRestart_

protected

Definition at line 276 of file fieldAverage.H.

◆ restartPeriod_

scalar restartPeriod_

protected

Definition at line 279 of file fieldAverage.H.

◆ restartTime_

scalar restartTime_

protected

Definition at line 282 of file fieldAverage.H.

◆ faItems_

List<fieldAverageItem> faItems_

protected

Definition at line 286 of file fieldAverage.H.

Referenced by fieldAverage::initialize(), and fieldAverage::storeWindowFields().

◆ totalIter_

List<label> totalIter_

protected

Definition at line 291 of file fieldAverage.H.

◆ totalTime_

List<scalar> totalTime_

protected

Definition at line 294 of file fieldAverage.H.

◆ periodIndex_

label periodIndex_

protected

Definition at line 297 of file fieldAverage.H.

The documentation for this class was generated from the following files:

src/functionObjects/field/fieldAverage/fieldAverage.H
src/functionObjects/field/fieldAverage/fieldAverage.C
src/functionObjects/field/fieldAverage/fieldAverageTemplates.C

Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ fieldAverage() [1/2]

◆ fieldAverage() [2/2]

◆ ~fieldAverage()

Member Function Documentation

◆ initialize()

◆ restart()

◆ addMeanFieldType()

◆ addMeanField()

◆ addPrime2MeanFieldType()

◆ addPrime2MeanField()

◆ calcAverages()

◆ calculateMeanFields()

◆ calculatePrime2MeanFields()

◆ addMeanSqrToPrime2MeanType()

◆ addMeanSqrToPrime2Mean()

◆ storeWindowFieldType()

◆ storeWindowFields()

◆ restoreWindowFieldsType()

◆ restoreWindowFields()

◆ writeAverages()

◆ writeFieldType()

◆ writeFields()

◆ writeAveragingProperties()

◆ readAveragingProperties()

◆ TypeName()

◆ operator=()

◆ read()

◆ execute()

◆ write()

Member Data Documentation

◆ prevTimeIndex_

◆ initialised_

◆ restartOnRestart_

◆ restartOnOutput_

◆ periodicRestart_

◆ restartPeriod_

◆ restartTime_

◆ faItems_

◆ totalIter_

◆ totalTime_

◆ periodIndex_
