Provides a general interface to enable dynamic code compilation. More...

Inheritance diagram for codedFunctionObject:

Collaboration diagram for codedFunctionObject:

[legend]

Public Member Functions
	TypeName ("coded")

	codedFunctionObject (const word &name, const Time &runTime, const dictionary &dict)

virtual	~codedFunctionObject ()=default

functionObject &	redirectFunctionObject () const

virtual bool	execute ()

virtual bool	write ()

virtual bool	end ()

virtual bool	read (const dictionary &)

Public Member Functions inherited from timeFunctionObject
	timeFunctionObject (const word &name, const Time &runTime)

virtual	~timeFunctionObject ()=default

const Time &	time () const

objectRegistry &	storedObjects ()

const objectRegistry &	storedObjects () const

Public Member Functions inherited from functionObject
	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const bool withNamePrefix=defaultUseNamePrefix)

autoPtr< functionObject >	clone () const

virtual	~functionObject ()=default

virtual const word &	type () const =0

const word &	name () const noexcept

bool	useNamePrefix () const noexcept

bool	useNamePrefix (bool on) noexcept

virtual bool	execute (const label subIndex)

virtual bool	adjustTimeStep ()

virtual bool	filesModified () const

virtual void	updateMesh (const mapPolyMesh &mpm)

virtual void	movePoints (const polyMesh &mesh)

Public Member Functions inherited from codedBase
	ClassName ("codedBase")

	codedBase ()=default

virtual	~codedBase ()=default

Static Public Attributes
static constexpr const char *const	codeTemplateC = "functionObjectTemplate.C"

static constexpr const char *const	codeTemplateH = "functionObjectTemplate.H"

Static Public Attributes inherited from functionObject
static int	debug

static bool	postProcess

static bool	defaultUseNamePrefix

static word	outputPrefix

Protected Member Functions
virtual dlLibraryTable &	libs () const

virtual string	description () const

virtual void	clearRedirect () const

virtual const dictionary &	codeContext () const

virtual const dictionary &	codeDict () const

virtual void	prepare (dynamicCode &, const dynamicCodeContext &) const

	codedFunctionObject (const codedFunctionObject &)=delete

void	operator= (const codedFunctionObject &)=delete

Protected Member Functions inherited from timeFunctionObject
void	clearOutputObjects (const wordList &objNames)

	timeFunctionObject (const timeFunctionObject &)=delete

void	operator= (const timeFunctionObject &)=delete

Protected Member Functions inherited from functionObject
word	scopedName (const word &name) const

Protected Member Functions inherited from codedBase
dynamicCodeContext &	codeContext ()

void	setCodeContext (const dictionary &dict)

void	append (const std::string &str)

void	updateLibrary (const word &name, const dynamicCodeContext &context) const

void	updateLibrary (const word &name, const dictionary &dict) const

void	updateLibrary (const word &name) const

	codedBase (const codedBase &)=delete

void	operator= (const codedBase &)=delete

Protected Attributes
dictionary	dict_

word	name_

string	codeData_

string	codeRead_

string	codeExecute_

string	codeWrite_

string	codeEnd_

autoPtr< functionObject >	redirectFunctionObjectPtr_

Protected Attributes inherited from timeFunctionObject
const Time &	time_

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &runTime, const dictionary &dict)

Public Attributes inherited from functionObject
bool	log

Static Protected Member Functions inherited from codedBase
static void	writeCodeDict (Ostream &os, const dictionary &dict)

static const dictionary &	codeDict (const objectRegistry &obr, const word &dictName="codeDict")

Detailed Description

Provides a general interface to enable dynamic code compilation.

The entries are:

codeInclude	:	include files
codeOptions	:	compiler line: added to EXE_INC (Make/options)
codeLibs	:	linker line: added to LIB_LIBS (Make/options)
codeData	:	c++; local member data (default constructed)
localCode	:	c++; local static functions
codeRead	:	c++; upon functionObject::read()
codeExecute	:	c++; upon functionObject::execute()
codeWrite	:	c++; upon functionObject::write()
codeEnd	:	c++; upon functionObject::end()
codeContext	:	additional dictionary context for the code

Usage

Example of function object specification:

difference
{
    type coded;
    libs (utilityFunctionObjects);

    // Name of on-the-fly generated functionObject
    name writeMagU;
    codeWrite
    #{
        // Lookup U
        const volVectorField& U = mesh().lookupObject<volVectorField>("U");

        // Write
        mag(U)().write();
    #};
}

Note: The code context dictionary can be supplied separately as the codeContext entry.

See also: Foam::functionObject Foam::codedBase

Source files

Definition at line 136 of file codedFunctionObject.H.

Constructor & Destructor Documentation

◆ codedFunctionObject() [1/2]

codedFunctionObject ( const codedFunctionObject & )

protecteddelete

◆ codedFunctionObject() [2/2]

codedFunctionObject	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

Definition at line 128 of file codedFunctionObject.C.

References Foam::read().

Here is the call graph for this function:

◆ ~codedFunctionObject()

virtual ~codedFunctionObject ( )

virtualdefault

Member Function Documentation

◆ libs()

Foam::dlLibraryTable & libs ( ) const

protectedvirtual

Implements codedBase.

Definition at line 50 of file codedFunctionObject.C.

References Time::libs(), and timeFunctionObject::time_.

Here is the call graph for this function:

◆ description()

Foam::string description ( ) const

protectedvirtual

Implements codedBase.

Definition at line 56 of file codedFunctionObject.C.

References Foam::name().

Here is the call graph for this function:

◆ clearRedirect()

void clearRedirect ( ) const

protectedvirtual

Implements codedBase.

Definition at line 62 of file codedFunctionObject.C.

◆ codeContext()

const Foam::dictionary & codeContext ( ) const

protectedvirtual

Definition at line 69 of file codedFunctionObject.C.

References dictionary::findDict(), keyType::LITERAL, and dictionary::null.

Here is the call graph for this function:

◆ codeDict()

const Foam::dictionary & codeDict ( ) const

protectedvirtual

Implements codedBase.

Definition at line 77 of file codedFunctionObject.C.

◆ prepare()

void prepare	(	dynamicCode &	dynCode,
		const dynamicCodeContext &	context
	)		const

protectedvirtual

Implements codedBase.

Definition at line 84 of file codedFunctionObject.C.

References dynamicCode::addCompileFile(), dynamicCode::addCopyFile(), DetailInfo, Foam::endl(), dynamicCodeContext::libs(), dynamicCodeContext::options(), dynamicCode::setFilterVariable(), dynamicCode::setMakeOptions(), and dynamicCodeContext::sha1().

Here is the call graph for this function:

◆ operator=()

void operator= ( const codedFunctionObject & )

protecteddelete

◆ TypeName()

TypeName ( "coded" )

◆ redirectFunctionObject()

Foam::functionObject & redirectFunctionObject ( ) const

Definition at line 148 of file codedFunctionObject.C.

References dictionaryContent::dict(), functionObject::New(), Foam::nl, dictionary::set(), and WarningInFunction.

Here is the call graph for this function:

◆ execute()

bool execute ( )

virtual

Implements functionObject.

Definition at line 182 of file codedFunctionObject.C.

◆ write()

bool write ( )

virtual

Implements functionObject.

Definition at line 189 of file codedFunctionObject.C.

◆ end()

bool end ( )

virtual

Reimplemented from functionObject.

Definition at line 196 of file codedFunctionObject.C.

◆ read()

bool read ( const dictionary & dict )

virtual

Reimplemented from functionObject.

Definition at line 203 of file codedFunctionObject.C.

References codedBase::codeContext(), dict, Foam::endl(), IOWarningInFunction, Foam::nl, functionObject::read(), and codedBase::setCodeContext().

Here is the call graph for this function:

Member Data Documentation

◆ dict_

dictionary dict_

protected

Definition at line 146 of file codedFunctionObject.H.

◆ name_

word name_

protected

Definition at line 148 of file codedFunctionObject.H.

◆ codeData_

string codeData_

protected

Definition at line 150 of file codedFunctionObject.H.

◆ codeRead_

string codeRead_

protected

Definition at line 151 of file codedFunctionObject.H.

◆ codeExecute_

string codeExecute_

protected

Definition at line 152 of file codedFunctionObject.H.

◆ codeWrite_

string codeWrite_

protected

Definition at line 153 of file codedFunctionObject.H.

◆ codeEnd_

string codeEnd_

protected

Definition at line 154 of file codedFunctionObject.H.

◆ redirectFunctionObjectPtr_

autoPtr<functionObject> redirectFunctionObjectPtr_

mutableprotected

Definition at line 157 of file codedFunctionObject.H.

◆ codeTemplateC

constexpr const char* const codeTemplateC = "functionObjectTemplate.C"

staticconstexpr

Definition at line 194 of file codedFunctionObject.H.

◆ codeTemplateH

constexpr const char* const codeTemplateH = "functionObjectTemplate.H"

staticconstexpr

Definition at line 198 of file codedFunctionObject.H.

The documentation for this class was generated from the following files:

src/functionObjects/utilities/codedFunctionObject/codedFunctionObject.H
src/functionObjects/utilities/codedFunctionObject/codedFunctionObject.C
