Watches for presence of the named trigger file in the case directory and signals a simulation stop (or other) event if found. More...

Inheritance diagram for abort:

[legend]

Collaboration diagram for abort:

[legend]

Public Member Functions
	TypeName ("abort")

	abort (const word &name, const Time &runTime, const dictionary &dict)

virtual	~abort ()=default

virtual bool	read (const dictionary &dict)

virtual bool	execute ()

virtual bool	write ()

virtual bool	end ()

Public Member Functions inherited from timeFunctionObject
	timeFunctionObject (const word &name, const Time &runTime)

virtual	~timeFunctionObject ()=default

const Time &	time () const

objectRegistry &	storedObjects ()

const objectRegistry &	storedObjects () const

Public Member Functions inherited from functionObject
	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const bool withNamePrefix=defaultUseNamePrefix)

autoPtr< functionObject >	clone () const

virtual	~functionObject ()=default

virtual const word &	type () const =0

const word &	name () const noexcept

bool	useNamePrefix () const noexcept

bool	useNamePrefix (bool on) noexcept

virtual bool	execute (const label subIndex)

virtual bool	adjustTimeStep ()

virtual bool	filesModified () const

virtual void	updateMesh (const mapPolyMesh &mpm)

virtual void	movePoints (const polyMesh &mesh)

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &runTime, const dictionary &dict)

Public Attributes inherited from functionObject
bool	log

Static Public Attributes inherited from functionObject
static int	debug

static bool	postProcess

static bool	defaultUseNamePrefix

static word	outputPrefix

Protected Member Functions inherited from timeFunctionObject
void	clearOutputObjects (const wordList &objNames)

	timeFunctionObject (const timeFunctionObject &)=delete

void	operator= (const timeFunctionObject &)=delete

Protected Member Functions inherited from functionObject
word	scopedName (const word &name) const

Protected Attributes inherited from timeFunctionObject
const Time &	time_

Detailed Description

Watches for presence of the named trigger file in the case directory and signals a simulation stop (or other) event if found.

The presence of the trigger file is only checked on the master process.

Currently the following action types are supported:

Example of function object specification:

abort
{
    type    abort;
    libs    (utilityFunctionObjects);

    file    "<case>/GOODBYE";
    action  writeNow
}

Function object usage

Property	Description	Required	Default
`type`	Type name: abort	yes
`file`	The trigger filename	no	<case>/name
`action`	The default action to trigger	no	nextWrite

When the trigger file is found, it is checked for the following content which corresponds to actions.

action=noWriteNow : triggers Foam::Time::saNoWriteNow (stop without writing data)
action=writeNow : triggers Foam::Time::saWriteNow (stop and write data)
action=nextWrite : triggers Foam::Time::saNextWrite (stop after next normal data write)
action=endTime : triggers Foam::Time::saEndTime (continue simulation to the end)
Anything else (empty file, no action=, ...) : use the default action

Note: The trigger file is considered "sticky". This means that once detected and processed, the trigger is duly noted and the file will not be rechecked. It is not possible or desirable to 'untrigger' an action.

Source files

Definition at line 121 of file abort.H.
