foamVtkMeshMaps Class Reference

Bookkeeping for mesh subsetting and/or polyhedral cell decomposition. Although the main use case is for handling vtk meshes, it is not specific to VTK alone. More...

Inheritance diagram for foamVtkMeshMaps:

Public Member Functions
	foamVtkMeshMaps ()=default
const labelList &	cellMap () const noexcept
DynamicList< label > &	cellMap () noexcept
const labelList &	pointMap () const noexcept
DynamicList< label > &	pointMap () noexcept
const labelList &	additionalIds () const noexcept
DynamicList< label > &	additionalIds () noexcept
void	clear ()
void	renumberCells (const labelUList &mapping)
void	renumberPoints (const labelUList &mapping)

Detailed Description

Bookkeeping for mesh subsetting and/or polyhedral cell decomposition. Although the main use case is for handling vtk meshes, it is not specific to VTK alone.

The cellMap is a local-to-global lookup for normal and decomposed cells. The pointMap is an optional local-to-global lookup for point ids. The additional ids is typically used to store the cell-centre labels for additional points of decomposed cells

Source files

• foamVtkMeshMaps.H
• foamVtkMeshMaps.C
• foamVtkMeshMapsI.H

Definition at line 54 of file foamVtkMeshMaps.H.

Constructor & Destructor Documentation

foamVtkMeshMaps()

foamVtkMeshMaps ( )

default

Member Function Documentation

cellMap() [1/2]

Foam::DynamicList< Foam::label > & cellMap ( ) const

inlinenoexcept

Definition at line 34 of file foamVtkMeshMapsI.H.

Referenced by vtuAdaptor::convertField(), vtuSizing::populateLegacy(), vtuSizing::populateShapesLegacy(), vtuSizing::populateShapesXml(), and vtuSizing::populateXml().

Here is the caller graph for this function:

cellMap() [2/2]

DynamicList<label>& cellMap ( )

inlinenoexcept

pointMap() [1/2]

Foam::DynamicList< Foam::label > & pointMap ( ) const

inlinenoexcept

Definition at line 48 of file foamVtkMeshMapsI.H.

pointMap() [2/2]

DynamicList<label>& pointMap ( )

inlinenoexcept

additionalIds() [1/2]

Foam::DynamicList< Foam::label > & additionalIds ( ) const

inlinenoexcept

Definition at line 62 of file foamVtkMeshMapsI.H.

Referenced by vtuSizing::populateLegacy(), vtuSizing::populateShapesLegacy(), vtuSizing::populateShapesXml(), and vtuSizing::populateXml().

Here is the caller graph for this function:

additionalIds() [2/2]

DynamicList<label>& additionalIds ( )

inlinenoexcept

clear()

void clear ( )

inline

Definition at line 25 of file foamVtkMeshMapsI.H.

References DynamicList::clear().

Here is the call graph for this function:

renumberCells()

void renumberCells

(

const labelUList &

mapping

)

Definition at line 26 of file foamVtkMeshMaps.C.

References Foam::inplaceRenumber().

Here is the call graph for this function:

renumberPoints()

void renumberPoints

(

const labelUList &

mapping

)

Definition at line 33 of file foamVtkMeshMaps.C.

References Foam::inplaceRenumber().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/fileFormats/vtk/part/foamVtkMeshMaps.H
• src/fileFormats/vtk/part/foamVtkMeshMaps.C
• src/fileFormats/vtk/part/foamVtkMeshMapsI.H
