fluxCorrectedVelocityFvPatchVectorField Class Reference

This boundary condition provides a velocity outlet boundary condition for patches where the pressure is specified. The outflow velocity is obtained by "zeroGradient" and then corrected from the flux: More...

Inheritance diagram for fluxCorrectedVelocityFvPatchVectorField:

Collaboration diagram for fluxCorrectedVelocityFvPatchVectorField:

Public Member Functions
	TypeName ("fluxCorrectedVelocity")
	fluxCorrectedVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &)
	fluxCorrectedVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	fluxCorrectedVelocityFvPatchVectorField (const fluxCorrectedVelocityFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)
virtual tmp< fvPatchVectorField >	clone () const
	fluxCorrectedVelocityFvPatchVectorField (const fluxCorrectedVelocityFvPatchVectorField &, const DimensionedField< vector, volMesh > &)
virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
virtual void	evaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)
virtual void	write (Ostream &) const

Detailed Description

This boundary condition provides a velocity outlet boundary condition for patches where the pressure is specified. The outflow velocity is obtained by "zeroGradient" and then corrected from the flux:

where

	=	velocity at the patch [m/s]
	=	velocity in cells adjacent to the patch [m/s]
	=	patch normal vectors
	=	flux at the patch [m3/s or kg/s]
	=	patch face area vectors [m2]

where

Property	Description	Required	Default value
phi	name of flux field	no	phi
rho	name of density field	no	rho

Example of the boundary condition specification:

    <patchName>
    {
        type            fluxCorrectedVelocity;
        phi             phi;
        rho             rho;
    }

Note

If reverse flow is possible or expected use the pressureInletOutletVelocity condition instead.

See also

Foam::zeroGradientFvPatchField Foam::pressureInletOutletVelocityFvPatchVectorField

Source files

• fluxCorrectedVelocityFvPatchVectorField.H
• fluxCorrectedVelocityFvPatchVectorField.C

Definition at line 127 of file fluxCorrectedVelocityFvPatchVectorField.H.

Constructor & Destructor Documentation

fluxCorrectedVelocityFvPatchVectorField() [1/4]

fluxCorrectedVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 32 of file fluxCorrectedVelocityFvPatchVectorField.C.

Referenced by fluxCorrectedVelocityFvPatchVectorField::clone().

Here is the caller graph for this function:

fluxCorrectedVelocityFvPatchVectorField() [2/4]

fluxCorrectedVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 60 of file fluxCorrectedVelocityFvPatchVectorField.C.

References dict.

fluxCorrectedVelocityFvPatchVectorField() [3/4]

fluxCorrectedVelocityFvPatchVectorField	(	const fluxCorrectedVelocityFvPatchVectorField &	ptf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 45 of file fluxCorrectedVelocityFvPatchVectorField.C.

fluxCorrectedVelocityFvPatchVectorField() [4/4]

fluxCorrectedVelocityFvPatchVectorField	(	const fluxCorrectedVelocityFvPatchVectorField &	fcvpvf,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 77 of file fluxCorrectedVelocityFvPatchVectorField.C.

Member Function Documentation

TypeName()

TypeName

(

"fluxCorrectedVelocity"

)

clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const

inlinevirtual

Definition at line 174 of file fluxCorrectedVelocityFvPatchVectorField.H.

References fluxCorrectedVelocityFvPatchVectorField::fluxCorrectedVelocityFvPatchVectorField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF ) const

inlinevirtual

Definition at line 191 of file fluxCorrectedVelocityFvPatchVectorField.H.

References fluxCorrectedVelocityFvPatchVectorField::fluxCorrectedVelocityFvPatchVectorField().

Here is the call graph for this function:

evaluate()

void evaluate ( const Pstream::commsTypes  commsType = Pstream::commsTypes::blocking )

virtual

Definition at line 91 of file fluxCorrectedVelocityFvPatchVectorField.C.

References Foam::dimArea, Foam::dimDensity, Foam::dimVelocity, Foam::stringOps::evaluate(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, n, Foam::operator==(), Foam::foamVersion::patch, and phi.

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 134 of file fluxCorrectedVelocityFvPatchVectorField.C.

References os(), and fvPatchField::write().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fields/fvPatchFields/derived/fluxCorrectedVelocity/fluxCorrectedVelocityFvPatchVectorField.H
• src/finiteVolume/fields/fvPatchFields/derived/fluxCorrectedVelocity/fluxCorrectedVelocityFvPatchVectorField.C
