This boundary condition provides a fixed value profile condition. More...

Inheritance diagram for fixedProfileFvPatchField< Type >:

Collaboration diagram for fixedProfileFvPatchField< Type >:

Public Member Functions
	TypeName ("fixedProfile")

	fixedProfileFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

	fixedProfileFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Field< Type > &fld)

	fixedProfileFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

	fixedProfileFvPatchField (const fixedProfileFvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

	fixedProfileFvPatchField (const fixedProfileFvPatchField< Type > &)

virtual tmp< fvPatchField< Type > >	clone () const

	fixedProfileFvPatchField (const fixedProfileFvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< fvPatchField< Type > >	clone (const DimensionedField< Type, volMesh > &iF) const

virtual void	updateCoeffs ()

virtual void	write (Ostream &) const

Public Member Functions inherited from fixedValueFvPatchField< Type >
	TypeName ("fixedValue")

	fixedValueFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

	fixedValueFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Type &value)

	fixedValueFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &, const bool valueRequired=true)

	fixedValueFvPatchField (const fixedValueFvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

	fixedValueFvPatchField (const fixedValueFvPatchField< Type > &)

	fixedValueFvPatchField (const fixedValueFvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual bool	fixesValue () const

virtual bool	assignable () const

virtual tmp< Field< Type > >	valueInternalCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< Type > >	valueBoundaryCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< Type > >	gradientInternalCoeffs () const

virtual tmp< Field< Type > >	gradientBoundaryCoeffs () const

virtual void	operator= (const UList< Type > &)

virtual void	operator= (const fvPatchField< Type > &)

virtual void	operator+= (const fvPatchField< Type > &)

virtual void	operator-= (const fvPatchField< Type > &)

virtual void	operator*= (const fvPatchField< scalar > &)

virtual void	operator/= (const fvPatchField< scalar > &)

virtual void	operator+= (const Field< Type > &)

virtual void	operator-= (const Field< Type > &)

virtual void	operator*= (const Field< scalar > &)

virtual void	operator/= (const Field< scalar > &)

virtual void	operator= (const Type &)

virtual void	operator+= (const Type &)

virtual void	operator-= (const Type &)

virtual void	operator*= (const scalar)

virtual void	operator/= (const scalar)

Public Member Functions inherited from fvPatchField< Type >
	TypeName ("fvPatchField")

	declareRunTimeSelectionTable (tmp, fvPatchField, patch,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF),(p, iF))

	declareRunTimeSelectionTable (tmp, fvPatchField, patchMapper,(const fvPatchField< Type > &ptf, const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const fvPatchFieldMapper &m),(dynamic_cast< const fvPatchFieldType & >(ptf), p, iF, m))

	declareRunTimeSelectionTable (tmp, fvPatchField, dictionary,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const dictionary &dict),(p, iF, dict))

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Type &value)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const word &patchType)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Field< Type > &)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &, const bool valueRequired=true)

	fvPatchField (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

	fvPatchField (const fvPatchField< Type > &)

	fvPatchField (const fvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< fvPatchField< Type > >	clone () const

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatch &p)

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &pf)

virtual	~fvPatchField ()=default

bool	useImplicit () const noexcept

bool	useImplicit (bool on) noexcept

virtual bool	fixesValue () const

virtual bool	assignable () const

virtual bool	coupled () const

const objectRegistry &	db () const

const fvPatch &	patch () const

const DimensionedField< Type, volMesh > &	internalField () const

const Field< Type > &	primitiveField () const

const word &	patchType () const

word &	patchType ()

bool	updated () const

bool	manipulatedMatrix () const

virtual void	autoMap (const fvPatchFieldMapper &)

virtual void	rmap (const fvPatchField< Type > &, const labelList &)

virtual tmp< Field< Type > >	snGrad () const

virtual tmp< Field< Type > >	snGrad (const scalarField &deltaCoeffs) const

virtual void	updateWeightedCoeffs (const scalarField &weights)

virtual tmp< Field< Type > >	patchInternalField () const

virtual void	patchInternalField (Field< Type > &) const

virtual tmp< Field< Type > >	patchNeighbourField () const

virtual void	initEvaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)

virtual void	evaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)

virtual tmp< Field< Type > >	valueInternalCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > >	valueBoundaryCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > >	gradientInternalCoeffs () const

virtual tmp< Field< Type > >	gradientInternalCoeffs (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > >	gradientBoundaryCoeffs () const

virtual tmp< Field< Type > >	gradientBoundaryCoeffs (const scalarField &deltaCoeffs) const

virtual void	manipulateMatrix (fvMatrix< Type > &matrix)

virtual void	manipulateMatrix (fvMatrix< Type > &matrix, const scalarField &weights)

virtual void	manipulateMatrix (fvMatrix< Type > &matrix, const label iMatrix, const direction cmp)

void	check (const fvPatchField< Type > &) const

virtual void	operator== (const fvPatchField< Type > &)

virtual void	operator== (const Field< Type > &)

virtual void	operator== (const Type &)

Additional Inherited Members
Public Types inherited from fvPatchField< Type >
typedef fvPatch	Patch

typedef calculatedFvPatchField< Type >	Calculated

Static Public Member Functions inherited from fvPatchField< Type >
static tmp< fvPatchField< Type > >	New (const word &, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > >	New (const word &, const word &actualPatchType, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > >	New (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

static tmp< fvPatchField< Type > >	New (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatch &)

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &)

static const word &	calculatedType ()

Static Public Attributes inherited from fvPatchField< Type >
static int	disallowGenericFvPatchField

Detailed Description

template<class Type>
class Foam::fixedProfileFvPatchField< Type >

This boundary condition provides a fixed value profile condition.

Usage

Property	Description	Required
`profile`	Profile Function1	yes
`direction`	Profile direction	yes
`origin`	Profile origin	yes

Example of the boundary condition specification:

    <patchName>
    {
        type       fixedProfile;
        profile    csvFile;

        profileCoeffs
        {
            nHeaderLine         0;          // Number of header lines
            refColumn           0;          // Reference column index
            componentColumns    (1 2 3);    // Component column indices
            separator           ",";        // Optional (defaults to ",")
            mergeSeparators     no;         // Merge multiple separators
            file                "Uprofile.csv";  // name of csv data file
            outOfBounds         clamp;      // Optional out-of-bounds handling
            interpolationScheme linear;     // Optional interpolation scheme
        }
        direction        (0 1 0);
        origin           0;
    }

Example setting a parabolic inlet profile for the PitzDaily case:

    inlet
    {
        type            fixedProfile;

        profile         polynomial
        (
            ((1 0 0)        (0 0 0))
            ((-6200 0 0)    (2 0 0))
        );
        direction       (0 1 0);
        origin          0.0127;
    }

Note: The profile entry is a Function1 type. The example above gives the usage for supplying csv file.

See also: Foam::fixedValueFvPatchField Foam::Function1Types Foam::timeVaryingMappedFixedValueFvPatchField

Source files

Definition at line 127 of file fixedProfileFvPatchField.H.

Constructor & Destructor Documentation

◆ fixedProfileFvPatchField() [1/6]

fixedProfileFvPatchField	(	const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF
	)

Definition at line 28 of file fixedProfileFvPatchField.C.

◆ fixedProfileFvPatchField() [2/6]

fixedProfileFvPatchField	(	const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF,
		const Field< Type > &	fld
	)

Definition at line 42 of file fixedProfileFvPatchField.C.

◆ fixedProfileFvPatchField() [3/6]

fixedProfileFvPatchField	(	const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 57 of file fixedProfileFvPatchField.C.

References Foam::abort(), Foam::stringOps::evaluate(), Foam::FatalError, FatalErrorInFunction, and Foam::mag().

Here is the call graph for this function:

◆ fixedProfileFvPatchField() [4/6]

fixedProfileFvPatchField	(	const fixedProfileFvPatchField< Type > &	ptf,
		const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 85 of file fixedProfileFvPatchField.C.

References Foam::stringOps::evaluate().

Here is the call graph for this function:

◆ fixedProfileFvPatchField() [5/6]

fixedProfileFvPatchField ( const fixedProfileFvPatchField< Type > & ptf )

Definition at line 104 of file fixedProfileFvPatchField.C.

◆ fixedProfileFvPatchField() [6/6]

fixedProfileFvPatchField	(	const fixedProfileFvPatchField< Type > &	ptf,
		const DimensionedField< Type, volMesh > &	iF
	)

Definition at line 117 of file fixedProfileFvPatchField.C.

References Foam::stringOps::evaluate().

Here is the call graph for this function:

Member Function Documentation

◆ TypeName()

TypeName ( "fixedProfile" )

◆ clone() [1/2]

virtual tmp<fvPatchField<Type> > clone ( ) const

inlinevirtual

Reimplemented from fixedValueFvPatchField< Type >.

Definition at line 191 of file fixedProfileFvPatchField.H.

◆ clone() [2/2]

virtual tmp<fvPatchField<Type> > clone ( const DimensionedField< Type, volMesh > & iF ) const

inlinevirtual

Reimplemented from fixedValueFvPatchField< Type >.

Definition at line 208 of file fixedProfileFvPatchField.H.

◆ updateCoeffs()

void updateCoeffs

virtual

Reimplemented from fvPatchField< Type >.

Definition at line 138 of file fixedProfileFvPatchField.C.

References Foam::operator==(), and Foam::foamVersion::patch.

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Reimplemented from fixedValueFvPatchField< Type >.

Definition at line 153 of file fixedProfileFvPatchField.C.

References os(), and Foam::vtk::write().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/finiteVolume/fields/fvPatchFields/derived/fixedProfile/fixedProfileFvPatchField.H
src/finiteVolume/fields/fvPatchFields/derived/fixedProfile/fixedProfileFvPatchField.C
