Public Member Functions | Protected Attributes | List of all members
fixedJumpAMIFvPatchField< Type > Class Template Reference
Boundary conditions » Coupled

This boundary condition provides a jump condition, across non-conformal cyclic path-pairs, employing an arbitraryMeshInterface (AMI). More...

Inheritance diagram for fixedJumpAMIFvPatchField< Type >:
Inheritance graph
[legend]
Collaboration diagram for fixedJumpAMIFvPatchField< Type >:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("fixedJumpAMI")

 fixedJumpAMIFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

 fixedJumpAMIFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

 fixedJumpAMIFvPatchField (const fixedJumpAMIFvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

 fixedJumpAMIFvPatchField (const fixedJumpAMIFvPatchField< Type > &)

virtual tmp< fvPatchField< Type > > clone () const

 fixedJumpAMIFvPatchField (const fixedJumpAMIFvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< fvPatchField< Type > > clone (const DimensionedField< Type, volMesh > &iF) const

virtual tmp< Field< Type > > jump () const

virtual void autoMap (const fvPatchFieldMapper &)

virtual void rmap (const fvPatchField< Type > &, const labelList &)

virtual void write (Ostream &) const

- Public Member Functions inherited from jumpCyclicAMIFvPatchField< Type >
 TypeName ("jumpCyclicAMI")

 jumpCyclicAMIFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

 jumpCyclicAMIFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

 jumpCyclicAMIFvPatchField (const jumpCyclicAMIFvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

 jumpCyclicAMIFvPatchField (const jumpCyclicAMIFvPatchField< Type > &)

 jumpCyclicAMIFvPatchField (const jumpCyclicAMIFvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual const word & interfaceFieldType () const

tmp< Field< Type > > patchNeighbourField () const

virtual void updateInterfaceMatrix (solveScalarField &result, const bool add, const lduAddressing &lduAddr, const label patchId, const solveScalarField &psiInternal, const scalarField &coeffs, const direction cmpt, const Pstream::commsTypes commsType) const

virtual void updateInterfaceMatrix (Field< Type > &, const bool add, const lduAddressing &lduAddr, const label patchId, const Field< Type > &, const scalarField &, const Pstream::commsTypes commsType) const

void updateInterfaceMatrix (solveScalarField &result, const bool add, const lduAddressing &lduAddr, const label patchId, const solveScalarField &psiInternal, const scalarField &coeffs, const direction cmpt, const Pstream::commsTypes commsType) const

void updateInterfaceMatrix (solveScalarField &result, const bool add, const lduAddressing &lduAddr, const label patchId, const solveScalarField &psiInternal, const scalarField &coeffs, const direction cmpt, const Pstream::commsTypes) const

- Public Member Functions inherited from cyclicAMIFvPatchField< Type >
 TypeName (cyclicAMIFvPatch::typeName_())

 cyclicAMIFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

 cyclicAMIFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

 cyclicAMIFvPatchField (const cyclicAMIFvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

 cyclicAMIFvPatchField (const cyclicAMIFvPatchField< Type > &)

 cyclicAMIFvPatchField (const cyclicAMIFvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

const cyclicAMIFvPatch & cyclicAMIPatch () const

virtual bool coupled () const

const cyclicAMIFvPatchField< Type > & neighbourPatchField () const

virtual void manipulateMatrix (fvMatrix< Type > &m, const label iMatrix, const direction cmpt)

virtual bool doTransform () const

virtual const tensorField & forwardT () const

virtual const tensorField & reverseT () const

virtual int rank () const

- Public Member Functions inherited from cyclicAMILduInterfaceField
 TypeName ("cyclicAMILduInterfaceField")

 cyclicAMILduInterfaceField ()

virtual ~cyclicAMILduInterfaceField ()

template<class Type >
void transformCoupleField (Field< Type > &f) const

void transformCoupleField (solveScalarField &psiInternal, const direction cmpt) const

- Public Member Functions inherited from coupledFvPatchField< Type >
 TypeName (coupledFvPatch::typeName_())

 coupledFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

 coupledFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Field< Type > &)

 coupledFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &, const bool valueRequired=true)

 coupledFvPatchField (const coupledFvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

 coupledFvPatchField (const coupledFvPatchField< Type > &)

 coupledFvPatchField (const coupledFvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< Field< Type > > snGrad (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > > snGrad () const

virtual void initEvaluate (const Pstream::commsTypes commsType)

virtual void evaluate (const Pstream::commsTypes commsType)

virtual tmp< Field< Type > > valueInternalCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< Type > > valueBoundaryCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< Type > > gradientInternalCoeffs (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > > gradientInternalCoeffs () const

virtual tmp< Field< Type > > gradientBoundaryCoeffs (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > > gradientBoundaryCoeffs () const

- Public Member Functions inherited from LduInterfaceField< Type >
 TypeName ("LduInterfaceField")

 LduInterfaceField (const lduInterface &patch)

virtual ~LduInterfaceField ()=default

virtual void initInterfaceMatrixUpdate (Field< Type > &, const bool add, const lduAddressing &, const label interfacei, const Field< Type > &, const scalarField &, const Pstream::commsTypes commsType) const

virtual void initInterfaceMatrixUpdate (solveScalarField &result, const bool add, const lduAddressing &, const label interfacei, const solveScalarField &psiInternal, const scalarField &coeffs, const direction cmpt, const Pstream::commsTypes commsType) const

virtual void updateInterfaceMatrix (solveScalarField &result, const bool add, const lduAddressing &, const label interfacei, const solveScalarField &psiInternal, const scalarField &coeffs, const direction cmpt, const Pstream::commsTypes commsType) const=0

- Public Member Functions inherited from lduInterfaceField
 TypeName ("lduInterfaceField")

 lduInterfaceField (const lduInterface &patch)

virtual ~lduInterfaceField ()=default

const lduInterface & interface () const

bool updatedMatrix () const

bool & updatedMatrix ()

virtual bool ready () const

virtual void initInterfaceMatrixUpdate (solveScalarField &result, const bool add, const lduAddressing &, const label interfacei, const solveScalarField &psiInternal, const scalarField &coeffs, const direction cmpt, const Pstream::commsTypes commsType) const

template<class Type >
void addToInternalField (Field< Type > &result, const bool add, const labelUList &faceCells, const scalarField &coeffs, const Field< Type > &vals) const

- Public Member Functions inherited from fvPatchField< Type >
 TypeName ("fvPatchField")

 declareRunTimeSelectionTable (tmp, fvPatchField, patch,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF),(p, iF))

 declareRunTimeSelectionTable (tmp, fvPatchField, patchMapper,(const fvPatchField< Type > &ptf, const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const fvPatchFieldMapper &m),(dynamic_cast< const fvPatchFieldType & >(ptf), p, iF, m))

 declareRunTimeSelectionTable (tmp, fvPatchField, dictionary,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const dictionary &dict),(p, iF, dict))

 fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

 fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Type &value)

 fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const word &patchType)

 fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Field< Type > &)

 fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &, const bool valueRequired=true)

 fvPatchField (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

 fvPatchField (const fvPatchField< Type > &)

 fvPatchField (const fvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< fvPatchField< Type > > clone () const

Foam::tmp< Foam::fvPatchField< Type > > NewCalculatedType (const fvPatch &p)

Foam::tmp< Foam::fvPatchField< Type > > NewCalculatedType (const fvPatchField< Type2 > &pf)

virtual ~fvPatchField ()=default

bool useImplicit () const noexcept

bool useImplicit (bool on) noexcept

virtual bool fixesValue () const

virtual bool assignable () const

virtual bool coupled () const

const objectRegistry & db () const

const fvPatch & patch () const

const DimensionedField< Type, volMesh > & internalField () const

const Field< Type > & primitiveField () const

const word & patchType () const

word & patchType ()

bool updated () const

bool manipulatedMatrix () const

virtual tmp< Field< Type > > snGrad () const

virtual void updateCoeffs ()

virtual void updateWeightedCoeffs (const scalarField &weights)

virtual tmp< Field< Type > > patchInternalField () const

virtual void patchInternalField (Field< Type > &) const

virtual tmp< Field< Type > > patchNeighbourField () const

virtual tmp< Field< Type > > valueInternalCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > > valueBoundaryCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > > gradientInternalCoeffs () const

virtual tmp< Field< Type > > gradientBoundaryCoeffs () const

virtual void manipulateMatrix (fvMatrix< Type > &matrix)

virtual void manipulateMatrix (fvMatrix< Type > &matrix, const scalarField &weights)

void check (const fvPatchField< Type > &) const

virtual void operator= (const UList< Type > &)

virtual void operator= (const fvPatchField< Type > &)

virtual void operator= (const Type &)

virtual void operator+= (const fvPatchField< Type > &)

virtual void operator+= (const Field< Type > &)

virtual void operator+= (const Type &)

virtual void operator-= (const fvPatchField< Type > &)

virtual void operator-= (const Field< Type > &)

virtual void operator-= (const Type &)

virtual void operator*= (const fvPatchField< scalar > &)

virtual void operator*= (const Field< scalar > &)

virtual void operator*= (const scalar)

virtual void operator/= (const fvPatchField< scalar > &)

virtual void operator/= (const Field< scalar > &)

virtual void operator/= (const scalar)

virtual void operator== (const fvPatchField< Type > &)

virtual void operator== (const Field< Type > &)

virtual void operator== (const Type &)


Protected Attributes

Field< Type > jump_


Additional Inherited Members

- Public Types inherited from fvPatchField< Type >
typedef fvPatch Patch

typedef calculatedFvPatchField< Type > Calculated

- Static Public Member Functions inherited from fvPatchField< Type >
static tmp< fvPatchField< Type > > New (const word &, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > > New (const word &, const word &actualPatchType, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > > New (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

static tmp< fvPatchField< Type > > New (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

static tmp< fvPatchField< Type > > NewCalculatedType (const fvPatch &)

static tmp< fvPatchField< Type > > NewCalculatedType (const fvPatchField< Type2 > &)

static const word & calculatedType ()

- Static Public Attributes inherited from fvPatchField< Type >
static int disallowGenericFvPatchField


Detailed Description

template<class Type>
class Foam::fixedJumpAMIFvPatchField< Type >

This boundary condition provides a jump condition, across non-conformal cyclic path-pairs, employing an arbitraryMeshInterface (AMI).

The jump is specified as a fixed value field, applied as an offset to the 'owner' patch.

Usage
Property Description Required Default value
patchType underlying patch type should be cyclic yes
jump current jump value yes

Example of the boundary condition specification:

    <patchName>
    {
        type            fixedJumpAMI;
        patchType       cyclic;
        jump            uniform 10;
    }

The above example shows the use of a fixed jump of '10'.

Note
The underlying patchType should be set to cyclicAMI
See also
Foam::jumpCyclicAMIFvPatchField
Source files

Definition at line 94 of file fixedJumpAMIFvPatchField.H.

Constructor & Destructor Documentation

◆ fixedJumpAMIFvPatchField() [1/5]

fixedJumpAMIFvPatchField ( const fvPatch &  p,
const DimensionedField< Type, volMesh > &  iF
)

Definition at line 27 of file fixedJumpAMIFvPatchField.C.

◆ fixedJumpAMIFvPatchField() [2/5]

fixedJumpAMIFvPatchField ( const fvPatch &  p,
const DimensionedField< Type, volMesh > &  iF,
const dictionary &  dict
)

Definition at line 53 of file fixedJumpAMIFvPatchField.C.

◆ fixedJumpAMIFvPatchField() [3/5]

fixedJumpAMIFvPatchField ( const fixedJumpAMIFvPatchField< Type > &  ptf,
const fvPatch &  p,
const DimensionedField< Type, volMesh > &  iF,
const fvPatchFieldMapper &  mapper
)

Definition at line 39 of file fixedJumpAMIFvPatchField.C.

◆ fixedJumpAMIFvPatchField() [4/5]

fixedJumpAMIFvPatchField ( const fixedJumpAMIFvPatchField< Type > &  ptf)

Definition at line 83 of file fixedJumpAMIFvPatchField.C.

◆ fixedJumpAMIFvPatchField() [5/5]

fixedJumpAMIFvPatchField ( const fixedJumpAMIFvPatchField< Type > &  ptf,
const DimensionedField< Type, volMesh > &  iF
)

Definition at line 94 of file fixedJumpAMIFvPatchField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "fixedJumpAMI"  )

◆ clone() [1/2]

virtual tmp<fvPatchField<Type> > clone ( ) const
inlinevirtual

Reimplemented from cyclicAMIFvPatchField< Type >.

Reimplemented in uniformJumpAMIFvPatchField< Type >.

Definition at line 147 of file fixedJumpAMIFvPatchField.H.

◆ clone() [2/2]

virtual tmp<fvPatchField<Type> > clone ( const DimensionedField< Type, volMesh > &  iF) const
inlinevirtual

Reimplemented from cyclicAMIFvPatchField< Type >.

Reimplemented in uniformJumpAMIFvPatchField< Type >, and energyJumpAMIFvPatchScalarField.

Definition at line 164 of file fixedJumpAMIFvPatchField.H.

◆ jump()

Foam::tmp< Foam::Field< Type > > jump
virtual

Implements jumpCyclicAMIFvPatchField< Type >.

Definition at line 107 of file fixedJumpAMIFvPatchField.C.

Referenced by fixedJumpAMIFvPatchField< scalar >::jump().

Here is the caller graph for this function:

◆ autoMap()

void autoMap ( const fvPatchFieldMapper &  m)
virtual

Reimplemented from fvPatchField< Type >.

Definition at line 139 of file fixedJumpAMIFvPatchField.C.

◆ rmap()

void rmap ( const fvPatchField< Type > &  ptf,
const labelList &  addr
)
virtual

Reimplemented from fvPatchField< Type >.

Definition at line 150 of file fixedJumpAMIFvPatchField.C.

Referenced by fixedJumpAMIFvPatchField< scalar >::rmap().

Here is the caller graph for this function:

◆ write()

void write ( Ostream &  os) const
virtual

Reimplemented from cyclicAMIFvPatchField< Type >.

Reimplemented in uniformJumpAMIFvPatchField< Type >, and energyJumpAMIFvPatchScalarField.

Definition at line 164 of file fixedJumpAMIFvPatchField.C.

Referenced by energyJumpAMIFvPatchScalarField::write().

Here is the caller graph for this function:

Member Data Documentation

◆ jump_

Field<Type> jump_
protected

Definition at line 104 of file fixedJumpAMIFvPatchField.H.

Referenced by fixedJumpAMIFvPatchField< scalar >::rmap().

The documentation for this class was generated from the following files:

Copyright © 2011-2018  OpenFOAM | OPENFOAM® is a registered trademark of OpenCFD Ltd.

Generated by   doxygen 1.8.17
