fixedFluxPressureFvPatchScalarField Class Reference

This boundary condition sets the pressure gradient to the provided value such that the flux on the boundary is that specified by the velocity boundary condition. More...

Inheritance diagram for fixedFluxPressureFvPatchScalarField:

Collaboration diagram for fixedFluxPressureFvPatchScalarField:

Public Member Functions
	TypeName ("fixedFluxPressure")
	fixedFluxPressureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	fixedFluxPressureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	fixedFluxPressureFvPatchScalarField (const fixedFluxPressureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
	fixedFluxPressureFvPatchScalarField (const fixedFluxPressureFvPatchScalarField &)
virtual tmp< fvPatchScalarField >	clone () const
	fixedFluxPressureFvPatchScalarField (const fixedFluxPressureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
virtual void	updateSnGrad (const scalarField &snGradp)
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const
Public Member Functions inherited from updateableSnGrad
	updateableSnGrad ()=default
virtual	~updateableSnGrad ()=default

Detailed Description

This boundary condition sets the pressure gradient to the provided value such that the flux on the boundary is that specified by the velocity boundary condition.

Example of the boundary condition specification:

<patchName>
{
    type            fixedFluxPressure;
}

See also

Foam::fixedGradientFvPatchField

Source files

• fixedFluxPressureFvPatchScalarField.H
• fixedFluxPressureFvPatchScalarField.C

Definition at line 65 of file fixedFluxPressureFvPatchScalarField.H.

Constructor & Destructor Documentation

fixedFluxPressureFvPatchScalarField() [1/5]

fixedFluxPressureFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 31 of file fixedFluxPressureFvPatchScalarField.C.

Referenced by fixedFluxPressureFvPatchScalarField::clone().

Here is the caller graph for this function:

fixedFluxPressureFvPatchScalarField() [2/5]

fixedFluxPressureFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 42 of file fixedFluxPressureFvPatchScalarField.C.

References dict, and p.

fixedFluxPressureFvPatchScalarField() [3/5]

fixedFluxPressureFvPatchScalarField	(	const fixedFluxPressureFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 69 of file fixedFluxPressureFvPatchScalarField.C.

References Foam::notNull(), and Foam::foamVersion::patch.

Here is the call graph for this function:

fixedFluxPressureFvPatchScalarField() [4/5]

fixedFluxPressureFvPatchScalarField

(

const fixedFluxPressureFvPatchScalarField &

wbppsf

)

Definition at line 111 of file fixedFluxPressureFvPatchScalarField.C.

fixedFluxPressureFvPatchScalarField() [5/5]

fixedFluxPressureFvPatchScalarField	(	const fixedFluxPressureFvPatchScalarField &	wbppsf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 121 of file fixedFluxPressureFvPatchScalarField.C.

Member Function Documentation

TypeName()

TypeName

(

"fixedFluxPressure"

)

clone() [1/2]

virtual tmp<fvPatchScalarField> clone ( ) const

inlinevirtual

Reimplemented in fixedFluxExtrapolatedPressureFvPatchScalarField.

Definition at line 116 of file fixedFluxPressureFvPatchScalarField.H.

References fixedFluxPressureFvPatchScalarField::fixedFluxPressureFvPatchScalarField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF ) const

inlinevirtual

Reimplemented in fixedFluxExtrapolatedPressureFvPatchScalarField.

Definition at line 133 of file fixedFluxPressureFvPatchScalarField.H.

References fixedFluxPressureFvPatchScalarField::fixedFluxPressureFvPatchScalarField().

Here is the call graph for this function:

updateSnGrad()

void updateSnGrad ( const scalarField &  snGradp )

virtual

Implements updateableSnGrad.

Definition at line 134 of file fixedFluxPressureFvPatchScalarField.C.

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 150 of file fixedFluxPressureFvPatchScalarField.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and timeIndex.

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 167 of file fixedFluxPressureFvPatchScalarField.C.

References os(), and Foam::vtk::write().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fields/fvPatchFields/derived/fixedFluxPressure/fixedFluxPressureFvPatchScalarField.H
• src/finiteVolume/fields/fvPatchFields/derived/fixedFluxPressure/fixedFluxPressureFvPatchScalarField.C
