filmPyrolysisVelocityCoupledFvPatchVectorField Class Reference

This boundary condition is designed to be used in conjunction with surface film and pyrolysis modelling. More...

Inheritance diagram for filmPyrolysisVelocityCoupledFvPatchVectorField:

Collaboration diagram for filmPyrolysisVelocityCoupledFvPatchVectorField:

Public Member Functions
	TypeName ("filmPyrolysisVelocityCoupled")
	filmPyrolysisVelocityCoupledFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &)
	filmPyrolysisVelocityCoupledFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	filmPyrolysisVelocityCoupledFvPatchVectorField (const filmPyrolysisVelocityCoupledFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)
	filmPyrolysisVelocityCoupledFvPatchVectorField (const filmPyrolysisVelocityCoupledFvPatchVectorField &)
virtual tmp< fvPatchVectorField >	clone () const
	filmPyrolysisVelocityCoupledFvPatchVectorField (const filmPyrolysisVelocityCoupledFvPatchVectorField &, const DimensionedField< vector, volMesh > &)
virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
const word &	phiName () const
word &	phiName ()
const word &	rhoName () const
word &	rhoName ()
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Detailed Description

This boundary condition is designed to be used in conjunction with surface film and pyrolysis modelling.

It provides a velocity boundary condition for patches on the primary region based on whether the patch is seen to be 'wet', retrieved from the film alpha field.

• if the patch is wet, the velocity is set using the film velocity
• otherwise, it is set using pyrolysis out-gassing velocity

Example of the boundary condition specification:

<patchName>
{
    type            filmPyrolysisVelocityCoupled;
    phi             phi;      // name of flux field (default = phi)
    rho             rho;      // name of density field (default = rho)
    deltaWet        1e-4;     // threshold height for 'wet' film
    value           uniform   (0 0 0); // initial velocity / [m/s]
}

Source files

• filmPyrolysisVelocityCoupledFvPatchVectorField.H
• filmPyrolysisVelocityCoupledFvPatchVectorField.C

Definition at line 65 of file filmPyrolysisVelocityCoupledFvPatchVectorField.H.

Constructor & Destructor Documentation

filmPyrolysisVelocityCoupledFvPatchVectorField() [1/5]

filmPyrolysisVelocityCoupledFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 32 of file filmPyrolysisVelocityCoupledFvPatchVectorField.C.

Referenced by filmPyrolysisVelocityCoupledFvPatchVectorField::clone().

Here is the caller graph for this function:

filmPyrolysisVelocityCoupledFvPatchVectorField() [2/5]

filmPyrolysisVelocityCoupledFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 64 of file filmPyrolysisVelocityCoupledFvPatchVectorField.C.

filmPyrolysisVelocityCoupledFvPatchVectorField() [3/5]

filmPyrolysisVelocityCoupledFvPatchVectorField	(	const filmPyrolysisVelocityCoupledFvPatchVectorField &	ptf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 47 of file filmPyrolysisVelocityCoupledFvPatchVectorField.C.

filmPyrolysisVelocityCoupledFvPatchVectorField() [4/5]

filmPyrolysisVelocityCoupledFvPatchVectorField

(

const filmPyrolysisVelocityCoupledFvPatchVectorField &

fpvpvf

)

Definition at line 86 of file filmPyrolysisVelocityCoupledFvPatchVectorField.C.

filmPyrolysisVelocityCoupledFvPatchVectorField() [5/5]

filmPyrolysisVelocityCoupledFvPatchVectorField	(	const filmPyrolysisVelocityCoupledFvPatchVectorField &	fpvpvf,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 100 of file filmPyrolysisVelocityCoupledFvPatchVectorField.C.

Member Function Documentation

TypeName()

TypeName

(

"filmPyrolysisVelocityCoupled"

)

clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const

inlinevirtual

Definition at line 124 of file filmPyrolysisVelocityCoupledFvPatchVectorField.H.

References filmPyrolysisVelocityCoupledFvPatchVectorField::filmPyrolysisVelocityCoupledFvPatchVectorField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF ) const

inlinevirtual

Definition at line 141 of file filmPyrolysisVelocityCoupledFvPatchVectorField.H.

References filmPyrolysisVelocityCoupledFvPatchVectorField::filmPyrolysisVelocityCoupledFvPatchVectorField().

Here is the call graph for this function:

phiName() [1/2]

const word& phiName ( ) const

inline

Definition at line 157 of file filmPyrolysisVelocityCoupledFvPatchVectorField.H.

phiName() [2/2]

word& phiName ( )

inline

Definition at line 163 of file filmPyrolysisVelocityCoupledFvPatchVectorField.H.

rhoName() [1/2]

const word& rhoName ( ) const

inline

Definition at line 169 of file filmPyrolysisVelocityCoupledFvPatchVectorField.H.

rhoName() [2/2]

word& rhoName ( )

inline

Definition at line 175 of file filmPyrolysisVelocityCoupledFvPatchVectorField.H.

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 115 of file filmPyrolysisVelocityCoupledFvPatchVectorField.C.

References Foam::dimArea, Foam::dimDensity, Foam::dimVelocity, Foam::exit(), Foam::FatalError, FatalErrorInFunction, objectRegistry::findObject(), UPstream::msgType(), Foam::nl, Foam::foamVersion::patch, phi, and regionModel::time().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 206 of file filmPyrolysisVelocityCoupledFvPatchVectorField.C.

References os(), fvPatchField::write(), and Ostream::writeEntryIfDifferent().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/regionModels/regionCoupling/derivedFvPatchFields/filmPyrolysisVelocityCoupled/filmPyrolysisVelocityCoupledFvPatchVectorField.H
• src/regionModels/regionCoupling/derivedFvPatchFields/filmPyrolysisVelocityCoupled/filmPyrolysisVelocityCoupledFvPatchVectorField.C
