Version of masterUncollatedFileOperation that collates regIOobjects into a container in the processors/ subdirectory. More...

Inheritance diagram for collatedFileOperation:

[legend]

Collaboration diagram for collatedFileOperation:

[legend]

Public Member Functions
	TypeName ("collated")

	collatedFileOperation (bool verbose)

	collatedFileOperation (const label comm, const labelList &ioRanks, const word &typeName, bool verbose)

virtual	~collatedFileOperation ()

virtual fileName	objectPath (const IOobject &io, const word &typeName) const

virtual bool	writeObject (const regIOobject &, IOstreamOption streamOpt=IOstreamOption(), const bool valid=true) const

virtual void	flush () const

virtual word	processorsDir (const IOobject &) const

virtual word	processorsDir (const fileName &) const

virtual void	setNProcs (const label nProcs)

Public Member Functions inherited from masterUncollatedFileOperation
	TypeName ("masterUncollated")

	masterUncollatedFileOperation (bool verbose)

	masterUncollatedFileOperation (const label comm, bool verbose)

virtual	~masterUncollatedFileOperation ()

virtual bool	mkDir (const fileName &, mode_t=0777) const

virtual bool	chMod (const fileName &, const mode_t) const

virtual mode_t	mode (const fileName &, const bool followLink=true) const

virtual fileName::Type	type (const fileName &, const bool followLink=true) const

virtual bool	exists (const fileName &, const bool checkGzip=true, const bool followLink=true) const

virtual bool	isDir (const fileName &, const bool followLink=true) const

virtual bool	isFile (const fileName &, const bool checkGzip=true, const bool followLink=true) const

virtual off_t	fileSize (const fileName &, const bool followLink=true) const

virtual time_t	lastModified (const fileName &, const bool followLink=true) const

virtual double	highResLastModified (const fileName &, const bool followLink=true) const

virtual fileNameList	readDir (const fileName &, const fileName::Type=fileName::FILE, const bool filtergz=true, const bool followLink=true) const

virtual bool	cp (const fileName &src, const fileName &dst, const bool followLink=true) const

virtual bool	ln (const fileName &src, const fileName &dst) const

virtual bool	mv (const fileName &src, const fileName &dst, const bool followLink=false) const

virtual bool	mvBak (const fileName &, const std::string &ext="bak") const

virtual bool	rm (const fileName &) const

virtual bool	rmDir (const fileName &dir, const bool silent=false) const

virtual fileName	filePath (const bool checkGlobal, const IOobject &io, const word &typeName, const bool search) const

virtual fileName	dirPath (const bool checkGlobal, const IOobject &io, const bool search) const

virtual fileNameList	readObjects (const objectRegistry &db, const fileName &instance, const fileName &local, word &newInstance) const

virtual bool	readHeader (IOobject &, const fileName &, const word &typeName) const

virtual autoPtr< ISstream >	readStream (regIOobject &, const fileName &, const word &typeName, const bool valid=true) const

virtual bool	read (regIOobject &, const bool masterOnly, const IOstreamOption::streamFormat format, const word &typeName) const

virtual autoPtr< ISstream >	NewIFstream (const fileName &) const

virtual autoPtr< OSstream >	NewOFstream (const fileName &pathname, IOstreamOption streamOpt=IOstreamOption(), const bool valid=true) const

virtual label	addWatch (const fileName &) const

virtual bool	removeWatch (const label) const

virtual label	findWatch (const labelList &watchIndices, const fileName &) const

virtual void	addWatches (regIOobject &, const fileNameList &) const

virtual fileName	getFile (const label) const

virtual void	updateStates (const bool masterOnly, const bool syncPar) const

virtual fileMonitor::fileState	getState (const label) const

virtual void	setUnmodified (const label) const

virtual instantList	findTimes (const fileName &, const word &) const

virtual IOobject	findInstance (const IOobject &io, const scalar startValue, const word &stopInstance) const

virtual void	setTime (const Time &) const

const HashPtrTable< instantList > &	times () const

Public Member Functions inherited from fileOperation
	TypeName ("fileOperation")

	fileOperation (const label comm, const bool distributedRoots=false)

	declareRunTimeSelectionTable (autoPtr, fileOperation, word,(bool verbose),(verbose))

virtual	~fileOperation ()=default

bool	distributed () const noexcept

bool	distributed (bool on) const noexcept

virtual fileName	filePath (const fileName &) const

virtual label	nProcs (const fileName &dir, const fileName &local="") const

fileName	processorsCasePath (const IOobject &, const word &procDir) const

fileName	processorsPath (const IOobject &, const word &instance, const word &procDir) const

fileName	processorsPath (const fileName &, const word &procDir) const

Static Public Attributes
static float	maxThreadFileBufferSize

Static Public Attributes inherited from masterUncollatedFileOperation
static float	maxMasterFileBufferSize

Static Public Attributes inherited from fileOperation
static const Enum< pathType >	pathTypeNames_

static word	processorsBaseDir = "processors"

static word	defaultFileHandler

static autoPtr< fileOperation >	fileHandlerPtr_

Protected Member Functions
void	printBanner (const bool printRanks=false) const

bool	isMasterRank (const label proci) const

bool	appendObject (const regIOobject &io, const fileName &pathName, IOstreamOption streamOpt) const

Protected Member Functions inherited from masterUncollatedFileOperation
template<class Type >
Type	scatterList (const UList< Type > &, const int, const label comm) const

template<class Type , class fileOp >
Type	masterOp (const fileName &, const fileOp &fop, const int tag, const label comm) const

template<class Type , class fileOp >
Type	masterOp (const fileName &, const fileName &, const fileOp &fop, const int tag, const label comm) const

virtual fileName	filePathInfo (const bool checkGlobal, const bool isFile, const IOobject &, const bool search, pathType &searchType, word &processorsDir, word &instance) const

fileName	localObjectPath (const IOobject &, const pathType &searchType, const word &processorsDir, const word &instancePath) const

bool	exists (const dirIndexList &, IOobject &io) const

Protected Member Functions inherited from fileOperation
fileMonitor &	monitor () const

refPtr< dirIndexList >	lookupAndCacheProcessorsPath (const fileName &objectPath, const bool syncPar) const

virtual refPtr< dirIndexList >	lookupProcessorsPath (const fileName &objectPath) const

bool	exists (IOobject &io) const

Protected Attributes
const label	myComm_

OFstreamCollator	writer_

label	nProcs_

const labelList	ioRanks_

Protected Attributes inherited from masterUncollatedFileOperation
const label	myComm_

HashPtrTable< instantList >	times_

Protected Attributes inherited from fileOperation
const label	comm_

bool	distributed_

HashTable< dirIndexList >	procsDirs_

autoPtr< fileMonitor >	monitorPtr_

Additional Inherited Members
Public Types inherited from fileOperation
enum	pathType : int { NOTFOUND = 0, ABSOLUTE, OBJECT, WRITEOBJECT, PROCUNCOLLATED, PROCBASEOBJECT = PROCUNCOLLATED + 1, PROCOBJECT = PROCBASEOBJECT + 1, PARENTOBJECT, FINDINSTANCE, PROCUNCOLLATEDINSTANCE, PROCBASEINSTANCE, PROCINSTANCE }

typedef Tuple2< fileName, Tuple2< pathType, int > >	dirIndex

typedef List< dirIndex >	dirIndexList

typedef IntRange< int >	procRangeType

Static Public Member Functions inherited from masterUncollatedFileOperation
static bool	uniformFile (const fileNameList &)

Static Public Member Functions inherited from fileOperation
static autoPtr< fileOperation >	NewUncollated ()

static autoPtr< fileOperation >	New (const word &handlerType, bool verbose=false)

static instantList	sortTimes (const fileNameList &dirEntries, const word &constantName="constant")

static label	splitProcessorPath (const fileName &objectPath, fileName &path, fileName &procDir, fileName &local, procRangeType &group, label &nProcs)

static label	detectProcessorPath (const fileName &objPath)

Static Protected Member Functions inherited from masterUncollatedFileOperation
static labelList	subRanks (const label n)

static word	findInstancePath (const instantList &timeDirs, const instant &t)

static void	readAndSend (const fileName &filePath, const labelUList &procs, PstreamBuffers &pBufs)

static autoPtr< ISstream >	read (IOobject &io, const label comm, const bool uniform, const fileNameList &filePaths, const boolList &procValid)

Static Protected Member Functions inherited from fileOperation
static labelList	ioRanks ()

static void	mergeTimes (const instantList &extraTimes, const word &constantName, instantList &times)

static bool	isFileOrDir (const bool isFile, const fileName &)

Detailed Description

Version of masterUncollatedFileOperation that collates regIOobjects into a container in the processors/ subdirectory.

Uses threading if maxThreadFileBufferSize != 0. > 0 : Can use mpi inside thread to collect data if buffer is not large enough. Does need full thread support inside MPI.

< 0 : special : -maxThreadFileBufferSize is guaranteed large enough for all writing. Initialises MPI without thread support.

See also: masterUncollatedFileOperation

Source files

Definition at line 61 of file collatedFileOperation.H.

Constructor & Destructor Documentation

◆ collatedFileOperation() [1/2]

collatedFileOperation ( bool verbose )

explicit

Definition at line 252 of file collatedFileOperation.C.

References Foam::infoDetailLevel.

◆ collatedFileOperation() [2/2]

collatedFileOperation	(	const label	comm,
		const labelList &	ioRanks,
		const word &	typeName,
		bool	verbose
	)

Definition at line 282 of file collatedFileOperation.C.

References Foam::infoDetailLevel.

◆ ~collatedFileOperation()

~collatedFileOperation ( )

virtual

Definition at line 304 of file collatedFileOperation.C.

References collatedFileOperation::flush(), UPstream::freeCommunicator(), collatedFileOperation::myComm_, and UPstream::worldComm.

Here is the call graph for this function:

Member Function Documentation

◆ printBanner()

void printBanner ( const bool printRanks = false ) const

protected

Definition at line 73 of file collatedFileOperation.C.

References DynamicList::append(), DetailInfo, stdFoam::end(), Foam::endl(), forAll, Foam::constant::atomic::group, Foam::hostName(), and Foam::nl.

Here is the call graph for this function:

◆ isMasterRank()

bool isMasterRank ( const label proci ) const

protected

Definition at line 158 of file collatedFileOperation.C.

◆ appendObject()

bool appendObject	(	const regIOobject &	io,
		const fileName &	pathName,
		IOstreamOption	streamOpt
	)		const

protected

Definition at line 181 of file collatedFileOperation.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::FatalIOError, FatalIOErrorInFunction, IOobject::name(), IOobject::objectPath(), os(), Foam::Pout, IOstreamOption::version(), and Foam::writeHeader().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "collated" )

◆ objectPath()

Foam::fileName objectPath	(	const IOobject &	io,
		const word &	typeName
	)		const

virtual

Reimplemented from fileOperation.

Definition at line 319 of file collatedFileOperation.C.

References IOobject::instance(), masterUncollatedFileOperation::localObjectPath(), word::null, fileOperation::OBJECT, TimePaths::processorCase(), fileOperation::PROCOBJECT, and IOobject::time().

Here is the call graph for this function:

◆ writeObject()

bool writeObject	(	const regIOobject &	io,
		IOstreamOption	streamOpt = `IOstreamOption()`,
		const bool	valid = `true`
	)		const

virtual

Reimplemented from masterUncollatedFileOperation.

Definition at line 349 of file collatedFileOperation.C.

References IOobject::bannerEnabled(), Foam::expressions::patchExpr::debug, dict, Foam::endl(), regIOobject::global(), IOobject::instance(), fileName::isAbsolute(), UPstream::master(), Foam::mkDir(), IOobject::name(), IOobject::objectPath(), os(), UPstream::parRun(), path(), IOobject::path(), Foam::Pout, TimePaths::processorCase(), IOobject::time(), regIOobject::writeData(), IOobject::writeEndDivider(), decomposedBlockData::writeExtraHeaderContent(), and IOobject::writeHeader().

Here is the call graph for this function:

◆ flush()

void flush ( ) const

virtual

Reimplemented from masterUncollatedFileOperation.

Definition at line 512 of file collatedFileOperation.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), masterUncollatedFileOperation::flush(), and Foam::Pout.

Referenced by collatedFileOperation::~collatedFileOperation().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ processorsDir() [1/2]

Foam::word processorsDir ( const IOobject & io ) const

virtual

Reimplemented from fileOperation.

Definition at line 590 of file collatedFileOperation.C.

References IOobject::objectPath().

Here is the call graph for this function:

◆ processorsDir() [2/2]

Foam::word processorsDir ( const fileName & fName ) const

virtual

Reimplemented from fileOperation.

Definition at line 526 of file collatedFileOperation.C.

References Foam::name(), UPstream::nProcs(), UPstream::parRun(), and UPstream::procID().

Here is the call graph for this function:

◆ setNProcs()

void setNProcs ( const label nProcs )

virtual

Reimplemented from fileOperation.

Definition at line 598 of file collatedFileOperation.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), and Foam::Pout.

Here is the call graph for this function:

Member Data Documentation

◆ myComm_

const label myComm_

protected

Definition at line 70 of file collatedFileOperation.H.

Referenced by collatedFileOperation::~collatedFileOperation().

◆ writer_

OFstreamCollator writer_

mutableprotected

Definition at line 73 of file collatedFileOperation.H.

◆ nProcs_

label nProcs_

protected

Definition at line 78 of file collatedFileOperation.H.

◆ ioRanks_

const labelList ioRanks_

protected

Definition at line 81 of file collatedFileOperation.H.

◆ maxThreadFileBufferSize

float maxThreadFileBufferSize

static

Definition at line 113 of file collatedFileOperation.H.

Referenced by collatedFileOperationInitialise::needsThreading().

The documentation for this class was generated from the following files:

src/OpenFOAM/global/fileOperations/collatedFileOperation/collatedFileOperation.H
src/OpenFOAM/global/fileOperations/collatedFileOperation/collatedFileOperation.C

Public Member Functions

Static Public Attributes

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ collatedFileOperation() [1/2]

◆ collatedFileOperation() [2/2]

◆ ~collatedFileOperation()

Member Function Documentation

◆ printBanner()

◆ isMasterRank()

◆ appendObject()

◆ TypeName()

◆ objectPath()

◆ writeObject()

◆ flush()

◆ processorsDir() [1/2]

◆ processorsDir() [2/2]

◆ setNProcs()

Member Data Documentation

◆ myComm_

◆ writer_

◆ nProcs_

◆ ioRanks_

◆ maxThreadFileBufferSize
