Core routines used when reading/writing NASTRAN files. More...

Inheritance diagram for NASCore:

Collaboration diagram for NASCore:

Public Types
enum	fieldFormat { SHORT, LONG, FREE }

enum	loadFormat { PLOAD2, PLOAD4 }

Public Member Functions
	NASCore ()=default

Static Public Member Functions
static scalar	readNasScalar (const std::string &str)

static std::string	nextNasField (const std::string &str, std::string::size_type &pos, std::string::size_type len)

static void	setPrecision (Ostream &os, const fieldFormat format)

static Ostream &	writeKeyword (Ostream &os, const word &keyword, const fieldFormat format)

static label	faceDecomposition (const UList< point > &points, const UList< face > &faces, labelList &decompOffsets, DynamicList< face > &decompFaces)

Static Public Attributes
static const Enum< fieldFormat >	fieldFormatNames

static const Enum< loadFormat >	loadFormatNames

Detailed Description

Core routines used when reading/writing NASTRAN files.

Source files

Definition at line 54 of file NASCore.H.

Member Enumeration Documentation

◆ fieldFormat

enum fieldFormat

Enumerator
SHORT	Short format (field width = 8)
LONG	Long format (field width = 16)
FREE	Free format (comma-separated fields)

Definition at line 59 of file NASCore.H.

◆ loadFormat

enum loadFormat

Enumerator
PLOAD2
PLOAD4

Definition at line 70 of file NASCore.H.

Constructor & Destructor Documentation

◆ NASCore()

NASCore ( )

default

Member Function Documentation

◆ readNasScalar()

Foam::scalar readNasScalar ( const std::string & str )

static

Definition at line 53 of file NASCore.C.

References Foam::parsing::errorNames, Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::parsing::GENERAL, Foam::isspace(), Foam::pow(), and Foam::readInt().

Here is the call graph for this function:

◆ nextNasField()

std::string nextNasField	(	const std::string &	str,
		std::string::size_type &	pos,
		std::string::size_type	len
	)

static

Definition at line 100 of file NASCore.C.

References stdFoam::end(), and Foam::pos().

Here is the call graph for this function:

◆ setPrecision()

void setPrecision	(	Ostream &	os,
		const fieldFormat	format
	)

static

Definition at line 124 of file NASCore.C.

References format(), os(), and Foam::scientific().

Referenced by nastranWriter::write().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ writeKeyword()

Foam::Ostream & writeKeyword	(	Ostream &	os,
		const word &	keyword,
		const fieldFormat	format
	)

static

Definition at line 158 of file NASCore.C.

References format(), os(), and Foam::setw().

Referenced by nastranSetWriter< Type >::write().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ faceDecomposition()

Foam::label faceDecomposition	(	const UList< point > &	points,
		const UList< face > &	faces,
		labelList &	decompOffsets,
		DynamicList< face > &	decompFaces
	)
