FIREMeshWriter Class Reference

Writes polyMesh in AVL/FIRE polyhedra format (fpma, fpmb) More...

Inheritance diagram for FIREMeshWriter:

Collaboration diagram for FIREMeshWriter:

Public Member Functions
	FIREMeshWriter (const polyMesh &, const scalar scaleFactor=1.0)
virtual	~FIREMeshWriter ()=default
virtual bool	write (const fileName &meshName=fileName::null) const
Public Member Functions inherited from meshWriter
	meshWriter (const polyMesh &, const scalar scaling=1.0)
virtual	~meshWriter ()

Static Public Attributes
static bool	binary = false
static bool	compress = false
static bool	prefixBoundary = true
Static Public Attributes inherited from meshWriter
static string	defaultMeshName = "meshExport"

Additional Inherited Members
Public Types inherited from FIRECore
enum	selectionType { cellSelection = 2, faceSelection = 3 }
enum	shapeType {   fireLine = 1, fireTri = 2, fireQuad = 3, fireTet = 4,   fireHex = 5, firePyr = 6, firePrism = 8 }
enum	fileExt3d { POLY_ASCII, POLY_BINARY, POLY_ASCII_Z, POLY_BINARY_Z }
typedef int32_t	fireInt_t
typedef double	fireReal_t
Static Public Member Functions inherited from FIRECore
static fileName	fireFileName (const fileName &baseName, const enum fileExt3d)
static label	getFireLabel (ISstream &)
static point	getFirePoint (ISstream &)
static std::string	getFireString (ISstream &)
static void	putFireLabel (OSstream &, const label)
static void	putFireLabels (OSstream &, const labelUList &)
static void	putFireLabels (OSstream &, const label count, const label start)
static void	putFirePoint (OSstream &, const point &)
static void	putFireString (OSstream &, const std::string &)
Protected Member Functions inherited from FIRECore
	FIRECore ()=default
Static Protected Member Functions inherited from FIRECore
static label	readPoints (ISstream &, pointField &)
Protected Attributes inherited from meshWriter
const polyMesh &	mesh_
scalar	scaleFactor_
boundaryRegion	boundaryRegion_
cellTable	cellTable_
labelList	cellTableId_
Static Protected Attributes inherited from FIRECore
static const Enum< fileExt3d >	file3dExtensions

Detailed Description

Writes polyMesh in AVL/FIRE polyhedra format (fpma, fpmb)

It is also possible to write compressed formats (fpmaz, fpmbz)

Note

The fpma, fpmb formats are relatively poorly documented, but are manageable to read and write. It is, however, not recommended to import them directly into AVL/FIRE (the GUI) since it is generally not robust enough. Instead use their file-convertor to reconvert them into their native format.

In the AVL/FIRE polyhedra format, the faces normals point inwards, whereas the OpenFOAM face normals always point outwards.

Source files

• FIREMeshWriter.H
• FIREMeshWriter.C

Definition at line 62 of file FIREMeshWriter.H.

Constructor & Destructor Documentation

FIREMeshWriter()

FIREMeshWriter	(	const polyMesh &	mesh,
		const scalar	scaleFactor = 1.0
	)

Definition at line 236 of file FIREMeshWriter.C.

~FIREMeshWriter()

virtual ~FIREMeshWriter ( )

virtualdefault

Member Function Documentation

write()

bool write ( const fileName &  meshName = fileName::null ) const

virtual

Implements meshWriter.

Definition at line 247 of file FIREMeshWriter.C.

References IOstreamOption::ASCII, IOstreamOption::BINARY, autoPtr::clear(), IOstreamOption::COMPRESSED, TimePaths::constant(), IOstreamOption::currentVersion, meshWriter::defaultMeshName, Foam::endl(), fileName::ext(), FIRECore::file3dExtensions, FIRECore::fireFileName(), found, autoPtr::good(), Foam::Info, fileName::lessExt(), Foam::mv(), FIRECore::POLY_ASCII, FIRECore::POLY_BINARY, objectRegistry::time(), Time::timeName(), IOstreamOption::UNCOMPRESSED, and writeGeometry().

Here is the call graph for this function:

Member Data Documentation

binary

bool binary = false

static

Definition at line 86 of file FIREMeshWriter.H.

compress

bool compress = false

static

Definition at line 89 of file FIREMeshWriter.H.

prefixBoundary

bool prefixBoundary = true

static

Definition at line 92 of file FIREMeshWriter.H.

---

The documentation for this class was generated from the following files:

• src/conversion/fire/FIREMeshWriter.H
• src/conversion/fire/FIREMeshWriter.C
