ABAQUSsurfaceFormat< Face > Class Template Reference

Abaqus surface reader. More...

Inheritance diagram for ABAQUSsurfaceFormat< Face >:

Collaboration diagram for ABAQUSsurfaceFormat< Face >:

Public Member Functions
	ABAQUSsurfaceFormat ()=default
	ABAQUSsurfaceFormat (const fileName &filename)
virtual	~ABAQUSsurfaceFormat ()=default
virtual bool	read (const fileName &filename)
virtual void	write (const fileName &name, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null) const
Public Member Functions inherited from MeshedSurface< Face >
	MeshedSurface ()
	MeshedSurface (const MeshedSurface &surf)
	MeshedSurface (const UnsortedMeshedSurface< Face > &surf)
	MeshedSurface (MeshedSurface &&surf)
	MeshedSurface (UnsortedMeshedSurface< Face > &&surf)
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const UList< surfZone > &zoneLst)
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const UList< surfZone > &zoneLst)
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const labelUList &zoneSizes=labelUList(), const UList< word > &zoneNames=UList< word >())
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const labelUList &zoneSizes=labelUList(), const UList< word > &zoneNames=UList< word >())
	MeshedSurface (const polyBoundaryMesh &bMesh, const bool globalPoints=false)
	MeshedSurface (const surfMesh &mesh)
	MeshedSurface (const fileName &name)
	MeshedSurface (const fileName &name, const word &fileType)
	MeshedSurface (Istream &is)
	MeshedSurface (const Time &runTime)
	MeshedSurface (const Time &runTime, const word &surfName)
	MeshedSurface (const IOobject &io, const dictionary &dict, const bool isGlobal=true)
	MeshedSurface ()
	MeshedSurface (const MeshedSurface< Face > &surf)
	MeshedSurface (const UnsortedMeshedSurface< Face > &surf)
	MeshedSurface (MeshedSurface< Face > &&surf)
	MeshedSurface (UnsortedMeshedSurface< Face > &&surf)
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const UList< surfZone > &zoneLst)
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const UList< surfZone > &zoneLst)
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const labelUList &zoneSizes, const UList< word > &zoneNames)
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const labelUList &zoneSizes, const UList< word > &zoneNames)
	MeshedSurface (const surfMesh &mesh)
	MeshedSurface (const polyBoundaryMesh &bMesh, const bool useGlobalPoints)
	MeshedSurface (const fileName &name, const word &fileType)
	MeshedSurface (const fileName &name)
	MeshedSurface (Istream &is)
	MeshedSurface (const Time &runTime)
	MeshedSurface (const Time &runTime, const word &surfName)
	MeshedSurface (const IOobject &io, const dictionary &dict, const bool isGlobal)
bool	read (const fileName &name, const word &fileType)
virtual void	write (const fileName &name, const word &fileType, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null) const
void	write (const Time &runTime, const word &surfName=word::null) const
	ClassName ("MeshedSurface")
	declareRunTimeSelectionTable (autoPtr, MeshedSurface, fileExtension,(const fileName &name),(name))
virtual	~MeshedSurface ()
	declareMemberFunctionSelectionTable (void, UnsortedMeshedSurface, write, fileExtension,(const fileName &name, const MeshedSurface< Face > &surf, IOstreamOption streamOpt, const dictionary &options),(name, surf, streamOpt, options))
label	size () const
const List< Face > &	surfFaces () const
const labelList &	faceIds () const
const surfZoneList &	surfZones () const
const vectorField &	Sf () const
const scalarField &	magSf () const
const vectorField &	Cf () const
virtual void	clear ()
virtual void	addZones (const UList< surfZone > &, const bool cullEmpty=false)
virtual void	addZones (const labelUList &sizes, const UList< word > &names, const bool cullEmpty=false)
virtual void	addZones (const labelUList &sizes, const bool cullEmpty=false)
bool	addZonesToFaces ()
bool	addZonesToFaces ()
bool	addZonesToFaces ()
virtual void	removeZones ()
virtual void	movePoints (const pointField &newPoints)
virtual void	scalePoints (const scalar scaleFactor)
virtual void	cleanup (const bool verbose)
virtual void	compactPoints (labelList &pointMap=const_cast< labelList & >(labelList::null()))
virtual bool	stitchFaces (const scalar tol=SMALL, const bool verbose=false)
virtual bool	checkFaces (const bool verbose=false)
virtual label	nTriangles () const
virtual label	nTriangles (labelList &faceMap) const
virtual label	triangulate ()
virtual label	triangulate (labelList &faceMap)
void	subsetMeshMap (const BoolListType &include, labelList &pointMap, labelList &faceMap) const
MeshedSurface	subsetMesh (const UList< bool > &include, labelList &pointMap, labelList &faceMap) const
MeshedSurface	subsetMesh (const bitSet &include, labelList &pointMap, labelList &faceMap) const
MeshedSurface	subsetMesh (const UList< bool > &include) const
MeshedSurface	subsetMesh (const bitSet &include) const
MeshedSurface	subsetMesh (const wordRes &includeNames, const wordRes &excludeNames=wordRes()) const
void	swap (MeshedSurface< Face > &surf)
void	transfer (pointField &pointLst, List< Face > &faceLst)
void	transfer (MeshedSurface< Face > &surf)
void	transfer (UnsortedMeshedSurface< Face > &surf)
autoPtr< MeshedSurface< Face > >	releaseGeom ()
void	swapFaces (List< Face > &faces)
void	swapPoints (pointField &points)
void	writeStats (Ostream &os) const
void	operator= (const MeshedSurface< Face > &surf)
void	operator= (MeshedSurface< Face > &&surf)
	operator MeshedSurfaceProxy< Face > () const

Static Public Member Functions
static void	write (const fileName &filename, const MeshedSurfaceProxy< Face > &surf, IOstreamOption streamOpt=IOstreamOption(), const dictionary &=dictionary::null)
Static Public Member Functions inherited from MeshedSurface< Face >
static void	write (const fileName &name, const MeshedSurface< Face > &surf, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null)
static void	write (const fileName &name, const word &fileType, const MeshedSurface< Face > &surf, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null)
static wordHashSet	readTypes ()
static wordHashSet	writeTypes ()
static bool	canReadType (const word &fileType, bool verbose=false)
static bool	canWriteType (const word &fileType, bool verbose=false)
static bool	canRead (const fileName &name, bool verbose=false)
static autoPtr< MeshedSurface >	New (const fileName &name, const word &fileType, bool mandatory=true)
static autoPtr< MeshedSurface >	New (const fileName &name)
Static Public Member Functions inherited from ABAQUSCore
static shapeType	getElementType (const std::string &elemTypeName)
static int	nPoints (shapeType tag)
static bool	isValidType (shapeType tag)
static bool	isShellType (shapeType tag)
static bool	isSolidType (shapeType tag)
static bool	isEncodedSolidId (const label combinedId)
static label	encodeSolidId (const label id, const label side)
static label	decodeSolidElementId (const label combinedId)
static label	decodeSolidSideNum (const label combinedId)
static void	writePoints (Ostream &os, const UList< point > &points, const scalar scaleFactor=1.0)
static label	faceDecomposition (const UList< point > &points, const UList< face > &faces, labelList &decompOffsets, DynamicList< face > &decompFaces)

Additional Inherited Members
Public Types inherited from MeshedSurface< Face >
typedef Face	face_type
typedef point	point_type
Public Types inherited from ABAQUSCore
enum	shapeType : uint8_t {   abaqusUnknownShape = 0, abaqusTria = 0x03, abaqusQuad = 0x04, abaqusTet = 0x84,   abaqusPyr = 0x85, abaqusPrism = 0x86, abaqusHex = 0x88 }
Protected Member Functions inherited from MeshedSurface< Face >
void	transcribe (MeshedSurface< face > &surf)
void	transcribe (MeshedSurface< face > &surf)
void	transcribe (MeshedSurface< face > &surf)
void	transcribe (MeshedSurface< face > &surf)
void	checkZones (const bool verbose=true)
pointField &	storedPoints ()
List< Face > &	storedFaces ()
labelList &	storedFaceIds ()
surfZoneList &	storedZones ()
void	sortFacesAndStore (DynamicList< Face > &unsortedFaces, DynamicList< label > &zoneIds, DynamicList< label > &elemIds, bool sorted)
virtual void	remapFaces (const labelUList &faceMapNewToOld)
Protected Member Functions inherited from ABAQUSCore
	ABAQUSCore ()=default
Static Protected Member Functions inherited from ABAQUSCore
static void	renumber0_elemId (label &elemId)
static const Map< labelList > &	abaqusToFoamFaceAddr ()

Detailed Description

template<class Face>
class Foam::fileFormats::ABAQUSsurfaceFormat< Face >

Abaqus surface reader.

Output stream options:

• ASCII only
• compression on/off

Output dictionary options: ignored

Source files

• ABAQUSsurfaceFormat.H
• ABAQUSsurfaceFormat.C

Definition at line 58 of file ABAQUSsurfaceFormat.H.

Constructor & Destructor Documentation

ABAQUSsurfaceFormat() [1/2]

ABAQUSsurfaceFormat ( )

default

ABAQUSsurfaceFormat() [2/2]

ABAQUSsurfaceFormat ( const fileName &  filename )

explicit

Definition at line 108 of file ABAQUSsurfaceFormat.C.

References Foam::blockMeshTools::read().

Here is the call graph for this function:

~ABAQUSsurfaceFormat()

virtual ~ABAQUSsurfaceFormat ( )

virtualdefault

Member Function Documentation

write() [1/2]

void write ( const fileName &  filename, const MeshedSurfaceProxy< Face > &  surf, IOstreamOption  streamOpt = IOstreamOption(), const dictionary &  = dictionary::null  )

static

Definition at line 238 of file ABAQUSsurfaceFormat.C.

References Foam::exit(), f(), MeshedSurfaceProxy::faceIds(), Foam::faceMap(), MeshedSurfaceProxy::faceMap(), Foam::FatalError, FatalErrorInFunction, IOstreamOption::format(), found, n, zoneIdentifier::name(), Foam::nl, os(), MeshedSurfaceProxy::points(), Pair::second(), UList::size(), MeshedSurfaceProxy::surfFaces(), MeshedSurfaceProxy::surfZones(), and MeshedSurfaceProxy::useFaceMap().

Referenced by ABAQUSsurfaceFormat< Face >::write().

Here is the call graph for this function:

Here is the caller graph for this function:

read()

bool read ( const fileName &  filename )

virtual

Reimplemented from MeshedSurface< Face >.

Definition at line 120 of file ABAQUSsurfaceFormat.C.

References DynamicList::append(), clear(), ABAQUSCore::readHelper::compact_nodes(), ABAQUSCore::readHelper::connectivity_, ABAQUSCore::readHelper::elemIds_, ABAQUSCore::readHelper::elsetIds_, ABAQUSCore::readHelper::elsetMap_, Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, forAllConstIters(), IOstream::good(), Foam::nl, ABAQUSCore::readHelper::points_, ABAQUSCore::readHelper::purge_solids(), ABAQUSCore::readHelper::read(), ABAQUSCore::readHelper::renumber_elements_1to0(), List::resize(), List::transfer(), Foam::stringOps::validate(), and Foam::Zero.

Here is the call graph for this function:

write() [2/2]

virtual void write ( const fileName &  name, IOstreamOption  streamOpt = IOstreamOption(), const dictionary &  options = dictionary::null  ) const

inlinevirtual

Reimplemented from MeshedSurface< Face >.

Definition at line 113 of file ABAQUSsurfaceFormat.H.

References Foam::name(), and ABAQUSsurfaceFormat< Face >::write().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/surfMesh/surfaceFormats/abaqus/ABAQUSsurfaceFormat.H
• src/surfMesh/surfaceFormats/abaqus/ABAQUSsurfaceFormat.C
