ABAQUSCore Class Reference

Core routines used when reading/writing ABAQUS files. More...

Inheritance diagram for ABAQUSCore:

Classes
struct	readHelper

Public Types
enum	shapeType : uint8_t {   abaqusUnknownShape = 0, abaqusTria = 0x03, abaqusQuad = 0x04, abaqusTet = 0x84,   abaqusPyr = 0x85, abaqusPrism = 0x86, abaqusHex = 0x88 }

Static Public Member Functions
static shapeType	getElementType (const std::string &elemTypeName)
static int	nPoints (shapeType tag)
static bool	isValidType (shapeType tag)
static bool	isShellType (shapeType tag)
static bool	isSolidType (shapeType tag)
static bool	isEncodedSolidId (const label combinedId)
static label	encodeSolidId (const label id, const label side)
static label	decodeSolidElementId (const label combinedId)
static label	decodeSolidSideNum (const label combinedId)
static void	writePoints (Ostream &os, const UList< point > &points, const scalar scaleFactor=1.0)
static label	faceDecomposition (const UList< point > &points, const UList< face > &faces, labelList &decompOffsets, DynamicList< face > &decompFaces)

Protected Member Functions
	ABAQUSCore ()=default

Static Protected Member Functions
static void	renumber0_elemId (label &elemId)
static const Map< labelList > &	abaqusToFoamFaceAddr ()

Detailed Description

Core routines used when reading/writing ABAQUS files.

Face mappings for abaqus deduced from libmesh internals

Tet4 cells

Face	OpenFOAM	libmesh	abaqus	starcd
(1 2 3)	0	2	2	5
(0 3 2)	1	3	3	4
(0 1 3)	2	1	1	2
(0 2 1)	3	0	0	0

Pyr5 cells

Face	OpenFOAM	libmesh	abaqus	starcd
(0 3 2 1)	0	4	n/a	0
(0 4 3)	1	3	n/a	4
(3 4 2)	2	2	n/a	3
(1 2 4)	3	1	n/a	5
(0 1 4)	4	0	n/a	2

Prism6 cells

Face	OpenFOAM	libmesh	abaqus	starcd
(0 2 1)	0	0	0	0
(3 4 5)	1	4	1	1
(0 3 5 2)	2	3	4	4
(1 2 5 4)	3	2	3	5
(0 1 4 3)	4	1	2	2

Hex8 cells

Face	OpenFOAM	libmesh	abaqus	starcd
(0 4 7 3)	0	4	5	4
(1 2 6 5)	1	2	3	5
(0 1 5 4)	2	1	2	2
(3 7 6 2)	3	3	4	3
(0 3 2 1)	4	0	0	0
(4 5 6 7)	5	5	1	1

Source files

• ABAQUSCore.H
• ABAQUSCore.C

Definition at line 239 of file ABAQUSCore.H.

Member Enumeration Documentation

shapeType

enum shapeType : uint8_t

Enumerator
abaqusUnknownShape
abaqusTria
abaqusQuad
abaqusTet
abaqusPyr
abaqusPrism
abaqusHex

Definition at line 246 of file ABAQUSCore.H.

Constructor & Destructor Documentation

ABAQUSCore()

ABAQUSCore ( )

protecteddefault

Member Function Documentation

getElementType()

Foam::fileFormats::ABAQUSCore::shapeType getElementType ( const std::string &  elemTypeName )

static

Definition at line 197 of file ABAQUSCore.C.

References checkElemType.

nPoints()

static int nPoints ( shapeType  tag )

inlinestatic

Definition at line 266 of file ABAQUSCore.H.

Referenced by ABAQUSCore::readHelper::read(), and ABAQUSCore::readHelper::readElements().

Here is the caller graph for this function:

isValidType()

static bool isValidType ( shapeType  tag )

inlinestatic

Definition at line 272 of file ABAQUSCore.H.

isShellType()

static bool isShellType ( shapeType  tag )

inlinestatic

Definition at line 278 of file ABAQUSCore.H.

isSolidType()

static bool isSolidType ( shapeType  tag )

inlinestatic

Definition at line 284 of file ABAQUSCore.H.

isEncodedSolidId()

static bool isEncodedSolidId ( const label  combinedId )

inlinestatic

Definition at line 290 of file ABAQUSCore.H.

Referenced by ABAQUSCore::decodeSolidElementId(), ABAQUSCore::decodeSolidSideNum(), and ABAQUSCore::renumber0_elemId().

Here is the caller graph for this function:

encodeSolidId()

static label encodeSolidId ( const label  id, const label  side  )

inlinestatic

Definition at line 296 of file ABAQUSCore.H.

Referenced by ABAQUSCore::readHelper::readSurfaceElements().

Here is the caller graph for this function:

decodeSolidElementId()

static label decodeSolidElementId ( const label  combinedId )

inlinestatic

Definition at line 302 of file ABAQUSCore.H.

References ABAQUSCore::isEncodedSolidId().

Here is the call graph for this function:

decodeSolidSideNum()

static label decodeSolidSideNum ( const label  combinedId )

inlinestatic

Definition at line 314 of file ABAQUSCore.H.

References ABAQUSCore::isEncodedSolidId().

Here is the call graph for this function:

renumber0_elemId()

static void renumber0_elemId ( label &  elemId )

inlinestaticprotected

Definition at line 330 of file ABAQUSCore.H.

References ABAQUSCore::isEncodedSolidId().

Here is the call graph for this function:

abaqusToFoamFaceAddr()

const Foam::Map< Foam::labelList > & abaqusToFoamFaceAddr ( )

staticprotected

Definition at line 183 of file ABAQUSCore.C.

References ABAQUSCore::abaqusHex, ABAQUSCore::abaqusPrism, ABAQUSCore::abaqusTet, and abaqusToFoamFaceAddr_.

writePoints()

void writePoints ( Ostream &  os, const UList< point > &  points, const scalar  scaleFactor = 1.0  )

static

Definition at line 781 of file ABAQUSCore.C.

References Foam::nl, os(), p, and points.

Here is the call graph for this function:

faceDecomposition()

Foam::label faceDecomposition ( const UList< point > &  points, const UList< face > &  faces, labelList &  decompOffsets, DynamicList< face > &  decompFaces  )

static

Definition at line 816 of file ABAQUSCore.C.

References DynamicList::clear(), f(), n, points, List::resize(), and UList::size().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/fileFormats/abaqus/ABAQUSCore.H
• src/fileFormats/abaqus/ABAQUSCore.C
