faceSelection Class Reference

Face selection method for createBaffles. More...

Inheritance diagram for faceSelection:

Collaboration diagram for faceSelection:

Public Member Functions
	TypeName ("faceSelection")
	declareRunTimeSelectionTable (autoPtr, faceSelection, dictionary,(const word &name, const fvMesh &mesh, const dictionary &dict),(name, mesh, dict))
	faceSelection (const word &name, const fvMesh &mesh, const dictionary &dict)
autoPtr< faceSelection >	clone () const
virtual	~faceSelection ()
const word &	name () const
const dictionary &	dict () const
virtual void	select (const label, labelList &, boolList &) const =0

Static Public Member Functions
static autoPtr< faceSelection >	New (const word &name, const fvMesh &mesh, const dictionary &dict)

Protected Attributes
const word	name_
const fvMesh &	mesh_
const dictionary	dict_
const bool	flip_

Detailed Description

Face selection method for createBaffles.

Source files

• faceSelection.H
• faceSelection.C

Definition at line 54 of file faceSelection.H.

Constructor & Destructor Documentation

faceSelection()

faceSelection	(	const word &	name,
		const fvMesh &	mesh,
		const dictionary &	dict
	)

~faceSelection()

virtual ~faceSelection ( )

virtual

Member Function Documentation

TypeName()

TypeName

(

"faceSelection"

)

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		faceSelection	,
		dictionary	,
		(const word &name, const fvMesh &mesh, const dictionary &dict)	,
		(name, mesh, dict)
	)

clone()

autoPtr<faceSelection> clone ( ) const

inline

Definition at line 105 of file faceSelection.H.

References NotImplemented.

New()

static autoPtr<faceSelection> New ( const word &  name, const fvMesh &  mesh, const dictionary &  dict  )

static

name()

const word& name ( ) const

inline

Definition at line 129 of file faceSelection.H.

References faceSelection::name_.

dict()

const dictionary& dict ( ) const

inline

Definition at line 134 of file faceSelection.H.

References faceSelection::dict_.

select()

virtual void select ( const  label, labelList &  , boolList &    ) const

pure virtual

Implemented in faceZoneSelection, and searchableSurfaceSelection.

Member Data Documentation

name_

const word name_

protected

Definition at line 61 of file faceSelection.H.

Referenced by faceSelection::name().

mesh_

const fvMesh& mesh_

protected

Definition at line 64 of file faceSelection.H.

dict_

const dictionary dict_

protected

Definition at line 67 of file faceSelection.H.

Referenced by faceSelection::dict().

flip_

const bool flip_

protected

Definition at line 70 of file faceSelection.H.

---

The documentation for this class was generated from the following file:

• applications/utilities/mesh/manipulation/createBaffles/faceSelection/faceSelection.H
