faceCollapser Class Reference

Collapses faces into edges. Used to remove sliver faces (faces with small area but non-zero span). More...

Public Member Functions
	ClassName ("faceCollapser")
	faceCollapser (const polyMesh &mesh)
void	setRefinement (const labelList &faceLabels, const labelList &fpA, const labelList &fpB, polyTopoChange &) const
void	updateMesh (const mapPolyMesh &)

Detailed Description

Collapses faces into edges. Used to remove sliver faces (faces with small area but non-zero span).

Passed in as

• face label
• the two indices in the face (fpA, fpB) which delimit the vertices to be kept.

Takes the vertices outside the range fpA..fpB and projects them onto the kept edges (edges using kept vertices only).

Note:

• Use in combination with edge collapse to cleanup meshes.
• Can not remove cells so will mess up trying to remove a face on a tet.
• WIP. Should be combined with edge collapsing and cell collapsing into proper 'collapser'.
• Caller is responsible for making sure kept vertices (fpA..fpB) for one face are not the vertices to be removed for another face.

Source files

• faceCollapser.H
• faceCollapser.C

Definition at line 74 of file faceCollapser.H.

Constructor & Destructor Documentation

faceCollapser()

faceCollapser ( const polyMesh &  mesh )

explicit

Definition at line 196 of file faceCollapser.C.

Member Function Documentation

ClassName()

ClassName

(

"faceCollapser"

)

setRefinement()

void setRefinement	(	const labelList &	faceLabels,
		const labelList &	fpA,
		const labelList &	fpB,
		polyTopoChange &	meshMod
	)		const

Definition at line 205 of file faceCollapser.C.

References Foam::abort(), DynamicList::append(), Foam::constant::electromagnetic::e, Foam::endl(), f(), Foam::FatalError, FatalErrorInFunction, Foam::meshTools::findEdge(), forAll, forAllConstIters(), SortableList::indices(), insert(), Foam::magSqr(), line::nearestDist(), Foam::nl, points, Foam::Pout, PointHit< PointType >::rawPoint(), Foam::reverse(), polyTopoChange::setAction(), PointHit< PointType >::setPoint(), DynamicList::shrink(), SortableList::sort(), Foam::sqrt(), and Foam::meshTools::writeOBJ().

Here is the call graph for this function:

updateMesh()

void updateMesh ( const mapPolyMesh &  )

inline

Definition at line 147 of file faceCollapser.H.

---

The documentation for this class was generated from the following files:

• src/dynamicMesh/polyTopoChange/polyTopoChange/faceCollapser.H
• src/dynamicMesh/polyTopoChange/polyTopoChange/faceCollapser.C
