Central-difference lnGrad scheme with limited non-orthogonal correction. More...

Inheritance diagram for limitedLnGrad< Type >:

Collaboration diagram for limitedLnGrad< Type >:

Public Member Functions
	TypeName ("limited")

	limitedLnGrad (const faMesh &mesh)

	limitedLnGrad (const faMesh &mesh, Istream &is)

virtual	~limitedLnGrad ()

virtual tmp< edgeScalarField >	deltaCoeffs (const GeometricField< Type, faPatchField, areaMesh > &) const

virtual bool	corrected () const

virtual tmp< GeometricField< Type, faePatchField, edgeMesh > >	correction (const GeometricField< Type, faPatchField, areaMesh > &) const

Public Member Functions inherited from lnGradScheme< Type >
	declareRunTimeSelectionTable (tmp, lnGradScheme, Mesh,(const faMesh &mesh, Istream &schemeData),(mesh, schemeData))

	lnGradScheme (const faMesh &mesh)

virtual	~lnGradScheme ()

const faMesh &	mesh () const

virtual tmp< GeometricField< Type, faePatchField, edgeMesh > >	lnGrad (const GeometricField< Type, faPatchField, areaMesh > &) const

tmp< GeometricField< Type, faePatchField, edgeMesh > >	lnGrad (const tmp< GeometricField< Type, faPatchField, areaMesh >> &) const

Public Member Functions inherited from refCount
constexpr	refCount () noexcept

int	count () const noexcept

bool	unique () const noexcept

void	operator++ () noexcept

void	operator++ (int) noexcept

void	operator-- () noexcept

void	operator-- (int) noexcept

Additional Inherited Members
Static Public Member Functions inherited from lnGradScheme< Type >
static tmp< lnGradScheme< Type > >	New (const faMesh &mesh, Istream &schemeData)

static tmp< GeometricField< Type, faePatchField, edgeMesh > >	lnGrad (const GeometricField< Type, faPatchField, areaMesh > &, const tmp< edgeScalarField > &, const word &snGradName="lnGrad")

Detailed Description

template<class Type>
class Foam::fa::limitedLnGrad< Type >

Central-difference lnGrad scheme with limited non-orthogonal correction.

The limiter is controlled by a coefficient with a value between 0 and 1 which when 0 switches the correction off and the scheme behaves as uncorrectedSnGrad, when set to 1 the full correction is applied and the scheme behaves as correctedSnGrad and when set to 0.5 the limiter is calculated such that the non-orthogonal contribution does not exceed the orthogonal part.

Author Hrvoje Jasak, Wikki Ltd.

Source files

Definition at line 62 of file limitedLnGrad.H.
