laplacianScheme< Type > Class Template Reference

Abstract base class for finite area calculus laplacian schemes. More...

Inheritance diagram for laplacianScheme< Type >:

Collaboration diagram for laplacianScheme< Type >:

Public Member Functions
	declareRunTimeSelectionTable (tmp, laplacianScheme, Istream,(const faMesh &mesh, Istream &schemeData),(mesh, schemeData))
	laplacianScheme (const faMesh &mesh)
	laplacianScheme (const faMesh &mesh, Istream &is)
virtual	~laplacianScheme ()
const faMesh &	mesh () const
virtual tmp< faMatrix< Type > >	famLaplacian (const edgeScalarField &, const GeometricField< Type, faPatchField, areaMesh > &)=0
virtual tmp< faMatrix< Type > >	famLaplacian (const areaScalarField &, const GeometricField< Type, faPatchField, areaMesh > &)
virtual tmp< GeometricField< Type, faPatchField, areaMesh > >	facLaplacian (const GeometricField< Type, faPatchField, areaMesh > &)=0
virtual tmp< GeometricField< Type, faPatchField, areaMesh > >	facLaplacian (const edgeScalarField &, const GeometricField< Type, faPatchField, areaMesh > &)=0
virtual tmp< GeometricField< Type, faPatchField, areaMesh > >	facLaplacian (const areaScalarField &, const GeometricField< Type, faPatchField, areaMesh > &)
Public Member Functions inherited from refCount
constexpr	refCount () noexcept
int	count () const noexcept
bool	unique () const noexcept
void	operator++ () noexcept
void	operator++ (int) noexcept
void	operator-- () noexcept
void	operator-- (int) noexcept

Static Public Member Functions
static tmp< laplacianScheme< Type > >	New (const faMesh &mesh, Istream &schemeData)

Protected Member Functions
	laplacianScheme (const laplacianScheme &)=delete
void	operator= (const laplacianScheme &)=delete

Protected Attributes
const faMesh &	mesh_
tmp< edgeInterpolationScheme< scalar > >	tinterpGammaScheme_
tmp< lnGradScheme< Type > >	tlnGradScheme_

Detailed Description

template<class Type>
class Foam::fa::laplacianScheme< Type >

Abstract base class for finite area calculus laplacian schemes.

Source files

• faLaplacianScheme.H
• faLaplacianScheme.C
• faLaplacianSchemes.C

Definition at line 64 of file faLaplacianScheme.H.

Constructor & Destructor Documentation

laplacianScheme() [1/3]

laplacianScheme ( const laplacianScheme< Type > &  )

protecteddelete

laplacianScheme() [2/3]

laplacianScheme ( const faMesh &  mesh )

inline

Definition at line 104 of file faLaplacianScheme.H.

laplacianScheme() [3/3]

laplacianScheme ( const faMesh &  mesh, Istream &  is  )

inline

Definition at line 112 of file faLaplacianScheme.H.

References IOstream::eof(), laplacianScheme< Type >::mesh(), lnGradScheme< Type >::New(), edgeInterpolationScheme< Type >::New(), laplacianScheme< Type >::tinterpGammaScheme_, and laplacianScheme< Type >::tlnGradScheme_.

Here is the call graph for this function:

~laplacianScheme()

~laplacianScheme

virtual

Definition at line 83 of file faLaplacianScheme.C.

Member Function Documentation

operator=()

void operator= ( const laplacianScheme< Type > &  )

protecteddelete

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	tmp	,
		laplacianScheme< Type >	,
		Istream	,
		(const faMesh &mesh, Istream &schemeData)	,
		(mesh, schemeData)
	)

New()

tmp< laplacianScheme< Type > > New ( const faMesh &  mesh, Istream &  schemeData  )

static

Definition at line 40 of file faLaplacianScheme.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), IOstream::eof(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, FatalIOErrorInLookup, InfoInFunction, mesh, and Foam::nl.

Referenced by Foam::fac::laplacian(), and Foam::fam::laplacian().

Here is the call graph for this function:

Here is the caller graph for this function:

mesh()

const faMesh& mesh ( ) const

inline

Definition at line 162 of file faLaplacianScheme.H.

References laplacianScheme< Type >::mesh_.

Referenced by laplacianScheme< Type >::laplacianScheme().

Here is the caller graph for this function:

famLaplacian() [1/2]

virtual tmp<faMatrix<Type> > famLaplacian ( const edgeScalarField &  , const GeometricField< Type, faPatchField, areaMesh > &    )

pure virtual

Implemented in gaussLaplacianScheme< Type >.

famLaplacian() [2/2]

tmp< faMatrix< Type > > famLaplacian ( const areaScalarField &  gamma, const GeometricField< Type, faPatchField, areaMesh > &  vf  )

virtual

Definition at line 92 of file faLaplacianScheme.C.

References gamma, and Foam::interpolate().

Here is the call graph for this function:

facLaplacian() [1/3]

virtual tmp<GeometricField<Type, faPatchField, areaMesh> > facLaplacian ( const GeometricField< Type, faPatchField, areaMesh > &  )

pure virtual

Implemented in gaussLaplacianScheme< Type >.

facLaplacian() [2/3]

virtual tmp<GeometricField<Type, faPatchField, areaMesh> > facLaplacian ( const edgeScalarField &  , const GeometricField< Type, faPatchField, areaMesh > &    )

pure virtual

Implemented in gaussLaplacianScheme< Type >.

facLaplacian() [3/3]

tmp< GeometricField< Type, faPatchField, areaMesh > > facLaplacian ( const areaScalarField &  gamma, const GeometricField< Type, faPatchField, areaMesh > &  vf  )

virtual

Definition at line 104 of file faLaplacianScheme.C.

References gamma, and Foam::interpolate().

Here is the call graph for this function:

Member Data Documentation

mesh_

const faMesh& mesh_

protected

Definition at line 73 of file faLaplacianScheme.H.

Referenced by laplacianScheme< Type >::mesh().

tinterpGammaScheme_

tmp<edgeInterpolationScheme<scalar> > tinterpGammaScheme_

protected

Definition at line 74 of file faLaplacianScheme.H.

Referenced by laplacianScheme< Type >::laplacianScheme().

tlnGradScheme_

tmp<lnGradScheme<Type> > tlnGradScheme_

protected

Definition at line 75 of file faLaplacianScheme.H.

Referenced by laplacianScheme< Type >::laplacianScheme().

---

The documentation for this class was generated from the following files:

• src/finiteArea/finiteArea/laplacianSchemes/faLaplacianScheme/faLaplacianScheme.H
• src/finiteArea/finiteArea/laplacianSchemes/faLaplacianScheme/faLaplacianScheme.C
