gaussLaplacianScheme< Type > Class Template Reference

Basic second-order laplacian using face-gradients and Gauss' theorem. More...

Inheritance diagram for gaussLaplacianScheme< Type >:

Collaboration diagram for gaussLaplacianScheme< Type >:

Public Member Functions
	TypeName ("Gauss")
	gaussLaplacianScheme (const faMesh &mesh)
	gaussLaplacianScheme (const faMesh &mesh, Istream &is)
tmp< faMatrix< Type > >	famLaplacian (const edgeScalarField &, const GeometricField< Type, faPatchField, areaMesh > &)
tmp< GeometricField< Type, faPatchField, areaMesh > >	facLaplacian (const GeometricField< Type, faPatchField, areaMesh > &)
tmp< GeometricField< Type, faPatchField, areaMesh > >	facLaplacian (const edgeScalarField &, const GeometricField< Type, faPatchField, areaMesh > &)
Public Member Functions inherited from laplacianScheme< Type >
	declareRunTimeSelectionTable (tmp, laplacianScheme, Istream,(const faMesh &mesh, Istream &schemeData),(mesh, schemeData))
	laplacianScheme (const faMesh &mesh)
	laplacianScheme (const faMesh &mesh, Istream &is)
virtual	~laplacianScheme ()
const faMesh &	mesh () const
virtual tmp< faMatrix< Type > >	famLaplacian (const areaScalarField &, const GeometricField< Type, faPatchField, areaMesh > &)
virtual tmp< GeometricField< Type, faPatchField, areaMesh > >	facLaplacian (const areaScalarField &, const GeometricField< Type, faPatchField, areaMesh > &)
Public Member Functions inherited from refCount
constexpr	refCount () noexcept
int	count () const noexcept
bool	unique () const noexcept
void	operator++ () noexcept
void	operator++ (int) noexcept
void	operator-- () noexcept
void	operator-- (int) noexcept

Additional Inherited Members
Static Public Member Functions inherited from laplacianScheme< Type >
static tmp< laplacianScheme< Type > >	New (const faMesh &mesh, Istream &schemeData)
Protected Member Functions inherited from laplacianScheme< Type >
	laplacianScheme (const laplacianScheme &)=delete
void	operator= (const laplacianScheme &)=delete
Protected Attributes inherited from laplacianScheme< Type >
const faMesh &	mesh_
tmp< edgeInterpolationScheme< scalar > >	tinterpGammaScheme_
tmp< lnGradScheme< Type > >	tlnGradScheme_

Detailed Description

template<class Type>
class Foam::fa::gaussLaplacianScheme< Type >

Basic second-order laplacian using face-gradients and Gauss' theorem.

Source files

• gaussFaLaplacianScheme.H
• gaussFaLaplacianScheme.C
• gaussFaLaplacianSchemes.C

Definition at line 53 of file gaussFaLaplacianScheme.H.

Constructor & Destructor Documentation

gaussLaplacianScheme() [1/2]

gaussLaplacianScheme ( const faMesh &  mesh )

inline

Definition at line 75 of file gaussFaLaplacianScheme.H.

gaussLaplacianScheme() [2/2]

gaussLaplacianScheme ( const faMesh &  mesh, Istream &  is  )

inline

Definition at line 81 of file gaussFaLaplacianScheme.H.

Member Function Documentation

TypeName()

TypeName

(

"Gauss"

)

famLaplacian()

tmp< faMatrix< Type > > famLaplacian ( const edgeScalarField &  gamma, const GeometricField< Type, faPatchField, areaMesh > &  vf  )

virtual

Implements laplacianScheme< Type >.

Definition at line 40 of file gaussFaLaplacianScheme.C.

References GeometricField::boundaryField(), Foam::correction(), Foam::fac::div(), faMatrix::faceFluxCorrectionPtr(), forAll, gamma, faPatchField::gradientBoundaryCoeffs(), faPatchField::gradientInternalCoeffs(), GeometricField::internalField(), mesh, and tmp::ref().

Here is the call graph for this function:

facLaplacian() [1/2]

tmp< GeometricField< Type, faPatchField, areaMesh > > facLaplacian ( const GeometricField< Type, faPatchField, areaMesh > &  vf )

virtual

Implements laplacianScheme< Type >.

Definition at line 109 of file gaussFaLaplacianScheme.C.

References Foam::fac::div(), Foam::fac::lnGrad(), and tmp::ref().

Here is the call graph for this function:

facLaplacian() [2/2]

tmp< GeometricField< Type, faPatchField, areaMesh > > facLaplacian ( const edgeScalarField &  gamma, const GeometricField< Type, faPatchField, areaMesh > &  vf  )

virtual

Implements laplacianScheme< Type >.

Definition at line 127 of file gaussFaLaplacianScheme.C.

References Foam::fac::div(), gamma, Foam::fac::lnGrad(), and tmp::ref().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteArea/finiteArea/laplacianSchemes/gaussFaLaplacianScheme/gaussFaLaplacianScheme.H
• src/finiteArea/finiteArea/laplacianSchemes/gaussFaLaplacianScheme/gaussFaLaplacianScheme.C
