gaussConvectionScheme< Type > Class Template Reference

Basic second-order convection using face-gradients and Gauss' theorem. More...

Inheritance diagram for gaussConvectionScheme< Type >:

Collaboration diagram for gaussConvectionScheme< Type >:

Public Member Functions
	TypeName ("Gauss")
	gaussConvectionScheme (const faMesh &mesh, const edgeScalarField &faceFlux, const tmp< edgeInterpolationScheme< Type >> &scheme)
	gaussConvectionScheme (const faMesh &mesh, const edgeScalarField &faceFlux, Istream &is)
tmp< GeometricField< Type, faePatchField, edgeMesh > >	flux (const edgeScalarField &, const GeometricField< Type, faPatchField, areaMesh > &) const
tmp< faMatrix< Type > >	famDiv (const edgeScalarField &, const GeometricField< Type, faPatchField, areaMesh > &) const
tmp< GeometricField< Type, faPatchField, areaMesh > >	facDiv (const edgeScalarField &, const GeometricField< Type, faPatchField, areaMesh > &) const
Public Member Functions inherited from convectionScheme< Type >
	declareRunTimeSelectionTable (tmp, convectionScheme, Istream,(const faMesh &mesh, const edgeScalarField &faceFlux, Istream &schemeData),(mesh, faceFlux, schemeData))
	convectionScheme (const faMesh &mesh, const edgeScalarField &faceFlux)
virtual	~convectionScheme ()
const faMesh &	mesh () const
Public Member Functions inherited from refCount
constexpr	refCount () noexcept
int	count () const noexcept
bool	unique () const noexcept
void	operator++ () noexcept
void	operator++ (int) noexcept
void	operator-- () noexcept
void	operator-- (int) noexcept

Additional Inherited Members
Static Public Member Functions inherited from convectionScheme< Type >
static tmp< convectionScheme< Type > >	New (const faMesh &mesh, const edgeScalarField &faceFlux, Istream &schemeData)

Detailed Description

template<class Type>
class Foam::fa::gaussConvectionScheme< Type >

Basic second-order convection using face-gradients and Gauss' theorem.

Source files

• gaussFaConvectionScheme.H
• gaussFaConvectionScheme.C
• gaussFaConvectionSchemes.C

Definition at line 54 of file gaussFaConvectionScheme.H.

Constructor & Destructor Documentation

gaussConvectionScheme() [1/2]

gaussConvectionScheme ( const faMesh &  mesh, const edgeScalarField &  faceFlux, const tmp< edgeInterpolationScheme< Type >> &  scheme  )

inline

Definition at line 82 of file gaussFaConvectionScheme.H.

gaussConvectionScheme() [2/2]

gaussConvectionScheme ( const faMesh &  mesh, const edgeScalarField &  faceFlux, Istream &  is  )

inline

Definition at line 94 of file gaussFaConvectionScheme.H.

Member Function Documentation

TypeName()

TypeName

(

"Gauss"

)

flux()

tmp< GeometricField< Type, faePatchField, edgeMesh > > flux ( const edgeScalarField &  faceFlux, const GeometricField< Type, faPatchField, areaMesh > &  vf  ) const

virtual

Implements convectionScheme< Type >.

Definition at line 40 of file gaussFaConvectionScheme.C.

famDiv()

tmp< faMatrix< Type > > famDiv ( const edgeScalarField &  faceFlux, const GeometricField< Type, faPatchField, areaMesh > &  vf  ) const

virtual

Implements convectionScheme< Type >.

Definition at line 52 of file gaussFaConvectionScheme.C.

References GeometricField::boundaryField(), Foam::fac::edgeIntegrate(), Foam::fvc::flux(), forAll, GeometricField::internalField(), tmp::ref(), faPatchField::valueBoundaryCoeffs(), and faPatchField::valueInternalCoeffs().

Here is the call graph for this function:

facDiv()

tmp< GeometricField< Type, faPatchField, areaMesh > > facDiv ( const edgeScalarField &  faceFlux, const GeometricField< Type, faPatchField, areaMesh > &  vf  ) const

virtual

Implements convectionScheme< Type >.

Definition at line 105 of file gaussFaConvectionScheme.C.

References Foam::fac::edgeIntegrate(), Foam::fvc::flux(), and tmp::ref().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteArea/finiteArea/convectionSchemes/gaussFaConvectionScheme/gaussFaConvectionScheme.H
• src/finiteArea/finiteArea/convectionSchemes/gaussFaConvectionScheme/gaussFaConvectionScheme.C
