faceSetOption Class Reference

Intermediate abstract class for handling face-set options for the derived faOptions. More...

Inheritance diagram for faceSetOption:
Inheritance graph
[legend]
Collaboration diagram for faceSetOption:
Collaboration graph
[legend]

Public Types

enum  selectionModeType { smAll, smVolFaceZone }


Public Member Functions

 TypeName ("faceSetOption")

 faceSetOption (const word &name, const word &modelType, const dictionary &dict, const fvPatch &patch)

virtual ~faceSetOption ()=default

scalar timeStart () const noexcept

scalar duration () const noexcept

bool inTimeLimits (const scalar timeValue) const

selectionModeType selectionMode () const noexcept

bool useSubMesh () const noexcept

const word & faceSetName () const noexcept

scalar A () const noexcept

const labelList & faces () const noexcept

scalar timeStart (scalar val) noexcept

scalar duration (scalar val) noexcept

virtual bool isActive ()

virtual bool read (const dictionary &dict)

- Public Member Functions inherited from option
 TypeName ("option")

 declareRunTimeSelectionTable (autoPtr, option, dictionary,(const word &name, const word &modelType, const dictionary &dict, const fvPatch &patch),(name, modelType, dict, patch))

 option (const word &name, const word &modelType, const dictionary &dict, const fvPatch &patch)

autoPtr< option > clone () const

virtual ~option ()=default

const word & name () const noexcept

const fvMesh & mesh () const noexcept

const fvPatch & patch () const noexcept

const dictionary & coeffs () const noexcept

bool active () const noexcept

void setApplied (const label fieldi)

const word & regionName () const noexcept

const faMesh & regionMesh () const

const volSurfaceMapping & vsm () const

bool active (const bool on) noexcept

virtual label applyToField (const word &fieldName) const

virtual void checkApplied () const

virtual void addSup (const areaScalarField &h, faMatrix< scalar > &eqn, const label fieldi)

virtual void addSup (const areaScalarField &h, faMatrix< vector > &eqn, const label fieldi)

virtual void addSup (const areaScalarField &h, faMatrix< symmTensor > &eqn, const label fieldi)

virtual void addSup (const areaScalarField &h, faMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void addSup (const areaScalarField &h, faMatrix< tensor > &eqn, const label fieldi)

virtual void addSup (const areaScalarField &h, const areaScalarField &rho, faMatrix< scalar > &eqn, const label fieldi)

virtual void addSup (const areaScalarField &h, const areaScalarField &rho, faMatrix< vector > &eqn, const label fieldi)

virtual void addSup (const areaScalarField &h, const areaScalarField &rho, faMatrix< symmTensor > &eqn, const label fieldi)

virtual void addSup (const areaScalarField &h, const areaScalarField &rho, faMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void addSup (const areaScalarField &h, const areaScalarField &rho, faMatrix< tensor > &eqn, const label fieldi)

virtual void constrain (faMatrix< scalar > &eqn, const label fieldi)

virtual void constrain (faMatrix< vector > &eqn, const label fieldi)

virtual void constrain (faMatrix< sphericalTensor > &eqn, const label fieldi)

virtual void constrain (faMatrix< symmTensor > &eqn, const label fieldi)

virtual void constrain (faMatrix< tensor > &eqn, const label fieldi)

virtual void correct (areaScalarField &field)

virtual void correct (areaVectorField &field)

virtual void correct (areaSphericalTensorField &field)

virtual void correct (areaSymmTensorField &field)

virtual void correct (areaTensorField &field)

virtual void writeHeader (Ostream &) const

virtual void writeFooter (Ostream &) const

virtual void writeData (Ostream &) const


Static Public Attributes

static const Enum< selectionModeType > selectionModeTypeNames_


Protected Member Functions

void setSelection (const dictionary &dict)

void setFaceSelection ()

void setArea ()

- Protected Member Functions inherited from option
void resetApplied ()


Protected Attributes

scalar timeStart_

scalar duration_

selectionModeType selectionMode_

word faceSetName_

labelList faces_

scalar A_

- Protected Attributes inherited from option
const word name_

const word modelType_

const fvMesh & mesh_

const fvPatch & patch_

dictionary dict_

dictionary coeffs_

wordList fieldNames_

List< bool > applied_

word regionName_


Additional Inherited Members

- Static Public Member Functions inherited from option
static autoPtr< option > New (const word &name, const dictionary &dict, const fvPatch &patch)

- Public Attributes inherited from option
bool log


Detailed Description

Intermediate abstract class for handling face-set options for the derived faOptions.

Usage
Minimal example by using constant/faOptions:
<userDefinedName1>
{
    // Mandatory/Optional (inherited) entries
    ...

    // Mandatory entries (unmodifiable)
    selectionMode     all;

    // Optional entries (runtime modifiable)
    timeStart         1.0;

    // Conditional mandatory entries (runtime modifiable)

        // when timeStart entry is present
        duration          1.4;

        // when selectionMode=volFaceZone
        faceZone          <faceZoneName>;
}

where the entries mean:

Property Description Type Reqd Dflt
selectionMode Mode of face selection - see below word yes -
timeStart Start time of faOption scalar no -1
duration Duration of faOption execution starting from timeStart scalar cndtnl 0
faceZone Name of operand faceZone word cndtnl -

Options for the selectionMode entry:

      all       | Use all faces in the computational domain
      faceZone  | Use a given faceZone

The inherited entries are elaborated in:

Note
  • Source/sink options are to be added to the right-hand side of equations.
Source files

Definition at line 130 of file faceSetOption.H.

Member Enumeration Documentation

◆ selectionModeType

enum selectionModeType
Enumerator
smAll
smVolFaceZone

Definition at line 139 of file faceSetOption.H.

Constructor & Destructor Documentation

◆ faceSetOption()

faceSetOption ( const word &  name,
const word &  modelType,
const dictionary &  dict,
const fvPatch &  patch
)

Definition at line 170 of file faceSetOption.C.

References Foam::decrIndent(), dict, Foam::incrIndent(), Foam::Info, and Foam::read().

Here is the call graph for this function:

◆ ~faceSetOption()

virtual ~faceSetOption ( )
virtualdefault

Member Function Documentation

◆ setSelection()

void setSelection ( const dictionary &  dict)
protected

Definition at line 48 of file faceSetOption.C.

References dict, Foam::exit(), faceSetOption::faceSetName_, Foam::FatalError, FatalErrorInFunction, faceSetOption::selectionMode_, faceSetOption::selectionModeTypeNames_, faceSetOption::smAll, and faceSetOption::smVolFaceZone.

Here is the call graph for this function:

◆ setFaceSelection()

void setFaceSelection ( )
protected

Definition at line 101 of file faceSetOption.C.

References Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::identity(), Foam::indent(), Foam::Info, n, and zoneID.

Here is the call graph for this function:

◆ setArea()

void setArea ( )
protected

Definition at line 74 of file faceSetOption.C.

References IOstream::defaultPrecision(), Foam::endl(), Foam::indent(), Foam::Info, Foam::reduce(), Foam::returnReduce(), and Time::timeName().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "faceSetOption"  )

◆ timeStart() [1/2]

Foam::scalar timeStart ( ) const
inlinenoexcept

Definition at line 23 of file faceSetOptionI.H.

References faceSetOption::timeStart_.

◆ duration() [1/2]

Foam::scalar duration ( ) const
inlinenoexcept

Definition at line 29 of file faceSetOptionI.H.

◆ inTimeLimits()

bool inTimeLimits ( const scalar  timeValue) const
inline

Definition at line 35 of file faceSetOptionI.H.

◆ selectionMode()

Foam::fa::faceSetOption::selectionModeType selectionMode ( ) const
inlinenoexcept

Definition at line 50 of file faceSetOptionI.H.

◆ useSubMesh()

bool useSubMesh ( ) const
inlinenoexcept

Definition at line 56 of file faceSetOptionI.H.

Referenced by limitVelocity::correct().

Here is the caller graph for this function:

◆ faceSetName()

const Foam::word & faceSetName ( ) const
inlinenoexcept

Definition at line 62 of file faceSetOptionI.H.

◆ A()

Foam::scalar A ( ) const
inlinenoexcept

Definition at line 68 of file faceSetOptionI.H.

◆ faces()

const Foam::labelList & faces ( ) const
inlinenoexcept

Definition at line 74 of file faceSetOptionI.H.

◆ timeStart() [2/2]

Foam::scalar timeStart ( scalar  val)
inlinenoexcept

Definition at line 80 of file faceSetOptionI.H.

◆ duration() [2/2]

Foam::scalar duration ( scalar  val)
inlinenoexcept

Definition at line 88 of file faceSetOptionI.H.

◆ isActive()

bool isActive ( )
virtual

Reimplemented from option.

Definition at line 198 of file faceSetOption.C.

References option::isActive().

Here is the call graph for this function:

◆ read()

bool read ( const dictionary &  dict)
virtual

Reimplemented from option.

Reimplemented in externalHeatFluxSource, jouleHeatingSource, contactHeatFluxSource, externalFileSource, and limitVelocity.

Definition at line 223 of file faceSetOption.C.

References dict, and option::read().

Referenced by limitVelocity::read().

Here is the call graph for this function:
Here is the caller graph for this function:

Member Data Documentation

◆ selectionModeTypeNames_

const Foam::Enum< Foam::fa::faceSetOption::selectionModeType > selectionModeTypeNames_
static

Definition at line 146 of file faceSetOption.H.

Referenced by faceSetOption::setSelection().

◆ timeStart_

scalar timeStart_
protected

Definition at line 154 of file faceSetOption.H.

Referenced by faceSetOption::timeStart().

◆ duration_

scalar duration_
protected

Definition at line 157 of file faceSetOption.H.

◆ selectionMode_

selectionModeType selectionMode_
protected

Definition at line 160 of file faceSetOption.H.

Referenced by faceSetOption::setSelection().

◆ faceSetName_

word faceSetName_
protected

Definition at line 163 of file faceSetOption.H.

Referenced by faceSetOption::setSelection().

◆ faces_

labelList faces_
protected

Definition at line 166 of file faceSetOption.H.

◆ A_

scalar A_
protected

Definition at line 169 of file faceSetOption.H.
