polyline Class Reference

Extrudes by transforming points along a polyline provided as a series of points and edge segments. Supports all blockMesh edge types, e.g. line, arc, spline. The surface points are rotated to follow the path. More...

Inheritance diagram for polyline:

Collaboration diagram for polyline:

Public Member Functions
	TypeName ("polyline")
	polyline (const dictionary &dict)
virtual	~polyline ()=default
point	operator() (const point &surfacePoint, const vector &surfaceNormal, const label layer) const
void	positionAndDirection (const scalar lambda, vector &p, vector &n) const
Public Member Functions inherited from extrudeModel
	TypeName ("extrudeModel")
	declareRunTimeSelectionTable (autoPtr, extrudeModel, dictionary,(const dictionary &dict),(dict))
	extrudeModel (const word &modelType, const dictionary &dict)
virtual	~extrudeModel ()=default
label	nLayers () const
scalar	expansionRatio () const
scalar	sumThickness (const label layer) const

Additional Inherited Members
Static Public Member Functions inherited from extrudeModel
static autoPtr< extrudeModel >	New (const dictionary &dict)
Protected Member Functions inherited from extrudeModel
	extrudeModel (const extrudeModel &)=delete
void	operator= (const extrudeModel &)=delete
Protected Attributes inherited from extrudeModel
label	nLayers_
const scalar	expansionRatio_
const dictionary &	coeffDict_

Detailed Description

Extrudes by transforming points along a polyline provided as a series of points and edge segments. Supports all blockMesh edge types, e.g. line, arc, spline. The surface points are rotated to follow the path.

Property	Description	Required	Default
vertices	List of vertices	yes
edges	List of blockEdge segments	yes
toleranceCheck	Relative tolerance for polyline checks	no	SMALL

Definition at line 74 of file polyline.H.

Constructor & Destructor Documentation

polyline()

polyline ( const dictionary &  dict )

explicit

Definition at line 42 of file polyline.C.

References Foam::abort(), Foam::expressions::patchExpr::debug, Foam::endl(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::Info, Foam::mag(), Foam::nl, Foam::normalised(), polyline::positionAndDirection(), and Foam::tab.

Here is the call graph for this function:

~polyline()

virtual ~polyline ( )

virtualdefault

Member Function Documentation

TypeName()

TypeName

(

"polyline"

)

operator()()

point operator() ( const point &  surfacePoint, const vector &  surfaceNormal, const label  layer  ) const

virtual

Implements extrudeModel.

Definition at line 125 of file polyline.C.

References Foam::endl(), Foam::mag(), n, Foam::normalised(), p, quaternion::transform(), and WarningInFunction.

Here is the call graph for this function:

positionAndDirection()

void positionAndDirection	(	const scalar	lambda,
		vector &	p,
		vector &	n
	)		const

Definition at line 168 of file polyline.C.

References Foam::interpolateXY(), lambda(), Foam::max(), Foam::min(), n, Foam::normalised(), p, s, and y.

Referenced by polyline::polyline().

Here is the call graph for this function:

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• src/mesh/extrudeModel/polyline/polyline.H
• src/mesh/extrudeModel/polyline/polyline.C
