externalDisplacementMeshMover Class Reference

Virtual base class for mesh movers with externally provided displacement field giving the boundary conditions. Move the mesh from the current location to a new location (so modify the mesh; v.s. motionSolver that only returns the new location). More...

Inheritance diagram for externalDisplacementMeshMover:

Collaboration diagram for externalDisplacementMeshMover:

Public Member Functions
	TypeName ("externalDisplacementMeshMover")
	declareRunTimeSelectionTable (autoPtr, externalDisplacementMeshMover, dictionary,(const dictionary &dict, const List< labelPair > &baffles, pointVectorField &pointDisplacement, const bool dryRun),(dict, baffles, pointDisplacement, dryRun))
	externalDisplacementMeshMover (const dictionary &dict, const List< labelPair > &baffles, pointVectorField &pointDisplacement, const bool dryRun)
virtual	~externalDisplacementMeshMover ()
pointVectorField &	pointDisplacement ()
const pointVectorField &	pointDisplacement () const
const pointMesh &	pMesh () const
const polyMesh &	mesh () const
virtual bool	move (const dictionary &, const label nAllowableErrors, labelList &checkFaces)=0
virtual void	movePoints (const pointField &)
virtual void	updateMesh (const mapPolyMesh &)

Static Public Member Functions
static autoPtr< externalDisplacementMeshMover >	New (const word &type, const dictionary &dict, const List< labelPair > &baffles, pointVectorField &pointDisplacement, const bool dryRun=false)

Static Protected Member Functions
static labelList	getFixedValueBCs (const pointVectorField &)
static autoPtr< indirectPrimitivePatch >	getPatch (const polyMesh &, const labelList &)

Protected Attributes
List< labelPair >	baffles_
pointVectorField &	pointDisplacement_
const bool	dryRun_

Detailed Description

Virtual base class for mesh movers with externally provided displacement field giving the boundary conditions. Move the mesh from the current location to a new location (so modify the mesh; v.s. motionSolver that only returns the new location).

All mesh movers are expected to read the dictionary settings at invocation of move(), i.e. not cache any settings.

Source files

• externalDisplacementMeshMover.H
• externalDisplacementMeshMover.C

Definition at line 54 of file externalDisplacementMeshMover.H.

Constructor & Destructor Documentation

externalDisplacementMeshMover()

externalDisplacementMeshMover	(	const dictionary &	dict,
		const List< labelPair > &	baffles,
		pointVectorField &	pointDisplacement,
		const bool	dryRun
	)

Definition at line 113 of file externalDisplacementMeshMover.C.

~externalDisplacementMeshMover()

~externalDisplacementMeshMover ( )

virtual

Definition at line 162 of file externalDisplacementMeshMover.C.

Member Function Documentation

getFixedValueBCs()

Foam::labelList getFixedValueBCs ( const pointVectorField &  field )

staticprotected

Definition at line 38 of file externalDisplacementMeshMover.C.

References DynamicList::append(), field(), forAll, and Foam::isA().

Here is the call graph for this function:

getPatch()

Foam::autoPtr< Foam::indirectPrimitivePatch > getPatch ( const polyMesh &  mesh, const labelList &  patchIDs  )

staticprotected

Definition at line 69 of file externalDisplacementMeshMover.C.

References forAll, mesh, Foam::New(), patches, and polyPatch::start().

Here is the call graph for this function:

TypeName()

TypeName

(

"externalDisplacementMeshMover"

)

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		externalDisplacementMeshMover	,
		dictionary	,
		(const dictionary &dict, const List< labelPair > &baffles, pointVectorField &pointDisplacement, const bool dryRun)	,
		(dict, baffles, pointDisplacement, dryRun)
	)

New()

Foam::autoPtr< Foam::externalDisplacementMeshMover > New ( const word &  type, const dictionary &  dict, const List< labelPair > &  baffles, pointVectorField &  pointDisplacement, const bool  dryRun = false  )

static

Definition at line 130 of file externalDisplacementMeshMover.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInLookup, and Foam::Info.

Referenced by snappyLayerDriver::addLayers(), and displacementMeshMoverMotionSolver::meshMover().

Here is the call graph for this function:

Here is the caller graph for this function:

pointDisplacement() [1/2]

pointVectorField& pointDisplacement ( )

inline

Definition at line 155 of file externalDisplacementMeshMover.H.

References externalDisplacementMeshMover::pointDisplacement_.

pointDisplacement() [2/2]

const pointVectorField& pointDisplacement ( ) const

inline

Definition at line 161 of file externalDisplacementMeshMover.H.

References externalDisplacementMeshMover::pointDisplacement_.

pMesh()

const pointMesh& pMesh ( ) const

inline

Definition at line 166 of file externalDisplacementMeshMover.H.

References externalDisplacementMeshMover::pointDisplacement_.

Referenced by externalDisplacementMeshMover::mesh().

Here is the caller graph for this function:

mesh()

const polyMesh& mesh ( ) const

inline

Definition at line 171 of file externalDisplacementMeshMover.H.

References externalDisplacementMeshMover::pMesh().

Here is the call graph for this function:

move()

virtual bool move ( const dictionary &  , const label  nAllowableErrors, labelList &  checkFaces  )

pure virtual

Implemented in medialAxisMeshMover, and displacementMotionSolverMeshMover.

movePoints()

void movePoints ( const pointField &  )

virtual

Reimplemented in medialAxisMeshMover, and displacementMotionSolverMeshMover.

Definition at line 168 of file externalDisplacementMeshMover.C.

Referenced by displacementMotionSolverMeshMover::movePoints(), and medialAxisMeshMover::movePoints().

Here is the caller graph for this function:

updateMesh()

void updateMesh ( const mapPolyMesh &  mpm )

virtual

Reimplemented in medialAxisMeshMover, and displacementMotionSolverMeshMover.

Definition at line 174 of file externalDisplacementMeshMover.C.

References DynamicList::append(), forAll, mapPolyMesh::reverseFaceMap(), and DynamicList::shrink().

Here is the call graph for this function:

Member Data Documentation

baffles_

List<labelPair> baffles_

protected

Definition at line 61 of file externalDisplacementMeshMover.H.

pointDisplacement_

pointVectorField& pointDisplacement_

protected

Definition at line 64 of file externalDisplacementMeshMover.H.

Referenced by externalDisplacementMeshMover::pMesh(), and externalDisplacementMeshMover::pointDisplacement().

dryRun_

const bool dryRun_

protected

Definition at line 67 of file externalDisplacementMeshMover.H.

---

The documentation for this class was generated from the following files:

• src/mesh/snappyHexMesh/externalDisplacementMeshMover/externalDisplacementMeshMover.H
• src/mesh/snappyHexMesh/externalDisplacementMeshMover/externalDisplacementMeshMover.C
