Creates upwind stencil by shifting a centred stencil to upwind and downwind faces and optionally removing all non-(up/down)wind faces ('pureUpwind'). More...

Inheritance diagram for extendedUpwindCellToFaceStencil:

[legend]

Collaboration diagram for extendedUpwindCellToFaceStencil:

[legend]

Public Member Functions
	extendedUpwindCellToFaceStencil (const cellToFaceStencil &, const bool pureUpwind, const scalar minOpposedness)

	extendedUpwindCellToFaceStencil (const cellToFaceStencil &)

bool	pureUpwind () const

const mapDistribute &	ownMap () const

const mapDistribute &	neiMap () const

const labelListList &	ownStencil () const

const labelListList &	neiStencil () const

template<class Type >
tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	weightedSum (const surfaceScalarField &phi, const GeometricField< Type, fvPatchField, volMesh > &fld, const List< List< scalar >> &ownWeights, const List< List< scalar >> &neiWeights) const

template<class Type >
Foam::tmp< Foam::GeometricField< Type, Foam::fvsPatchField, Foam::surfaceMesh > >	weightedSum (const surfaceScalarField &phi, const GeometricField< Type, fvPatchField, volMesh > &fld, const List< List< scalar >> &ownWeights, const List< List< scalar >> &neiWeights) const

Public Member Functions inherited from extendedCellToFaceStencil
	ClassName ("extendedCellToFaceStencil")

	extendedCellToFaceStencil (const polyMesh &)

template<class Type >
void	collectData (const mapDistribute &map, const labelListList &stencil, const GeometricField< Type, fvPatchField, volMesh > &fld, List< List< Type >> &stencilFld)

template<class Type >
Foam::tmp< Foam::GeometricField< Type, Foam::fvsPatchField, Foam::surfaceMesh > >	weightedSum (const mapDistribute &map, const labelListList &stencil, const GeometricField< Type, fvPatchField, volMesh > &fld, const List< List< scalar >> &stencilWeights)

Additional Inherited Members
Static Public Member Functions inherited from extendedCellToFaceStencil
template<class T >
static void	collectData (const mapDistribute &map, const labelListList &stencil, const GeometricField< T, fvPatchField, volMesh > &fld, List< List< T >> &stencilFld)

template<class Type >
static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	weightedSum (const mapDistribute &map, const labelListList &stencil, const GeometricField< Type, fvPatchField, volMesh > &fld, const List< List< scalar >> &stencilWeights)

Static Protected Member Functions inherited from extendedCellToFaceStencil
static void	writeStencilStats (Ostream &os, const labelListList &stencil, const mapDistribute &map)

Protected Attributes inherited from extendedCellToFaceStencil
const polyMesh &	mesh_

Detailed Description

Creates upwind stencil by shifting a centred stencil to upwind and downwind faces and optionally removing all non-(up/down)wind faces ('pureUpwind').

Note: the minOpposedness parameter is to decide which upwind and downwind faces to combine the stencils from. If myArea is the local area and upwindArea the area of the possible upwind candidate it will be included if (upwindArea & myArea)/magSqr(myArea) > minOpposedness so this includes both cosine and area. WIP.

Source files

Definition at line 57 of file extendedUpwindCellToFaceStencil.H.

Constructor & Destructor Documentation

◆ extendedUpwindCellToFaceStencil() [1/2]

extendedUpwindCellToFaceStencil	(	const cellToFaceStencil &	stencil,
		const bool	pureUpwind,
		const scalar	minOpposedness
	)

Definition at line 376 of file extendedUpwindCellToFaceStencil.C.

References DynamicList::append(), fvMesh::C(), primitiveMesh::faceAreas(), primitiveMesh::faceCentres(), forAll, cellToFaceStencil::globalNumbering(), mesh, cellToFaceStencil::mesh(), UPstream::nProcs(), and points.

Here is the call graph for this function:

◆ extendedUpwindCellToFaceStencil() [2/2]

extendedUpwindCellToFaceStencil ( const cellToFaceStencil & stencil )

Definition at line 520 of file extendedUpwindCellToFaceStencil.C.

References DynamicList::append(), fvMesh::C(), primitiveMesh::faceAreas(), primitiveMesh::faceCentres(), forAll, cellToFaceStencil::globalNumbering(), mesh, cellToFaceStencil::mesh(), UPstream::nProcs(), and points.

Here is the call graph for this function:

Member Function Documentation

◆ pureUpwind()

bool pureUpwind ( ) const

inline

Definition at line 147 of file extendedUpwindCellToFaceStencil.H.

◆ ownMap()

const mapDistribute& ownMap ( ) const

inline

Definition at line 153 of file extendedUpwindCellToFaceStencil.H.

Referenced by pureUpwindCFCCellToFaceStencilObject::pureUpwindCFCCellToFaceStencilObject(), upwindCECCellToFaceStencilObject::upwindCECCellToFaceStencilObject(), upwindCFCCellToFaceStencilObject::upwindCFCCellToFaceStencilObject(), upwindCPCCellToFaceStencilObject::upwindCPCCellToFaceStencilObject(), and upwindFECCellToFaceStencilObject::upwindFECCellToFaceStencilObject().

Here is the caller graph for this function:

◆ neiMap()

const mapDistribute& neiMap ( ) const

inline

Definition at line 159 of file extendedUpwindCellToFaceStencil.H.

◆ ownStencil()

const labelListList& ownStencil ( ) const

inline

Definition at line 165 of file extendedUpwindCellToFaceStencil.H.

Referenced by pureUpwindCFCCellToFaceStencilObject::pureUpwindCFCCellToFaceStencilObject(), upwindCECCellToFaceStencilObject::upwindCECCellToFaceStencilObject(), upwindCFCCellToFaceStencilObject::upwindCFCCellToFaceStencilObject(), upwindCPCCellToFaceStencilObject::upwindCPCCellToFaceStencilObject(), and upwindFECCellToFaceStencilObject::upwindFECCellToFaceStencilObject().

Here is the caller graph for this function:

◆ neiStencil()

const labelListList& neiStencil ( ) const

inline

Definition at line 171 of file extendedUpwindCellToFaceStencil.H.

◆ weightedSum() [1/2]

tmp<GeometricField<Type, fvsPatchField, surfaceMesh> > weightedSum	(	const surfaceScalarField &	phi,
		const GeometricField< Type, fvPatchField, volMesh > &	fld,
		const List< List< scalar >> &	ownWeights,
		const List< List< scalar >> &	neiWeights
	)		const

Referenced by PureUpwindFitScheme< Type, Polynomial, Stencil >::correction(), and UpwindFitScheme< Type, Polynomial, Stencil >::correction().

Here is the caller graph for this function:

◆ weightedSum() [2/2]

Foam::tmp<Foam::GeometricField<Type, Foam::fvsPatchField, Foam::surfaceMesh> > weightedSum	(	const surfaceScalarField &	phi,
		const GeometricField< Type, fvPatchField, volMesh > &	fld,
		const List< List< scalar >> &	ownWeights,
		const List< List< scalar >> &	neiWeights
	)		const
