expressionEntry Class Reference

Convert dictionary entry to a stringified expression. More...

Inheritance diagram for expressionEntry:

Public Member Functions
	TypeNameNoDebug ("expressionEntry")
	declareRunTimeSelectionTable (autoPtr, expressionEntry, empty,(),())
	expressionEntry ()=default
virtual	~expressionEntry ()=default
virtual string	toExpr (const entry &e) const
template<class Type >
Foam::string	toExprStr (const Type &data)
template<class Type >
Foam::string	toExprStr (ITstream &is)

Static Public Member Functions
static autoPtr< expressionEntry >	New (const word &name)
static string	evaluate (const entry &e)
static void	inplaceExpand (std::string &s, const dictionary &dict)
static expressions::exprString	expand (const std::string &str, const dictionary &dict)

Static Protected Member Functions
template<class Type >
static string	toExprStr (const Type &data)
template<class Type >
static string	toExprStr (ITstream &is)

Detailed Description

Convert dictionary entry to a stringified expression.

The general OpenFOAM dictionary expansions will result in space-separated values. For example,

    origin (0.21 0 0.01);

    condition  "mag(pos() - $centre) < 0.5";

this will expand to the following:

    condition  "mag(pos() - (0.21 0 0.01)) < 0.5";

For these type of expressions, we'd would like better control. Using instead the special expansions, we can add an effective type cast.

    condition  "mag(pos() - $[(vector)centre]) < 0.5";

which will expand to the following:

    condition  "mag(pos() - vector(0.21,0,0.01)) < 0.5";

Source files

• expressionEntry.H
• expressionEntry.C
• expressionEntryI.H

Definition at line 81 of file expressionEntry.H.

Constructor & Destructor Documentation

expressionEntry()

expressionEntry ( )

default

~expressionEntry()

virtual ~expressionEntry ( )

virtualdefault

Member Function Documentation

toExprStr() [1/4]

static string toExprStr ( const Type &  data )

staticprotected

toExprStr() [2/4]

static string toExprStr ( ITstream &  is )

staticprotected

TypeNameNoDebug()

TypeNameNoDebug

(

"expressionEntry"

)

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		expressionEntry	,
		empty	,
		()	,
		()
	)

New()

Foam::autoPtr< Foam::exprTools::expressionEntry > New ( const word &  name )

static

Definition at line 111 of file expressionEntry.C.

References Foam::exit(), Foam::FatalError, FatalErrorInLookup, and Foam::name().

Here is the call graph for this function:

evaluate()

Foam::string evaluate ( const entry &  e )

inlinestatic

Definition at line 27 of file expressionEntryI.H.

References Foam::constant::electromagnetic::e.

Referenced by expressionEntry::toExpr().

Here is the caller graph for this function:

inplaceExpand()

void inplaceExpand ( std::string &  s, const dictionary &  dict  )

static

Definition at line 134 of file expressionEntry.C.

References dict, Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::getVariableOrDie(), Foam::stringOps::inplaceExpand(), Foam::stringOps::inplaceTrim(), Foam::New(), Foam::nl, s, entry::stream(), and ITstream::toString().

Here is the call graph for this function:

expand()

Foam::expressions::exprString expand ( const std::string &  str, const dictionary &  dict  )

static

Definition at line 274 of file expressionEntry.C.

References dict, Foam::stringOps::inplaceExpand(), and s.

Here is the call graph for this function:

toExpr()

virtual string toExpr ( const entry &  e ) const

inlinevirtual

Reimplemented in dimensionedSphericalTensorEntry, dimensionedSymmTensorEntry, sphericalTensorEntry, dimensionedTensorEntry, symmTensorEntry, dimensionedVectorEntry, stringEntry, tensorEntry, dimensionedScalarEntry, vectorEntry, and boolEntry.

Definition at line 157 of file expressionEntry.H.

References Foam::constant::electromagnetic::e, and expressionEntry::evaluate().

Here is the call graph for this function:

toExprStr() [3/4]

Foam::string toExprStr ( const Type &  data )

inline

Definition at line 35 of file expressionEntryI.H.

References Foam::component(), and StringStreamAllocator< StreamType >::str().

Here is the call graph for this function:

toExprStr() [4/4]

Foam::string toExprStr ( ITstream &  is )

inline

Definition at line 53 of file expressionEntryI.H.

References Foam::Zero.

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/expressions/exprEntry/expressionEntry.H
• src/OpenFOAM/expressions/exprEntry/expressionEntry.C
• src/OpenFOAM/expressions/exprEntry/expressionEntryI.H
