This boundary condition provides a wall constraint on the turbulent kinetic energy dissipation rate, i.e. epsilon, and the turbulent kinetic energy production contribution, i.e. G, for low- and high-Reynolds number turbulence models. More...

Inheritance diagram for epsilonWallFunctionFvPatchScalarField:

[legend]

Collaboration diagram for epsilonWallFunctionFvPatchScalarField:

[legend]

Public Member Functions
	TypeName ("epsilonWallFunction")

	epsilonWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)

	epsilonWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)

	epsilonWallFunctionFvPatchScalarField (const epsilonWallFunctionFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)

	epsilonWallFunctionFvPatchScalarField (const epsilonWallFunctionFvPatchScalarField &)

virtual tmp< fvPatchScalarField >	clone () const

	epsilonWallFunctionFvPatchScalarField (const epsilonWallFunctionFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)

virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const

virtual	~epsilonWallFunctionFvPatchScalarField ()=default

scalarField &	G (bool init=false)

scalarField &	epsilon (bool init=false)

virtual void	updateCoeffs ()

virtual void	updateWeightedCoeffs (const scalarField &weights)

virtual void	manipulateMatrix (fvMatrix< scalar > &matrix)

virtual void	manipulateMatrix (fvMatrix< scalar > &matrix, const scalarField &weights)

virtual void	write (Ostream &) const

Public Member Functions inherited from fixedValueFvPatchField< scalar >
	TypeName ("fixedValue")

	fixedValueFvPatchField (const fvPatch &, const DimensionedField< scalar, volMesh > &)

	fixedValueFvPatchField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const scalar &value)

	fixedValueFvPatchField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &, const bool valueRequired=true)

	fixedValueFvPatchField (const fixedValueFvPatchField< scalar > &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)

	fixedValueFvPatchField (const fixedValueFvPatchField< scalar > &)

	fixedValueFvPatchField (const fixedValueFvPatchField< scalar > &, const DimensionedField< scalar, volMesh > &)

virtual tmp< fvPatchField< scalar > >	clone () const

virtual bool	fixesValue () const

virtual bool	assignable () const

virtual tmp< Field< scalar > >	valueInternalCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< scalar > >	valueBoundaryCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< scalar > >	gradientInternalCoeffs () const

virtual tmp< Field< scalar > >	gradientBoundaryCoeffs () const

virtual void	operator= (const UList< scalar > &)

virtual void	operator= (const fvPatchField< scalar > &)

virtual void	operator= (const scalar &)

virtual void	operator+= (const fvPatchField< scalar > &)

virtual void	operator+= (const Field< scalar > &)

virtual void	operator+= (const scalar &)

virtual void	operator-= (const fvPatchField< scalar > &)

virtual void	operator-= (const Field< scalar > &)

virtual void	operator-= (const scalar &)

virtual void	operator*= (const fvPatchField< scalar > &)

virtual void	operator*= (const Field< scalar > &)

virtual void	operator*= (const scalar)

virtual void	operator/= (const fvPatchField< scalar > &)

virtual void	operator/= (const Field< scalar > &)

virtual void	operator/= (const scalar)

Public Member Functions inherited from fvPatchField< scalar >
	TypeName ("fvPatchField")

	declareRunTimeSelectionTable (tmp, fvPatchField, patch,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF),(p, iF))

	declareRunTimeSelectionTable (tmp, fvPatchField, patchMapper,(const fvPatchField< Type > &ptf, const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const fvPatchFieldMapper &m),(dynamic_cast< const fvPatchFieldType & >(ptf), p, iF, m))

	declareRunTimeSelectionTable (tmp, fvPatchField, dictionary,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const dictionary &dict),(p, iF, dict))

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Type &value)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const word &patchType)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Field< Type > &)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &, const bool valueRequired=true)

	fvPatchField (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

	fvPatchField (const fvPatchField< Type > &)

	fvPatchField (const fvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< fvPatchField< Type > >	clone (const DimensionedField< Type, volMesh > &iF) const

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatch &p)

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &pf)

virtual	~fvPatchField ()=default

bool	useImplicit () const noexcept

bool	useImplicit (bool on) noexcept

virtual bool	coupled () const

const objectRegistry &	db () const

const fvPatch &	patch () const

const DimensionedField< Type, volMesh > &	internalField () const

const Field< Type > &	primitiveField () const

const word &	patchType () const

word &	patchType ()

bool	updated () const

bool	manipulatedMatrix () const

virtual void	autoMap (const fvPatchFieldMapper &)

virtual void	rmap (const fvPatchField< Type > &, const labelList &)

virtual tmp< Field< Type > >	snGrad () const

virtual tmp< Field< Type > >	snGrad (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > >	patchInternalField () const

virtual void	patchInternalField (Field< Type > &) const

virtual tmp< Field< Type > >	patchNeighbourField () const

virtual void	initEvaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)

virtual void	evaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)

virtual tmp< Field< Type > >	valueInternalCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > >	valueBoundaryCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > >	gradientInternalCoeffs (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > >	gradientBoundaryCoeffs (const scalarField &deltaCoeffs) const

virtual void	manipulateMatrix (fvMatrix< Type > &matrix)

virtual void	manipulateMatrix (fvMatrix< Type > &matrix, const scalarField &weights)

virtual void	manipulateMatrix (fvMatrix< Type > &matrix, const label iMatrix, const direction cmp)

void	check (const fvPatchField< Type > &) const

virtual void	operator= (const UList< Type > &)

virtual void	operator= (const fvPatchField< Type > &)

virtual void	operator= (const Type &)

virtual void	operator+= (const fvPatchField< Type > &)

virtual void	operator+= (const Field< Type > &)

virtual void	operator+= (const Type &)

virtual void	operator-= (const fvPatchField< Type > &)

virtual void	operator-= (const Field< Type > &)

virtual void	operator-= (const Type &)

virtual void	operator== (const fvPatchField< Type > &)

virtual void	operator== (const Field< Type > &)

virtual void	operator== (const Type &)

Protected Member Functions
virtual void	setMaster ()

virtual void	createAveragingWeights ()

virtual epsilonWallFunctionFvPatchScalarField &	epsilonPatch (const label patchi)

virtual void	calculateTurbulenceFields (const turbulenceModel &turbulence, scalarField &G0, scalarField &epsilon0)

virtual void	calculate (const turbulenceModel &turbulence, const List< scalar > &cornerWeights, const fvPatch &patch, scalarField &G, scalarField &epsilon)

virtual label &	master ()

Protected Attributes
const bool	lowReCorrection_

bool	initialised_

label	master_

scalarField	G_

scalarField	epsilon_

List< List< scalar > >	cornerWeights_

Static Protected Attributes
static scalar	tolerance_ = 1e-5

Additional Inherited Members
Public Types inherited from fvPatchField< scalar >
typedef fvPatch	Patch

typedef calculatedFvPatchField< Type >	Calculated

Static Public Member Functions inherited from fvPatchField< scalar >
static tmp< fvPatchField< Type > >	New (const word &, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > >	New (const word &, const word &actualPatchType, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > >	New (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

static tmp< fvPatchField< Type > >	New (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatch &)

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &)

static const word &	calculatedType ()

Static Public Attributes inherited from fvPatchField< scalar >
static int	disallowGenericFvPatchField

Detailed Description

This boundary condition provides a wall constraint on the turbulent kinetic energy dissipation rate, i.e. epsilon, and the turbulent kinetic energy production contribution, i.e. G, for low- and high-Reynolds number turbulence models.

Reference:

    Binomial blending of the viscous and inertial sublayers (tag:ME):
        Menter, F., & Esch, T. (2001).
        Elements of industrial heat transfer prediction.
        In Proceedings of the 16th Brazilian Congress of Mechanical
        Engineering (COBEM), November 2001. vol. 20, p. 117-127.

    Exponential/Max blending of the viscous and inertial sublayers (tag:PH):
        Popovac, M., & Hanjalić, K. (2007).
        Compound wall treatment for RANS computation of complex
        turbulent flows and heat transfer.
        Flow, turbulence and combustion, 78(2), 177-202.
        DOI:10.1007/s10494-006-9067-x

Usage

Example of the boundary condition specification:

<patchName>
{
    // Mandatory entries (unmodifiable)
    type             epsilonWallFunction;

    // Optional entries (unmodifiable)
    lowReCorrection  false;
    blending         stepwise;
    n                2.0;

    // Optional (inherited) entries
    ...
}

where the entries mean:

Property	Description	Type	Req'd	Dflt
`type`	Type name: epsilonWallFunction	word	yes	-
`lowReCorrection`	Flag: apply low-Re correction	bool	no	false
`blending`	Viscous/inertial sublayer blending method	word	no	stepwise
`n`	Binomial blending exponent	scalar	no	2.0

The inherited entries are elaborated in:

Options for the blending entry:

      stepwise    | Stepwise switch (discontinuous)
      max         | Maximum value switch (discontinuous)
      binomial    | Binomial blending (smooth)
      exponential | Exponential blending (smooth)

wherein epsilon predictions for the viscous and inertial sublayers are blended according to the following expressions:

stepwise (default):

$\epsilon = \epsilon_{vis} \qquad if \quad y^+ < y^+_{lam}$

$\epsilon = \epsilon_{log} \qquad if \quad y^+ >= y^+_{lam}$

where

$\epsilon$	=	$\epsilon$ at
$\epsilon_{vis}$	=	$\epsilon$ computed by viscous subl. assumptions
$\epsilon_{log}$	=	$\epsilon$ computed by inertial subl. assumptions
	=	estimated wall-normal height of the cell centre in wall units
$y^+_{lam}$	=	estimated intersection of the viscous and inertial sublayers

max (PH:Eq. 27):

$\epsilon = max(\epsilon_{vis}, \epsilon_{log})$

binomial (ME:Eqs. 15-16):

$\epsilon = ((\epsilon_{vis})^n + (\epsilon_{log})^n)^{1/n}$

where

=

Binomial blending exponent

exponential (PH:Eq. 32):

$\epsilon = \epsilon_{vis} \exp[-\Gamma] +\epsilon_{log} \exp[-1/\Gamma]$

where (PH:p. 193)

$\Gamma_\epsilon$	=	$\Gamma = 0.001 (y^+)^4 / (1.0 + y^+)$
$\Gamma_G$	=	$\Gamma = 0.01 (y^+)^4 / (1.0 + 5.0 y^+)$
$\Gamma_\epsilon$	=	Blending expression for $\epsilon$
$\Gamma_G$	=	Blending expression for

G predictions for the viscous and inertial sublayers are blended in a stepwise manner, and G below $y^+_{lam}$ (i.e. in the viscous sublayer) is presumed to be zero.

Note

The coefficients Cmu, kappa, and E are obtained from the specified nutWallFunction in order to ensure that each patch possesses the same set of values for these coefficients.
lowReCorrection operates with only stepwise blending treatment to ensure the backward compatibility.
If lowReCorrection is on, stepwise blending treatment is fully active.
If lowReCorrection is off, only the inertial sublayer prediction is used in the wall function, hence high-Re mode operation.

See also

Foam::omegaWallFunctionFvPatchScalarField

Source files

Definition at line 255 of file epsilonWallFunctionFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ epsilonWallFunctionFvPatchScalarField() [1/5]

epsilonWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 298 of file epsilonWallFunctionFvPatchScalarField.C.

Referenced by epsilonWallFunctionFvPatchScalarField::clone().

Here is the caller graph for this function:

◆ epsilonWallFunctionFvPatchScalarField() [2/5]

epsilonWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 338 of file epsilonWallFunctionFvPatchScalarField.C.

References Foam::operator==().

Here is the call graph for this function:

◆ epsilonWallFunctionFvPatchScalarField() [3/5]

epsilonWallFunctionFvPatchScalarField	(	const epsilonWallFunctionFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 317 of file epsilonWallFunctionFvPatchScalarField.C.

◆ epsilonWallFunctionFvPatchScalarField() [4/5]

epsilonWallFunctionFvPatchScalarField ( const epsilonWallFunctionFvPatchScalarField & ewfpsf )

Definition at line 377 of file epsilonWallFunctionFvPatchScalarField.C.

◆ epsilonWallFunctionFvPatchScalarField() [5/5]

epsilonWallFunctionFvPatchScalarField	(	const epsilonWallFunctionFvPatchScalarField &	ewfpsf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 395 of file epsilonWallFunctionFvPatchScalarField.C.

◆ ~epsilonWallFunctionFvPatchScalarField()

virtual ~epsilonWallFunctionFvPatchScalarField ( )

virtualdefault

Member Function Documentation

◆ setMaster()

void setMaster ( )

protectedvirtual

Definition at line 47 of file epsilonWallFunctionFvPatchScalarField.C.

References epsilonWallFunctionFvPatchScalarField::epsilon(), epsilonWallFunctionFvPatchScalarField::epsilonPatch(), forAll, fvPatchField< scalar >::internalField(), epsilonWallFunctionFvPatchScalarField::master(), and epsilonWallFunctionFvPatchScalarField::master_.

Here is the call graph for this function:

◆ createAveragingWeights()

void createAveragingWeights ( )

protectedvirtual

Definition at line 77 of file epsilonWallFunctionFvPatchScalarField.C.

References DynamicList::append(), GeometricField::boundaryField(), polyMesh::changing(), Foam::dimless, epsilon, forAll, mesh, IOobject::NO_READ, IOobject::NO_WRITE, fvPatchField::patchInternalField(), fvMesh::time(), Time::timeName(), and Foam::Zero.

Here is the call graph for this function:

◆ epsilonPatch()

Foam::epsilonWallFunctionFvPatchScalarField & epsilonPatch ( const label patchi )

protectedvirtual

Definition at line 138 of file epsilonWallFunctionFvPatchScalarField.C.

References epsilon.

Referenced by epsilonWallFunctionFvPatchScalarField::setMaster().

Here is the caller graph for this function:

◆ calculateTurbulenceFields()

void calculateTurbulenceFields	(	const turbulenceModel &	turbulence,
		scalarField &	G0,
		scalarField &	epsilon0
	)

protectedvirtual

Definition at line 155 of file epsilonWallFunctionFvPatchScalarField.C.

References epsilonWallFunctionFvPatchScalarField::calculate(), Foam::constant::electromagnetic::epsilon0, fvPatch::faceCells(), forAll, Foam::constant::electromagnetic::G0, fvPatchField::patch(), and turbulence.

Here is the call graph for this function:

◆ calculate()

void calculate	(	const turbulenceModel &	turbulence,
		const List< scalar > &	cornerWeights,
		const fvPatch &	patch,
		scalarField &	G,
		scalarField &	epsilon
	)

protectedvirtual

Reimplemented in atmEpsilonWallFunctionFvPatchScalarField.

Definition at line 188 of file epsilonWallFunctionFvPatchScalarField.C.

References GeometricField::boundaryField(), nutWallFunctionFvPatchScalarField::Cmu(), Foam::constant::electromagnetic::epsilon0, Foam::exp(), forAll, Foam::constant::electromagnetic::G0, k, turbulenceModel::k(), nutWallFunctionFvPatchScalarField::kappa(), Foam::mag(), Foam::max(), turbulenceModel::nu(), nutWallFunctionFvPatchScalarField::nutw(), Foam::foamVersion::patch, Foam::pow(), Foam::pow025(), Foam::pow4(), fvPatchField::snGrad(), Foam::sqr(), Foam::sqrt(), turbulenceModel::U(), y, turbulenceModel::y(), yPlus, and nutWallFunctionFvPatchScalarField::yPlusLam().

Referenced by epsilonWallFunctionFvPatchScalarField::calculateTurbulenceFields().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ master()

virtual label& master ( )

inlineprotectedvirtual

Definition at line 345 of file epsilonWallFunctionFvPatchScalarField.H.

References epsilonWallFunctionFvPatchScalarField::master_.

Referenced by epsilonWallFunctionFvPatchScalarField::setMaster().

Here is the caller graph for this function:

◆ TypeName()

TypeName ( "epsilonWallFunction" )

◆ clone() [1/2]

virtual tmp<fvPatchScalarField> clone ( ) const

inlinevirtual

Reimplemented in atmEpsilonWallFunctionFvPatchScalarField.

Definition at line 392 of file epsilonWallFunctionFvPatchScalarField.H.

References epsilonWallFunctionFvPatchScalarField::epsilonWallFunctionFvPatchScalarField().

Here is the call graph for this function:

◆ clone() [2/2]

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > & iF ) const

inlinevirtual

Reimplemented from fixedValueFvPatchField< scalar >.

Reimplemented in atmEpsilonWallFunctionFvPatchScalarField.

Definition at line 409 of file epsilonWallFunctionFvPatchScalarField.H.

References epsilonWallFunctionFvPatchScalarField::epsilonWallFunctionFvPatchScalarField().

Here is the call graph for this function:

◆ G()

Foam::scalarField & G ( bool init = false )

Definition at line 415 of file epsilonWallFunctionFvPatchScalarField.C.

References init(), and Foam::foamVersion::patch.

Here is the call graph for this function:

◆ epsilon()

Foam::scalarField & epsilon ( bool init = false )

Definition at line 434 of file epsilonWallFunctionFvPatchScalarField.C.

References init(), and Foam::foamVersion::patch.

Referenced by epsilonWallFunctionFvPatchScalarField::setMaster().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ updateCoeffs()

void updateCoeffs ( )

virtual

Reimplemented from fvPatchField< scalar >.

Definition at line 452 of file epsilonWallFunctionFvPatchScalarField.C.

References epsilon, Foam::constant::electromagnetic::epsilon0, forAll, Foam::constant::universal::G, Foam::constant::electromagnetic::G0, turbulenceModel::GName(), Foam::constant::atomic::group, IOobject::groupName(), Foam::foamVersion::patch, turbulenceModel::propertiesName, and fvPatchField::updateCoeffs().

Here is the call graph for this function:

◆ updateWeightedCoeffs()

void updateWeightedCoeffs ( const scalarField & weights )

virtual

Reimplemented from fvPatchField< scalar >.

Definition at line 498 of file epsilonWallFunctionFvPatchScalarField.C.

References epsilon, Foam::constant::electromagnetic::epsilon0, forAll, Foam::constant::universal::G, Foam::constant::electromagnetic::G0, turbulenceModel::GName(), Foam::constant::atomic::group, IOobject::groupName(), Foam::foamVersion::patch, turbulenceModel::propertiesName, and fvPatchField::updateCoeffs().

Here is the call graph for this function:

◆ manipulateMatrix() [1/2]

void manipulateMatrix ( fvMatrix< scalar > & matrix )

virtual

Definition at line 555 of file epsilonWallFunctionFvPatchScalarField.C.

References fvPatchField::manipulateMatrix(), Foam::foamVersion::patch, and fvMatrix::setValues().

Here is the call graph for this function:

◆ manipulateMatrix() [2/2]

void manipulateMatrix	(	fvMatrix< scalar > &	matrix,
		const scalarField &	weights
	)

virtual

Definition at line 571 of file epsilonWallFunctionFvPatchScalarField.C.

References DynamicList::append(), Foam::expressions::patchExpr::debug, Foam::endl(), fld, forAll, fvPatchField::manipulateMatrix(), Foam::foamVersion::patch, Foam::Pout, and fvMatrix::setValues().

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Reimplemented from fixedValueFvPatchField< scalar >.

Reimplemented in atmEpsilonWallFunctionFvPatchScalarField.

Definition at line 614 of file epsilonWallFunctionFvPatchScalarField.C.

References os(), fixedValueFvPatchField< Type >::write(), and Ostream::writeEntry().

Here is the call graph for this function:

Member Data Documentation

◆ tolerance_

Foam::scalar tolerance_ = 1e-5

staticprotected

Definition at line 289 of file epsilonWallFunctionFvPatchScalarField.H.

◆ lowReCorrection_

const bool lowReCorrection_

protected

Definition at line 292 of file epsilonWallFunctionFvPatchScalarField.H.

◆ initialised_

bool initialised_

protected

Definition at line 295 of file epsilonWallFunctionFvPatchScalarField.H.

◆ master_

label master_

protected

Definition at line 298 of file epsilonWallFunctionFvPatchScalarField.H.

Referenced by epsilonWallFunctionFvPatchScalarField::master(), and epsilonWallFunctionFvPatchScalarField::setMaster().

◆ G_

scalarField G_

protected

Definition at line 301 of file epsilonWallFunctionFvPatchScalarField.H.

◆ epsilon_

scalarField epsilon_

protected

Definition at line 304 of file epsilonWallFunctionFvPatchScalarField.H.

◆ cornerWeights_

List<List<scalar> > cornerWeights_

protected

Definition at line 307 of file epsilonWallFunctionFvPatchScalarField.H.

The documentation for this class was generated from the following files:

src/TurbulenceModels/turbulenceModels/derivedFvPatchFields/wallFunctions/epsilonWallFunctions/epsilonWallFunction/epsilonWallFunctionFvPatchScalarField.H
src/TurbulenceModels/turbulenceModels/derivedFvPatchFields/wallFunctions/epsilonWallFunctions/epsilonWallFunction/epsilonWallFunctionFvPatchScalarField.C

Public Member Functions

Protected Member Functions

Protected Attributes

Static Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ epsilonWallFunctionFvPatchScalarField() [1/5]

◆ epsilonWallFunctionFvPatchScalarField() [2/5]

◆ epsilonWallFunctionFvPatchScalarField() [3/5]

◆ epsilonWallFunctionFvPatchScalarField() [4/5]

◆ epsilonWallFunctionFvPatchScalarField() [5/5]

◆ ~epsilonWallFunctionFvPatchScalarField()

Member Function Documentation

◆ setMaster()

◆ createAveragingWeights()

◆ epsilonPatch()

◆ calculateTurbulenceFields()

◆ calculate()

◆ master()

◆ TypeName()

◆ clone() [1/2]

◆ clone() [2/2]

◆ G()

◆ epsilon()

◆ updateCoeffs()

◆ updateWeightedCoeffs()

◆ manipulateMatrix() [1/2]

◆ manipulateMatrix() [2/2]

◆ write()

Member Data Documentation

◆ tolerance_

◆ lowReCorrection_

◆ initialised_

◆ master_

◆ G_

◆ epsilon_

◆ cornerWeights_
