entry Class Reference

A keyword and a list of tokens is an 'entry'. More...

Inheritance diagram for entry:

Collaboration diagram for entry:

Public Types
enum	inputMode {   MERGE, OVERWRITE, PROTECT, WARN,   ERROR, GLOBAL }

Public Member Functions
	entry (const keyType &keyword)
	entry (const entry &e)
virtual autoPtr< entry >	clone (const dictionary &parentDict) const =0
virtual autoPtr< entry >	clone () const
virtual	~entry ()=default
const keyType &	keyword () const noexcept
keyType &	keyword () noexcept
virtual const fileName &	name () const =0
virtual fileName &	name ()=0
virtual fileName	relativeName () const =0
virtual label	startLineNumber () const =0
virtual label	endLineNumber () const =0
virtual bool	isStream () const noexcept
virtual ITstream &	stream () const =0
virtual bool	isDict () const noexcept
virtual const dictionary *	dictPtr () const noexcept
virtual dictionary *	dictPtr () noexcept
virtual const dictionary &	dict () const =0
virtual dictionary &	dict ()=0
void	checkITstream (const ITstream &is) const
template<class T >
T	get () const
template<class T >
void	readEntry (T &val) const
template<class T , class Predicate >
T	getCheck (const Predicate &pred) const
template<class T , class Predicate >
void	readCheck (T &val, const Predicate &pred) const
virtual void	write (Ostream &os) const =0
void	operator= (const entry &e)
bool	operator== (const entry &e) const
bool	operator!= (const entry &e) const

Static Public Member Functions
static bool	New (dictionary &parentDict, Istream &is, const inputMode inpMode=inputMode::GLOBAL, const int endChar=0)
static autoPtr< entry >	New (Istream &is)
static void	resetInputMode ()

Static Public Attributes
static int	disableFunctionEntries
static inputMode	globalInputMode = inputMode::MERGE

Static Protected Member Functions
static void	reportReadWarning (const IOstream &, const std::string &)

Friends
Ostream &	operator<< (Ostream &os, const entry &e)

Detailed Description

A keyword and a list of tokens is an 'entry'.

An entry can be read, written and printed, and the types and values of its tokens analysed. An entry is a high-level building block for data description. It is a front-end for the token parser. A list of entries can be used as a set of keyword syntax elements, for example.

Source files

• entry.H
• entry.C
• entryIO.C

Definition at line 63 of file entry.H.

Member Enumeration Documentation

inputMode

enum inputMode

strong

Enumerator
MERGE	Merge sub-dictionaries when possible.
OVERWRITE	Keep last entry. Silently remove previous ones.
PROTECT	Keep initial entry. Silently ignore subsequent ones.
WARN	Keep initial entry. Warn about subsequent ones.
ERROR	FatalError for duplicate entries.
GLOBAL	Use global value from globalInputMode variable.

Definition at line 72 of file entry.H.

Constructor & Destructor Documentation

entry() [1/2]

entry

(

const keyType &

keyword

)

Definition at line 62 of file entry.C.

entry() [2/2]

entry

(

const entry &

e

)

Definition at line 69 of file entry.C.

~entry()

virtual ~entry ( )

virtualdefault

Member Function Documentation

reportReadWarning()

void reportReadWarning ( const IOstream &  is, const std::string &  msg  )

staticprotected

Definition at line 41 of file entry.C.

References Foam::endl(), IOstream::lineNumber(), and IOstream::relativeName().

Here is the call graph for this function:

clone() [1/2]

virtual autoPtr<entry> clone ( const dictionary &  parentDict ) const

pure virtual

Implemented in dictionaryEntry, dictionaryListEntry, and primitiveEntry.

clone() [2/2]

Foam::autoPtr< Foam::entry > clone ( ) const

virtual

Definition at line 76 of file entry.C.

References dictionary::null.

New() [1/2]

bool New ( dictionary &  parentDict, Istream &  is, const inputMode  inpMode = inputMode::GLOBAL, const int  endChar = 0  )

static

Definition at line 98 of file entryIO.C.

References dictionary::add(), token::BEGIN_BLOCK, token::BEGIN_LIST, fileName::clean(), dictionary::csearchScoped(), entry::disableFunctionEntries, token::DOLLAR, token::END_BLOCK, token::END_LIST, IOstream::eof(), functionEntry::execute(), Foam::exit(), IOstream::fatalCheck(), Foam::FatalIOError, FatalIOErrorInFunction, FUNCTION_NAME, token::HASH, token::info(), Foam::stringOps::inplaceExpand(), token::isLabel(), token::isPunctuation(), Foam::glTF::key(), keyType::LITERAL, dictionary::makeScopedDict(), Foam::mode(), fileName::name(), fileName::path(), Istream::putBack(), keyType::REGEX, keyType::REGEX_RECURSIVE, dictionary::search(), dictionary::searchScoped(), dictionary::substituteScopedKeyword(), and word::validate().

Referenced by ifeqEntry::evaluate(), dictionary::read(), and functionObjectList::readFunctionObject().

Here is the call graph for this function:

Here is the caller graph for this function:

New() [2/2]

Foam::autoPtr< Foam::entry > New ( Istream &  is )

static

Definition at line 456 of file entryIO.C.

References token::BEGIN_BLOCK, IOstream::fatalCheck(), FUNCTION_NAME, dictionary::null, Istream::putBack(), and autoPtr::reset().

Here is the call graph for this function:

resetInputMode()

void resetInputMode ( )

static

Definition at line 54 of file entry.C.

References entry::globalInputMode, and entry::MERGE.

Referenced by dictionary::dictionary(), and Foam::operator>>().

Here is the caller graph for this function:

keyword() [1/2]

const keyType& keyword ( ) const

inlinenoexcept

Definition at line 191 of file entry.H.

Referenced by dictionary::add(), cellModel::cellModel(), solutionControl::maxResidual(), solutionControl::maxTypeResidual(), phase::iNew::operator()(), phaseModel::iNew::operator()(), sizeGroup::iNew::operator()(), Foam::operator>>(), Foam::functionObjects::operator>>(), genericPatchFieldBase::processEntry(), GeometricField::Boundary::readField(), refinementSurfaces::refinementSurfaces(), dictionary::set(), shellSurfaces::shellSurfaces(), Foam::blockMeshTools::write(), dictionaryListEntry::write(), dictionaryEntry::write(), and genericPatchFieldBase::writeGeneric().

Here is the caller graph for this function:

keyword() [2/2]

keyType& keyword ( )

inlinenoexcept

Definition at line 197 of file entry.H.

name() [1/2]

virtual const fileName& name ( ) const

pure virtual

Implemented in primitiveEntry, and dictionaryEntry.

Referenced by dictionary::add().

Here is the caller graph for this function:

name() [2/2]

virtual fileName& name ( )

pure virtual

Implemented in primitiveEntry, and dictionaryEntry.

relativeName()

virtual fileName relativeName ( ) const

pure virtual

Implemented in primitiveEntry, and dictionaryEntry.

startLineNumber()

virtual label startLineNumber ( ) const

pure virtual

Implemented in primitiveEntry, and dictionaryEntry.

Referenced by dynamicCodeContext::readEntry().

Here is the caller graph for this function:

endLineNumber()

virtual label endLineNumber ( ) const

pure virtual

Implemented in primitiveEntry, and dictionaryEntry.

isStream()

virtual bool isStream ( ) const

inlinevirtualnoexcept

Reimplemented in primitiveEntry.

Definition at line 219 of file entry.H.

Referenced by Constant< Type >::Constant(), Polynomial< Type >::Polynomial(), genericPatchFieldBase::processEntry(), and Table< Type >::Table().

Here is the caller graph for this function:

stream()

virtual ITstream& stream ( ) const

pure virtual

Implemented in primitiveEntry, and dictionaryEntry.

Referenced by Constant< Type >::Constant(), exprResultDelayed::exprResultDelayed(), Foam::exprTools::getList(), expressionEntry::inplaceExpand(), solutionControl::maxTypeResidual(), fvGeometryScheme::New(), Polynomial< Type >::Polynomial(), genericPatchFieldBase::processEntry(), Foam::blockMeshTools::read(), entry::readCheck(), fvExprDriver::readDict(), entry::readEntry(), Foam::readScaling(), shellSurfaces::shellSurfaces(), Table< Type >::Table(), solution::upgradeSolverDict(), and Foam::writeEntryIfPresent().

Here is the caller graph for this function:

isDict()

virtual bool isDict ( ) const

inlinevirtualnoexcept

Definition at line 229 of file entry.H.

References entry::dictPtr().

Referenced by dictionary::add(), dictionary::cfindScopedDict(), Foam::entryToString(), GAMGSolver::GAMGSolver(), Foam::getVariableOrDie(), dictionary::makeScopedDict(), functionObjectList::read(), GeometricField::Boundary::readField(), Foam::debug::switchSet(), solution::upgradeSolverDict(), and Foam::writeEntryIfPresent().

Here is the call graph for this function:

Here is the caller graph for this function:

dictPtr() [1/2]

virtual const dictionary* dictPtr ( ) const

inlinevirtualnoexcept

Reimplemented in dictionaryEntry.

Definition at line 236 of file entry.H.

Referenced by dictionary::cfindScopedDict(), entry::isDict(), and dictionary::makeScopedDict().

Here is the caller graph for this function:

dictPtr() [2/2]

virtual dictionary* dictPtr ( )

inlinevirtualnoexcept

Reimplemented in dictionaryEntry.

Definition at line 243 of file entry.H.

dict() [1/2]

virtual const dictionary& dict ( ) const

pure virtual

Implemented in dictionaryEntry, and primitiveEntry.

Referenced by dictionary::add(), Foam::entryToString(), GAMGSolver::GAMGSolver(), functionObjectList::read(), sampledSurfaces::read(), GeometricField::Boundary::readField(), refinementSurfaces::refinementSurfaces(), shellSurfaces::shellSurfaces(), Foam::debug::switchSet(), and Foam::writeEntryIfPresent().

Here is the caller graph for this function:

dict() [2/2]

virtual dictionary& dict ( )

pure virtual

Implemented in dictionaryEntry, and primitiveEntry.

checkITstream()

void checkITstream

(

const ITstream &

is

)

const

Definition at line 103 of file entry.C.

References JobInfo::constructed, Foam::endl(), Foam::exit(), Foam::FatalIOError, IOstream::lineNumber(), Foam::nl, and ITstream::nRemainingTokens().

Referenced by entry::readCheck(), entry::readEntry(), and Foam::readScaling().

Here is the call graph for this function:

Here is the caller graph for this function:

get()

T get ( ) const

inline

Definition at line 265 of file entry.H.

References Foam::T().

Referenced by Foam::getOrAdd(), Enum< actionType >::getOrDefault(), multiFieldValue::read(), and Enum< actionType >::readEntry().

Here is the call graph for this function:

Here is the caller graph for this function:

readEntry()

void readEntry ( T &  val ) const

inline

Definition at line 277 of file entry.H.

References entry::checkITstream(), and entry::stream().

Referenced by dynamicCodeContext::readEntry().

Here is the call graph for this function:

Here is the caller graph for this function:

getCheck()

T getCheck ( const Predicate &  pred ) const

inline

Definition at line 290 of file entry.H.

References Foam::T().

Here is the call graph for this function:

readCheck()

void readCheck ( T &  val, const Predicate &  pred  ) const

inline

Definition at line 303 of file entry.H.

References entry::checkITstream(), and entry::stream().

Here is the call graph for this function:

write()

virtual void write ( Ostream &  os ) const

pure virtual

Implemented in primitiveEntry, dictionaryEntry, functionEntry, and dictionaryListEntry.

operator=()

void operator=

(

const entry &

e

)

Definition at line 187 of file entry.C.

References Foam::constant::electromagnetic::e.

operator==()

bool operator==

(

const entry &

e

)

const

Definition at line 198 of file entry.C.

References Foam::constant::electromagnetic::e, and StringStreamAllocator< StreamType >::str().

Here is the call graph for this function:

operator!=()

bool operator!=

(

const entry &

e

)

const

Definition at line 221 of file entry.C.

References Foam::constant::electromagnetic::e, and Foam::operator==().

Here is the call graph for this function:

Friends And Related Function Documentation

operator<<

Ostream& operator<< ( Ostream &  os, const entry &  e  )

friend

Member Data Documentation

disableFunctionEntries

int disableFunctionEntries

static

Definition at line 123 of file entry.H.

Referenced by entry::New().

globalInputMode

Foam::entry::inputMode globalInputMode = inputMode::MERGE

static

Definition at line 126 of file entry.H.

Referenced by entry::resetInputMode().

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/db/dictionary/entry/entry.H
• src/OpenFOAM/db/dictionary/entry/entry.C
• src/OpenFOAM/db/dictionary/entry/entryIO.C
