Sorting/classification of cells (3D) into corresponding ensight element types. More...

Inheritance diagram for ensightCells:

Collaboration diagram for ensightCells:

Public Types
enum	elemType { TETRA4 = 0, PYRAMID5, PENTA6, HEXA8, NFACED }

Public Member Functions
	TypeName ("ensightCells")

	ensightCells ()

	ensightCells (const string &description)

virtual	~ensightCells ()=default

label	size (const elemType etype) const

labelRange	range (const elemType etype) const

label	total () const

label	total (const elemType etype) const

const FixedList< label, nTypes > &	totals () const

FixedList< label, nTypes >	sizes () const

const labelList &	cellIds () const

const labelUList	cellIds (const elemType etype) const

Map< label >	meshPointMap (const polyMesh &mesh) const

void	classify (const polyMesh &mesh)

void	classify (const polyMesh &mesh, const labelUList &cellIds)

void	classify (const polyMesh &mesh, const bitSet &selection)

void	clearOut ()

void	clear ()

void	reduce ()

void	sort ()

void	incrCellIds (const label off)

void	decrCellIds (const label off)

label	uniqueMeshPoints (const polyMesh &mesh, labelList &uniqueMeshPointLabels, bool parallel) const

virtual void	writeDict (Ostream &os, const bool full=false) const

virtual void	write (ensightGeoFile &os, const polyMesh &mesh, bool parallel) const

label	size () const noexcept

Public Member Functions inherited from ensightPart
	TypeNameNoDebug ("ensightPart")

	ensightPart ()

	ensightPart (const string &description)

virtual	~ensightPart ()=default

label	index () const noexcept

label &	index () noexcept

label	identifier () const noexcept

label &	identifier () noexcept

bool	empty () const noexcept

label	size () const noexcept

const string &	name () const noexcept

void	rename (const string &value)

void	rename (string &&value)

label	operator[] (const label i) const

Static Public Member Functions
static const char *	key (const elemType etype)

Static Public Attributes
static constexpr int	nTypes = 5

static const char *	elemNames [nTypes]

Additional Inherited Members
Protected Member Functions inherited from ensightPart
const labelList &	addressing () const noexcept

labelList &	addressing () noexcept

void	clear ()

void	incrAddressing (const label off)

void	decrAddressing (const label off)

Detailed Description

Sorting/classification of cells (3D) into corresponding ensight element types.

Definition at line 48 of file ensightCells.H.

Member Enumeration Documentation

◆ elemType

enum elemType

Enumerator
TETRA4	"tetra4"
PYRAMID5	"pyramid5"
PENTA6	"penta6"
HEXA8	"hexa8"
NFACED	"nfaced"

Definition at line 58 of file ensightCells.H.

Constructor & Destructor Documentation

◆ ensightCells() [1/2]

ensightCells ( )

Definition at line 71 of file ensightCells.C.

◆ ensightCells() [2/2]

ensightCells ( const string & description )

explicit

Definition at line 79 of file ensightCells.C.

References ensightPart::rename().

Here is the call graph for this function:

◆ ~ensightCells()

virtual ~ensightCells ( )

virtualdefault

Member Function Documentation

◆ key()

const char * key ( const elemType etype )

inlinestatic

Definition at line 36 of file ensightCellsI.H.

Referenced by ensightCells::writeDict().

Here is the caller graph for this function:

◆ TypeName()

TypeName ( "ensightCells" )

◆ size() [1/2]

Foam::label size ( const elemType etype ) const

inline

Definition at line 54 of file ensightCellsI.H.

Referenced by Foam::ensightOutput::writeField().

Here is the caller graph for this function:

◆ range()

Foam::labelRange range ( const elemType etype ) const

inline

Definition at line 60 of file ensightCellsI.H.

◆ total() [1/2]

Foam::label total ( ) const

Definition at line 102 of file ensightCells.C.

References forAll.

Referenced by Foam::ensightOutput::writeField().

Here is the caller graph for this function:

◆ total() [2/2]

Foam::label total ( const elemType etype ) const

inline

Definition at line 48 of file ensightCellsI.H.

◆ totals()

const Foam::FixedList< Foam::label, 5 > & totals ( ) const

inline

Definition at line 42 of file ensightCellsI.H.

◆ sizes()

Foam::FixedList< Foam::label, 5 > sizes ( ) const

Definition at line 89 of file ensightCells.C.

References Foam::BitOps::count(), and forAll.

Here is the call graph for this function:

◆ cellIds() [1/2]

const Foam::labelList & cellIds ( ) const

inline

Definition at line 66 of file ensightCellsI.H.

Referenced by ensightCells::meshPointMap(), and Foam::ensightOutput::writeField().

Here is the caller graph for this function:

◆ cellIds() [2/2]

const Foam::labelUList cellIds ( const elemType etype ) const

inline

Definition at line 73 of file ensightCellsI.H.

References range.

◆ meshPointMap()

Foam::Map< Foam::label > meshPointMap ( const polyMesh & mesh ) const

Definition at line 30 of file ensightCellsAddr.C.

References ensightCells::cellIds(), mesh, nPoints, and ensightPart::size().

Here is the call graph for this function:

◆ classify() [1/3]

void classify ( const polyMesh & mesh )

Definition at line 231 of file ensightCells.C.

References mesh, and primitiveMesh::nCells().

Referenced by ensightMesh::correct().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ classify() [2/3]

void classify	(	const polyMesh &	mesh,
		const labelUList &	cellIds
	)

Definition at line 239 of file ensightCells.C.

References mesh.

◆ classify() [3/3]

void classify	(	const polyMesh &	mesh,
		const bitSet &	selection
	)

Definition at line 249 of file ensightCells.C.

References mesh.

◆ clearOut()

void clearOut ( )

Definition at line 124 of file ensightCells.C.

◆ clear()

void clear ( )

Definition at line 113 of file ensightCells.C.

References ensightPart::clear(), and Foam::Zero.

Referenced by ensightMesh::correct().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ reduce()

void reduce ( )

Definition at line 128 of file ensightCells.C.

References forAll, and Foam::reduce().

Referenced by ensightMesh::correct().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ sort()

void sort ( )

Definition at line 139 of file ensightCells.C.

References IntRange< IntType >::empty(), range, and Foam::sort().

Here is the call graph for this function:

◆ incrCellIds()

void incrCellIds ( const label off )

inline

Definition at line 79 of file ensightCellsI.H.

◆ decrCellIds()

void decrCellIds ( const label off )

inline

Definition at line 85 of file ensightCellsI.H.

◆ uniqueMeshPoints()

Foam::label uniqueMeshPoints	(	const polyMesh &	mesh,
		labelList &	uniqueMeshPointLabels,
		bool	parallel
	)		const

Definition at line 215 of file ensightCellsAddr.C.

References mesh, and List::null().

Referenced by Foam::ensightOutput::writePointField().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ writeDict()

void writeDict	(	Ostream &	os,
		const bool	full = `false`
	)		const

virtual

Reimplemented from ensightPart.

Definition at line 258 of file ensightCells.C.

References Ostream::beginBlock(), Ostream::endBlock(), Foam::endEntry(), ensightCells::key(), Foam::name(), ensightCells::nTypes, os(), Foam::type(), Ostream::writeEntry(), Ostream::writeKeyword(), and UList::writeList().

Here is the call graph for this function:

◆ write()

void write	(	ensightGeoFile &	os,
		const polyMesh &	mesh,
		bool	parallel
	)		const

virtual

< Collective write?

Definition at line 256 of file ensightCellsIO.C.

References ensightPart::index(), mesh, ensightPart::name(), ensightCells::NFACED, nPoints, ensightCells::nTypes, os(), UPstream::parRun(), polyMesh::points(), and Foam::ensightOutput::Detail::writeCoordinates().

Here is the call graph for this function:

◆ size() [2/2]

label size

inlinenoexcept

Definition at line 150 of file ensightPart.H.

Member Data Documentation

◆ nTypes

constexpr int nTypes = 5

staticconstexpr

Definition at line 68 of file ensightCells.H.

Referenced by ensightCells::write(), and ensightCells::writeDict().

◆ elemNames

const char * elemNames

static

Initial value:

=
{
    "tetra4", "pyramid5", "penta6", "hexa8", "nfaced"
}

Definition at line 71 of file ensightCells.H.

The documentation for this class was generated from the following files:

src/fileFormats/ensight/part/cells/ensightCells.H
src/fileFormats/ensight/part/cells/ensightCells.C
src/fileFormats/ensight/part/cells/ensightCellsAddr.C
src/fileFormats/ensight/part/cells/ensightCellsI.H
src/fileFormats/ensight/part/cells/ensightCellsIO.C
