edgeInterpolationScheme< Type > Class Template Reference

Abstract base class for edge interpolation schemes. More...

Inheritance diagram for edgeInterpolationScheme< Type >:

Collaboration diagram for edgeInterpolationScheme< Type >:

Public Member Functions
	declareRunTimeSelectionTable (tmp, edgeInterpolationScheme, Mesh,(const faMesh &mesh, Istream &schemeData),(mesh, schemeData))
	declareRunTimeSelectionTable (tmp, edgeInterpolationScheme, MeshFlux,(const faMesh &mesh, const edgeScalarField &faceFlux, Istream &schemeData),(mesh, faceFlux, schemeData))
	edgeInterpolationScheme (const faMesh &mesh)
virtual	~edgeInterpolationScheme ()
const faMesh &	mesh () const
virtual tmp< edgeScalarField >	weights (const GeometricField< Type, faPatchField, areaMesh > &) const =0
virtual bool	corrected () const
virtual tmp< GeometricField< Type, faePatchField, edgeMesh > >	correction (const GeometricField< Type, faPatchField, areaMesh > &) const
virtual tmp< GeometricField< Type, faePatchField, edgeMesh > >	interpolate (const GeometricField< Type, faPatchField, areaMesh > &) const
virtual tmp< GeometricField< Type, faePatchField, edgeMesh > >	euclidianInterpolate (const GeometricField< Type, faPatchField, areaMesh > &) const
tmp< GeometricField< Type, faePatchField, edgeMesh > >	interpolate (const tmp< GeometricField< Type, faPatchField, areaMesh >> &) const
Public Member Functions inherited from refCount
constexpr	refCount () noexcept
int	count () const noexcept
bool	unique () const noexcept
void	operator++ () noexcept
void	operator++ (int) noexcept
void	operator-- () noexcept
void	operator-- (int) noexcept

Static Public Member Functions
static tmp< edgeInterpolationScheme< Type > >	New (const faMesh &mesh, Istream &schemeData)
static tmp< edgeInterpolationScheme< Type > >	New (const faMesh &mesh, const edgeScalarField &faceFlux, Istream &schemeData)
static tmp< GeometricField< Type, faePatchField, edgeMesh > >	interpolate (const GeometricField< Type, faPatchField, areaMesh > &, const tmp< edgeScalarField > &, const tmp< edgeScalarField > &)
static tmp< GeometricField< Type, faePatchField, edgeMesh > >	interpolate (const GeometricField< Type, faPatchField, areaMesh > &, const tmp< edgeScalarField > &)
static tmp< GeometricField< Type, faePatchField, edgeMesh > >	euclidianInterpolate (const GeometricField< Type, faPatchField, areaMesh > &, const tmp< edgeScalarField > &)

Detailed Description

template<class Type>
class Foam::edgeInterpolationScheme< Type >

Abstract base class for edge interpolation schemes.

Source files

• edgeInterpolationScheme.H
• edgeInterpolationScheme.C

Definition at line 53 of file edgeInterpolationScheme.H.

Constructor & Destructor Documentation

edgeInterpolationScheme()

edgeInterpolationScheme ( const faMesh &  mesh )

inline

Definition at line 102 of file edgeInterpolationScheme.H.

~edgeInterpolationScheme()

~edgeInterpolationScheme

virtual

Definition at line 122 of file edgeInterpolationScheme.C.

Member Function Documentation

declareRunTimeSelectionTable() [1/2]

declareRunTimeSelectionTable	(	tmp	,
		edgeInterpolationScheme< Type >	,
		Mesh	,
		(const faMesh &mesh, Istream &schemeData)	,
		(mesh, schemeData)
	)

declareRunTimeSelectionTable() [2/2]

declareRunTimeSelectionTable	(	tmp	,
		edgeInterpolationScheme< Type >	,
		MeshFlux	,
		(const faMesh &mesh, const edgeScalarField &faceFlux, Istream &schemeData)	,
		(mesh, faceFlux, schemeData)
	)

New() [1/2]

Foam::tmp< Foam::edgeInterpolationScheme< Type > > New ( const faMesh &  mesh, Istream &  schemeData  )

static

Definition at line 34 of file edgeInterpolationScheme.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), IOstream::eof(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, FatalIOErrorInLookup, InfoInFunction, mesh, and Foam::nl.

Referenced by gaussGrad< Type >::gaussGrad(), and laplacianScheme< Type >::laplacianScheme().

Here is the call graph for this function:

Here is the caller graph for this function:

New() [2/2]

Foam::tmp< Foam::edgeInterpolationScheme< Type > > New ( const faMesh &  mesh, const edgeScalarField &  faceFlux, Istream &  schemeData  )

static

Definition at line 77 of file edgeInterpolationScheme.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), IOstream::eof(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, FatalIOErrorInLookup, InfoInFunction, and mesh.

Here is the call graph for this function:

mesh()

const faMesh& mesh ( ) const

inline

Definition at line 134 of file edgeInterpolationScheme.H.

Referenced by skewCorrectedEdgeInterpolation< Type >::corrected(), skewCorrectedEdgeInterpolation< Type >::correction(), skewCorrectedEdgeInterpolation< Type >::skewCorrection(), and linearEdgeInterpolation< Type >::weights().

Here is the caller graph for this function:

interpolate() [1/4]

Foam::tmp< Foam::GeometricField< Type, Foam::faePatchField, Foam::edgeMesh > > interpolate ( const GeometricField< Type, faPatchField, areaMesh > &  vf, const tmp< edgeScalarField > &  tlambdas, const tmp< edgeScalarField > &  tys  )

static

Definition at line 131 of file edgeInterpolationScheme.C.

References GeometricField::boundaryField(), GeometricField::boundaryFieldRef(), tmp::clear(), Foam::expressions::patchExpr::debug, Foam::endl(), forAll, InfoInFunction, GeometricField::internalField(), lambda(), mesh, N(), Foam::constant::mathematical::pi(), GeometricField::primitiveFieldRef(), tmp::ref(), UList::size(), Tensor::T(), Foam::transform(), and y.

Referenced by Foam::linearEdgeInterpolate(), and skewCorrectedEdgeInterpolation< Type >::skewCorrection().

Here is the call graph for this function:

Here is the caller graph for this function:

interpolate() [2/4]

Foam::tmp< Foam::GeometricField< Type, Foam::faePatchField, Foam::edgeMesh > > interpolate ( const GeometricField< Type, faPatchField, areaMesh > &  vf, const tmp< edgeScalarField > &  tlambdas  )

static

Definition at line 250 of file edgeInterpolationScheme.C.

References GeometricField::boundaryField(), GeometricField::boundaryFieldRef(), tmp::clear(), Foam::expressions::patchExpr::debug, Foam::endl(), forAll, InfoInFunction, GeometricField::internalField(), lambda(), mesh, N(), Foam::constant::mathematical::pi(), GeometricField::primitiveFieldRef(), tmp::ref(), UList::size(), Tensor::T(), and Foam::transform().

Here is the call graph for this function:

euclidianInterpolate() [1/2]

Foam::tmp< Foam::GeometricField< Type, Foam::faePatchField, Foam::edgeMesh > > euclidianInterpolate ( const GeometricField< Type, faPatchField, areaMesh > &  vf, const tmp< edgeScalarField > &  tlambdas  )

static

Definition at line 367 of file edgeInterpolationScheme.C.

References GeometricField::boundaryField(), GeometricField::boundaryFieldRef(), tmp::clear(), Foam::expressions::patchExpr::debug, Foam::endl(), forAll, InfoInFunction, GeometricField::internalField(), lambda(), mesh, N(), Foam::constant::mathematical::pi(), GeometricField::primitiveFieldRef(), tmp::ref(), and UList::size().

Here is the call graph for this function:

weights()

virtual tmp<edgeScalarField> weights ( const GeometricField< Type, faPatchField, areaMesh > &  ) const

pure virtual

Implemented in blendedEdgeInterpolation< Type >, skewCorrectedEdgeInterpolation< Type >, faNVDscheme< Type, NVDweight >, upwindEdgeInterpolation< Type >, and linearEdgeInterpolation< Type >.

corrected()

virtual bool corrected ( ) const

inlinevirtual

Reimplemented in skewCorrectedEdgeInterpolation< Type >.

Definition at line 177 of file edgeInterpolationScheme.H.

correction()

virtual tmp<GeometricField<Type, faePatchField, edgeMesh> > correction ( const GeometricField< Type, faPatchField, areaMesh > &  ) const

inlinevirtual

Reimplemented in skewCorrectedEdgeInterpolation< Type >.

Definition at line 185 of file edgeInterpolationScheme.H.

interpolate() [3/4]

Foam::tmp< Foam::GeometricField< Type, Foam::faePatchField, Foam::edgeMesh > > interpolate ( const GeometricField< Type, faPatchField, areaMesh > &  vf ) const

virtual

Definition at line 443 of file edgeInterpolationScheme.C.

References Foam::correction(), Foam::expressions::patchExpr::debug, Foam::endl(), InfoInFunction, Foam::fac::interpolate(), and tmp::ref().

Here is the call graph for this function:

euclidianInterpolate() [2/2]

Foam::tmp< Foam::GeometricField< Type, Foam::faePatchField, Foam::edgeMesh > > euclidianInterpolate ( const GeometricField< Type, faPatchField, areaMesh > &  vf ) const

virtual

Definition at line 472 of file edgeInterpolationScheme.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), and InfoInFunction.

Here is the call graph for this function:

interpolate() [4/4]

Foam::tmp< Foam::GeometricField< Type, Foam::faePatchField, Foam::edgeMesh > > interpolate

(

const tmp< GeometricField< Type, faPatchField, areaMesh >> &

tvf

)

const

Definition at line 496 of file edgeInterpolationScheme.C.

References Foam::fac::interpolate().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteArea/interpolation/edgeInterpolation/edgeInterpolationScheme/edgeInterpolationScheme.H
• src/finiteArea/interpolation/edgeInterpolation/edgeInterpolationScheme/edgeInterpolationScheme.C
