edgeFaceCirculator Class Reference

Walks from starting face around edge. More...

Public Member Functions
	edgeFaceCirculator (const primitiveMesh &mesh, const label faceLabel, const bool ownerSide, const label index, const bool isBoundaryEdge)
	edgeFaceCirculator (const edgeFaceCirculator &circ)
label	faceLabel () const
bool	isInternalFace () const
bool	ownerSide () const
label	index () const
label	cellLabel () const
bool	sameOrder (const label v0, const label v1) const
void	setCanonical ()
void	operator= (const edgeFaceCirculator &iter)
bool	operator== (const edgeFaceCirculator &iter) const
bool	operator!= (const edgeFaceCirculator &iter) const
edgeFaceCirculator &	operator++ ()
edgeFaceCirculator	begin () const
edgeFaceCirculator	cbegin () const
const edgeFaceCirculator	end () const
const edgeFaceCirculator	cend () const

Static Public Member Functions
static label	getMinIndex (const face &f, const label v0, const label v1)

Detailed Description

Walks from starting face around edge.

Implicit description of edge:

• face
• index in face. edge is always between f[index] and f[index+1]
• direction (cell to walk into)

1. Use in-place:


   edgeFaceCirculator circ(..);
   // Optionally rotate to beginning: circ.setCanonical();

   // Walk
   do
   {
       Info<< "face:" << circ.face() << endl;
       ++circ;
   }
   while (circ != circ.end());

2. Use like STL iterator:


   edgeFaceCirculator circ(..);
   for
   (
       edgeFaceCirculator iter = circ.begin();
       iter != circ.end();
       ++iter
   )
   {
       Info<< "face:" << iter.face() << endl;
   }

Source files

• edgeFaceCirculator.H
• edgeFaceCirculator.C

Definition at line 84 of file edgeFaceCirculator.H.

Constructor & Destructor Documentation

edgeFaceCirculator() [1/2]

edgeFaceCirculator ( const primitiveMesh &  mesh, const label  faceLabel, const bool  ownerSide, const label  index, const bool  isBoundaryEdge  )

inline

Definition at line 105 of file edgeFaceCirculatorI.H.

edgeFaceCirculator() [2/2]

edgeFaceCirculator ( const edgeFaceCirculator &  circ )

inline

Definition at line 122 of file edgeFaceCirculatorI.H.

Member Function Documentation

getMinIndex()

Foam::label getMinIndex ( const face &  f, const label  v0, const label  v1  )

inlinestatic

Definition at line 136 of file edgeFaceCirculatorI.H.

References f().

Here is the call graph for this function:

faceLabel()

Foam::label faceLabel ( ) const

inline

Definition at line 166 of file edgeFaceCirculatorI.H.

isInternalFace()

bool isInternalFace ( ) const

inline

Definition at line 172 of file edgeFaceCirculatorI.H.

ownerSide()

bool ownerSide ( ) const

inline

Definition at line 183 of file edgeFaceCirculatorI.H.

index()

Foam::label index ( ) const

inline

Definition at line 189 of file edgeFaceCirculatorI.H.

cellLabel()

Foam::label cellLabel ( ) const

inline

Definition at line 195 of file edgeFaceCirculatorI.H.

References polyMesh::faceNeighbour(), polyMesh::faceOwner(), and mesh.

Here is the call graph for this function:

sameOrder()

bool sameOrder ( const label  v0, const label  v1  ) const

inline

Definition at line 210 of file edgeFaceCirculatorI.H.

References Foam::abort(), f(), polyMesh::faces(), Foam::FatalError, FatalErrorInFunction, and mesh.

Here is the call graph for this function:

setCanonical()

void setCanonical ( )

inline

Definition at line 230 of file edgeFaceCirculatorI.H.

References Foam::abort(), stdFoam::end(), Foam::endl(), f(), polyMesh::faceNeighbour(), polyMesh::faceOwner(), polyMesh::faces(), Foam::FatalError, FatalErrorInFunction, mesh, Foam::meshTools::otherFace(), and polyMesh::points().

Referenced by edgeFaceCirculator::begin(), and edgeFaceCirculator::cbegin().

Here is the call graph for this function:

Here is the caller graph for this function:

operator=()

void operator= ( const edgeFaceCirculator &  iter )

inline

Definition at line 334 of file edgeFaceCirculatorI.H.

operator==()

bool operator== ( const edgeFaceCirculator &  iter ) const

inline

Definition at line 344 of file edgeFaceCirculatorI.H.

operator!=()

bool operator!= ( const edgeFaceCirculator &  iter ) const

inline

Definition at line 364 of file edgeFaceCirculatorI.H.

operator++()

Foam::edgeFaceCirculator & operator++ ( )

inline

Definition at line 374 of file edgeFaceCirculatorI.H.

References Foam::abort(), polyMesh::faceNeighbour(), polyMesh::faceOwner(), Foam::FatalError, FatalErrorInFunction, mesh, and Foam::meshTools::otherFace().

Here is the call graph for this function:

begin()

Foam::edgeFaceCirculator begin ( ) const

inline

Definition at line 420 of file edgeFaceCirculatorI.H.

References edgeFaceCirculator::setCanonical().

Here is the call graph for this function:

cbegin()

Foam::edgeFaceCirculator cbegin ( ) const

inline

Definition at line 439 of file edgeFaceCirculatorI.H.

References edgeFaceCirculator::setCanonical().

Here is the call graph for this function:

end()

const Foam::edgeFaceCirculator end ( ) const

inline

Definition at line 458 of file edgeFaceCirculatorI.H.

cend()

const Foam::edgeFaceCirculator cend ( ) const

inline

Definition at line 463 of file edgeFaceCirculatorI.H.

---

The documentation for this class was generated from the following files:

• src/meshTools/edgeFaceCirculator/edgeFaceCirculator.H
• src/meshTools/edgeFaceCirculator/edgeFaceCirculatorI.H
