edge Class Reference

An edge is a list of two point labels. The functionality it provides supports the discretisation on a 2-D flat mesh. More...

Inheritance diagram for edge:

Collaboration diagram for edge:

Classes
struct	Hash
struct	hasher

Public Member Functions
	edge ()
	edge (const label from, const label to)
	edge (const labelPair &pair)
	edge (const FixedList< label, 2 > &list)
	edge (const label from, const label to, const bool doSort)
	edge (const FixedList< label, 2 > &list, const bool doSort)
	edge (const UList< label > &list, const FixedList< label, 2 > &indices)
	edge (Istream &is)
label	start () const
label &	start ()
label	end () const
label &	end ()
edge	reverseEdge () const
label	minVertex () const
label	maxVertex () const
bool	valid () const
bool	found (const label pointLabel) const
label	which (const label pointLabel) const
bool	connects (const edge &other) const
label	commonVertex (const edge &other) const
label	otherVertex (const label pointLabel) const
label	collapse ()
label	count () const
bool	empty () const
void	clear ()
bool	insert (const label index)
template<class InputIterator >
label	insert (InputIterator begIter, InputIterator endIter)
label	insert (std::initializer_list< label > list)
template<unsigned N>
label	insert (const FixedList< label, N > &list)
label	insert (const labelUList &list)
label	erase (const label index)
template<class InputIterator >
label	erase (InputIterator begIter, InputIterator endIter)
label	erase (std::initializer_list< label > list)
template<unsigned N>
label	erase (const FixedList< label, N > &list)
label	erase (const labelUList &list)
point	centre (const UList< point > &pts) const
vector	vec (const UList< point > &pts) const
vector	unitVec (const UList< point > &pts) const
scalar	mag (const UList< point > &pts) const
linePointRef	line (const UList< point > &pts) const
label &	operator[] (const label i)
const label &	operator[] (const label i) const
unsigned	hash_code (unsigned seed=0) const
template<class InputIterator >
Foam::label	insert (InputIterator begIter, InputIterator endIter)
template<unsigned N>
Foam::label	insert (const FixedList< label, N > &list)
template<class InputIterator >
Foam::label	erase (InputIterator begIter, InputIterator endIter)
template<unsigned N>
Foam::label	erase (const FixedList< label, N > &list)
const T &	second () const noexcept
T &	second () noexcept
Public Member Functions inherited from Pair
	Pair ()=default
	Pair (const T &f, const T &s)
	Pair (T &&f, T &&s)
	Pair (const std::pair< T, T > &vals)
	Pair (std::pair< T, T > &&vals)
	Pair (const FixedList< T, 2 > &list)
	Pair (const T &f, const T &s, const bool doSort)
	Pair (const FixedList< T, 2 > &list, const bool doSort)
	Pair (Istream &is)
const T &	second () const noexcept
T &	second () noexcept
const T &	other (const T &a) const
bool	sorted () const
void	flip ()
void	sort ()

Static Public Member Functions
static int	compare (const edge &a, const edge &b)
Static Public Member Functions inherited from Pair
static int	compare (const Pair< T > &a, const Pair< T > &b)

Static Public Attributes
static const char *const	typeName = "edge"

Detailed Description

An edge is a list of two point labels. The functionality it provides supports the discretisation on a 2-D flat mesh.

The edge is implemented as a Pair/FixedList of labels. As well as geometrically relevant methods, it also provides methods similar to HashSet for additional convenience. Valid point labels are always non-negative (since they correspond to addressing within the mesh). The value '-1' is used to tag invalid point labels that correspond conceptually to open 'slots', which can be filled with a HashSet-like functionality.

Source files

• edge.H
• edge.C
• edgeI.H

Definition at line 59 of file edge.H.

Constructor & Destructor Documentation

edge() [1/8]

edge ( )

inline

Definition at line 34 of file edgeI.H.

Referenced by cellShape::edge().

Here is the caller graph for this function:

edge() [2/8]

edge ( const label  from, const label  to  )

inline

Definition at line 40 of file edgeI.H.

edge() [3/8]

edge ( const labelPair &  pair )

inline

Definition at line 46 of file edgeI.H.

edge() [4/8]

edge ( const FixedList< label, 2 > &  list )

inline

Definition at line 52 of file edgeI.H.

edge() [5/8]

edge ( const label  from, const label  to, const bool  doSort  )

inline

Definition at line 58 of file edgeI.H.

edge() [6/8]

edge ( const FixedList< label, 2 > &  list, const bool  doSort  )

inline

Definition at line 64 of file edgeI.H.

edge() [7/8]

edge ( const UList< label > &  list, const FixedList< label, 2 > &  indices  )

inline

Definition at line 71 of file edgeI.H.

edge() [8/8]

edge ( Istream &  is )

inline

Definition at line 80 of file edgeI.H.

Member Function Documentation

start() [1/2]

Foam::label & start ( ) const

inline

Definition at line 88 of file edgeI.H.

Referenced by directionInfo::edgeToFaceIndex(), cellFeatures::isFeaturePoint(), PrimitivePatch<::Foam::List< labelledTri >, pointField >::meshEdge(), PrimitivePatch<::Foam::List< labelledTri >, pointField >::meshEdges(), slidingInterface::modifyMotionPoints(), Foam::polyMeshZipUpCells(), PatchTools::sortedPointEdges(), and extendedEdgeMesh::sortPointsAndEdges().

Here is the caller graph for this function:

start() [2/2]

label& start ( )

inline

end() [1/2]

Foam::label & end ( ) const

inline

Definition at line 99 of file edgeI.H.

Referenced by directionInfo::edgeToFaceIndex(), cellFeatures::isFeaturePoint(), slidingInterface::modifyMotionPoints(), Foam::polyMeshZipUpCells(), PatchTools::sortedPointEdges(), and extendedEdgeMesh::sortPointsAndEdges().

Here is the caller graph for this function:

end() [2/2]

label& end ( )

inline

reverseEdge()

Foam::edge reverseEdge ( ) const

inline

Definition at line 218 of file edgeI.H.

Referenced by hexCell::reverseEdge(), and tetCell::reverseEdge().

Here is the caller graph for this function:

minVertex()

Foam::label minVertex ( ) const

inline

Definition at line 111 of file edgeI.H.

maxVertex()

Foam::label maxVertex ( ) const

inline

Definition at line 117 of file edgeI.H.

valid()

bool valid ( ) const

inline

Definition at line 123 of file edgeI.H.

Referenced by multiWorldConnections::addConnectionById(), multiWorldConnections::addConnectionByName(), multiWorldConnections::getCommById(), and multiWorldConnections::getCommByName().

Here is the caller graph for this function:

found()

bool found ( const label  pointLabel ) const

inline

Definition at line 129 of file edgeI.H.

Referenced by edge::commonVertex(), edge::connects(), intersectedSurface::intersectedSurface(), patchEdgeFaceRegions::updateEdge(), and patchEdgeFaceRegions::updateFace().

Here is the caller graph for this function:

which()

Foam::label which ( const label  pointLabel ) const

inline

Definition at line 140 of file edgeI.H.

connects()

bool connects ( const edge &  other ) const

inline

Definition at line 159 of file edgeI.H.

References edge::found().

Referenced by Foam::calcProximityOfFeatureEdges().

Here is the call graph for this function:

Here is the caller graph for this function:

commonVertex()

Foam::label commonVertex ( const edge &  other ) const

inline

Definition at line 165 of file edgeI.H.

References edge::found().

Referenced by removePoints::countPointUsage(), and GTSsurfaceFormat< Face >::read().

Here is the call graph for this function:

Here is the caller graph for this function:

otherVertex()

Foam::label otherVertex ( const label  pointLabel ) const

inline

Definition at line 181 of file edgeI.H.

Referenced by removePoints::countPointUsage(), searchableExtrudedCircle::findParametricNearest(), and GTSsurfaceFormat< Face >::read().

Here is the caller graph for this function:

collapse()

Foam::label collapse ( )

inline

Definition at line 197 of file edgeI.H.

References n.

count()

Foam::label count ( ) const

inline

Definition at line 231 of file edgeI.H.

References n.

empty()

bool empty ( ) const

inline

Definition at line 247 of file edgeI.H.

clear()

void clear ( )

inline

Definition at line 224 of file edgeI.H.

insert() [1/7]

bool insert ( const label  index )

inline

Definition at line 253 of file edgeI.H.

insert() [2/7]

label insert ( InputIterator  begIter, InputIterator  endIter  )

inline

insert() [3/7]

Foam::label insert ( std::initializer_list< label >  list )

inline

Definition at line 308 of file edgeI.H.

References insert().

Here is the call graph for this function:

insert() [4/7]

label insert ( const FixedList< label, N > &  list )

inline

insert() [5/7]

Foam::label insert ( const labelUList &  list )

inline

Definition at line 321 of file edgeI.H.

References UList::begin(), UList::end(), and insert().

Here is the call graph for this function:

erase() [1/7]

Foam::label erase ( const label  index )

inline

Definition at line 327 of file edgeI.H.

References n.

erase() [2/7]

label erase ( InputIterator  begIter, InputIterator  endIter  )

inline

erase() [3/7]

Foam::label erase ( std::initializer_list< label >  list )

inline

Definition at line 374 of file edgeI.H.

References erase().

Here is the call graph for this function:

erase() [4/7]

label erase ( const FixedList< label, N > &  list )

inline

erase() [5/7]

Foam::label erase ( const labelUList &  list )

inline

Definition at line 387 of file edgeI.H.

References UList::begin(), UList::end(), and erase().

Here is the call graph for this function:

centre()

Foam::point centre ( const UList< point > &  pts ) const

inline

Definition at line 395 of file edgeI.H.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Referenced by surfaceFeatures::nearestEdges().

Here is the call graph for this function:

Here is the caller graph for this function:

vec()

Foam::vector vec ( const UList< point > &  pts ) const

inline

Definition at line 410 of file edgeI.H.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Referenced by searchableExtrudedCircle::findParametricNearest(), slidingInterface::modifyMotionPoints(), surfaceFeatures::nearestFeatEdge(), extendedEdgeMesh::sortPointsAndEdges(), and cuttingSurfaceBase::walkCellCuts().

Here is the call graph for this function:

Here is the caller graph for this function:

unitVec()

Foam::vector unitVec ( const UList< point > &  pts ) const

inline

Definition at line 425 of file edgeI.H.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, Foam::mag(), s, and Foam::Zero.

Referenced by cellFeatures::isFeaturePoint().

Here is the call graph for this function:

Here is the caller graph for this function:

mag()

Foam::scalar mag ( const UList< point > &  pts ) const

inline

Definition at line 443 of file edgeI.H.

References Foam::mag().

Referenced by face::longestEdge(), and surfaceFeatures::trimFeatures().

Here is the call graph for this function:

Here is the caller graph for this function:

line()

Foam::linePointRef line ( const UList< point > &  pts ) const

inline

Definition at line 449 of file edgeI.H.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Referenced by slidingInterface::modifyMotionPoints(), and syncTools::syncEdgeList().

Here is the call graph for this function:

Here is the caller graph for this function:

compare()

int compare ( const edge &  a, const edge &  b  )

inlinestatic

Definition at line 26 of file edgeI.H.

References Foam::constant::physicoChemical::b, and Pair::compare().

Referenced by Foam::operator!=(), Foam::operator==(), and syncTools::syncEdgeList().

Here is the call graph for this function:

Here is the caller graph for this function:

operator[]() [1/2]

Foam::label & operator[] ( const label  i )

inline

Definition at line 466 of file edgeI.H.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

operator[]() [2/2]

const Foam::label & operator[] ( const label  i ) const

inline

Definition at line 479 of file edgeI.H.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

hash_code()

unsigned hash_code ( unsigned  seed = 0 ) const

inline

Definition at line 284 of file edge.H.

References Pair::second().

Referenced by edge::hasher::operator()().

Here is the call graph for this function:

Here is the caller graph for this function:

insert() [6/7]

Foam::label insert ( InputIterator  begIter, InputIterator  endIter  )

inline

Definition at line 286 of file edgeI.H.

References insert().

Here is the call graph for this function:

insert() [7/7]

Foam::label insert ( const FixedList< label, N > &  list )

inline

Definition at line 315 of file edgeI.H.

References FixedList::begin(), FixedList::end(), and insert().

Here is the call graph for this function:

erase() [6/7]

Foam::label erase ( InputIterator  begIter, InputIterator  endIter  )

inline

Definition at line 355 of file edgeI.H.

References erase().

Here is the call graph for this function:

erase() [7/7]

Foam::label erase ( const FixedList< label, N > &  list )

inline

Definition at line 381 of file edgeI.H.

References FixedList::begin(), FixedList::end(), and erase().

Here is the call graph for this function:

second() [1/2]

const T& second

inlinenoexcept

Referenced by isoSurfaceTopo::interpolateTemplate(), isoSurfaceTopo::isoSurfaceTopo(), and slidingInterface::modifyMotionPoints().

Here is the caller graph for this function:

second() [2/2]

T& second

inlinenoexcept

Member Data Documentation

typeName

const char *const typeName = "edge"

static

Definition at line 67 of file edge.H.

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/meshes/meshShapes/edge/edge.H
• src/OpenFOAM/meshes/meshShapes/edge/edge.C
• src/OpenFOAM/meshes/meshShapes/edge/edgeI.H
