eddy Class Reference

Class to describe eddies for the turbulentDFSEMInletFvPatchVectorField boundary condition. More...

Public Member Functions
	eddy ()
	eddy (Istream &is)
	eddy (const label patchFaceI, const point &position0, const scalar x, const scalar sigmaX, const symmTensor &R, Random &rndGen)
	eddy (const eddy &e)
label	patchFaceI () const noexcept
const point &	position0 () const noexcept
scalar	x () const noexcept
const vector &	sigma () const noexcept
const vector &	alpha () const noexcept
const tensor &	Rpg () const noexcept
scalar	c1 () const noexcept
point	position (const vector &n) const
label	dir1 () const
vector	epsilon (Random &rndGen) const
scalar	volume () const
void	move (const scalar dx)
boundBox	bounds (const bool global=true) const
vector	uPrime (const point &xp, const vector &n) const
void	writeCentreOBJ (const vector &n, Ostream &os) const
label	writeSurfaceOBJ (const label pointOffset, const vector &n, Ostream &os) const
void	operator= (const eddy &e)

Static Public Attributes
static int	debug = 0

Friends
bool	operator== (const eddy &a, const eddy &b)
bool	operator!= (const eddy &a, const eddy &b)
Istream &	operator>> (Istream &is, eddy &e)
Ostream &	operator<< (Ostream &os, const eddy &e)

Detailed Description

Class to describe eddies for the turbulentDFSEMInletFvPatchVectorField boundary condition.

Source files

• eddy.H
• eddy.C
• eddyI.H
• eddyIO.C

Definition at line 65 of file eddy.H.

Constructor & Destructor Documentation

eddy() [1/4]

eddy

(

)

Definition at line 109 of file eddy.C.

eddy() [2/4]

eddy

(

Istream &

is

)

Definition at line 27 of file eddyIO.C.

References IOstream::check(), and FUNCTION_NAME.

Here is the call graph for this function:

eddy() [3/4]

eddy	(	const label	patchFaceI,
		const point &	position0,
		const scalar	x,
		const scalar	sigmaX,
		const symmTensor &	R,
		Random &	rndGen
	)

Definition at line 123 of file eddy.C.

References Foam::cmptAv(), Foam::cmptMin(), Foam::cmptProduct(), Foam::expressions::patchExpr::debug, Foam::constant::electromagnetic::e, Foam::eigenValues(), Foam::eigenVectors(), Foam::endl(), epsilon, forAll, found, lambda(), Foam::Pout, R, rndGen, Random::shuffle(), dimensioned::T(), and WarningInFunction.

Here is the call graph for this function:

eddy() [4/4]

eddy

(

const eddy &

e

)

Definition at line 208 of file eddy.C.

Member Function Documentation

patchFaceI()

Foam::label patchFaceI ( ) const

inlinenoexcept

Definition at line 35 of file eddyI.H.

position0()

const Foam::point & position0 ( ) const

inlinenoexcept

Definition at line 41 of file eddyI.H.

x()

Foam::scalar x ( ) const

inlinenoexcept

Definition at line 47 of file eddyI.H.

sigma()

const Foam::vector & sigma ( ) const

inlinenoexcept

Definition at line 53 of file eddyI.H.

alpha()

const Foam::vector & alpha ( ) const

inlinenoexcept

Definition at line 59 of file eddyI.H.

Rpg()

const Foam::tensor & Rpg ( ) const

inlinenoexcept

Definition at line 65 of file eddyI.H.

c1()

Foam::scalar c1 ( ) const

inlinenoexcept

Definition at line 71 of file eddyI.H.

position()

Foam::point position ( const vector &  n ) const

inline

Definition at line 77 of file eddyI.H.

References n.

dir1()

label dir1 ( ) const

inline

epsilon()

Foam::vector epsilon ( Random &  rndGen ) const

inline

Definition at line 83 of file eddyI.H.

References rndGen.

volume()

Foam::scalar volume ( ) const

inline

Definition at line 89 of file eddyI.H.

References Foam::cmptProduct(), and Foam::constant::mathematical::pi().

Here is the call graph for this function:

move()

void move ( const scalar  dx )

inline

Definition at line 95 of file eddyI.H.

bounds()

Foam::boundBox bounds ( const bool  global = true ) const

inline

Definition at line 101 of file eddyI.H.

References boundBox::max(), and boundBox::min().

Here is the call graph for this function:

uPrime()

Foam::vector uPrime	(	const point &	xp,
		const vector &	n
	)		const

Definition at line 223 of file eddy.C.

References Foam::cmptDivide(), Foam::cmptMultiply(), Foam::mag(), n, VectorSpace< Vector< scalar >, scalar, 3 >::one, rp(), and VectorSpace< Vector< scalar >, scalar, 3 >::zero.

Here is the call graph for this function:

writeCentreOBJ()

void writeCentreOBJ	(	const vector &	n,
		Ostream &	os
	)		const

Definition at line 248 of file eddy.C.

References n, Foam::nl, os(), and p.

Here is the call graph for this function:

writeSurfaceOBJ()

Foam::label writeSurfaceOBJ	(	const label	pointOffset,
		const vector &	n,
		Ostream &	os
	)		const

Definition at line 259 of file eddy.C.

References Foam::cos(), forAll, Tensor::I, n, Foam::nl, os(), p, Foam::constant::mathematical::pi(), s, Foam::sin(), Foam::sqr(), Foam::sqrt(), Foam::constant::mathematical::twoPi(), Tensor::vectorComponent(), and x.

Here is the call graph for this function:

operator=()

void operator=

(

const eddy &

e

)

Definition at line 44 of file eddyIO.C.

References Foam::constant::electromagnetic::e.

Friends And Related Function Documentation

operator==

bool operator== ( const eddy &  a, const eddy &  b  )

friend

Definition at line 222 of file eddy.H.

operator!=

bool operator!= ( const eddy &  a, const eddy &  b  )

friend

Definition at line 235 of file eddy.H.

operator>>

Istream& operator>> ( Istream &  is, eddy &  e  )

friend

operator<<

Ostream& operator<< ( Ostream &  os, const eddy &  e  )

friend

Member Data Documentation

debug

int debug = 0

static

Definition at line 143 of file eddy.H.

Referenced by turbulentDFSEMInletFvPatchVectorField::turbulentDFSEMInletFvPatchVectorField().

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fields/fvPatchFields/derived/turbulentDFSEMInlet/eddy/eddy.H
• src/finiteVolume/fields/fvPatchFields/derived/turbulentDFSEMInlet/eddy/eddy.C
• src/finiteVolume/fields/fvPatchFields/derived/turbulentDFSEMInlet/eddy/eddyI.H
• src/finiteVolume/fields/fvPatchFields/derived/turbulentDFSEMInlet/eddy/eddyIO.C
