velocityGroup Class Reference

This diameterModel is intended for use with a populationBalanceModel in order to simulate polydispersed bubbly or particulate flows. It can hold any number of sizeGroups from which the Sauter mean diameter is calculated. It can also be used as a diameterModel without a populationBalance and would then behave like a constantDiameter model. In this case, some arbitrary name must be entered for the populationBalance keyword. More...

Inheritance diagram for velocityGroup:

Collaboration diagram for velocityGroup:

Public Member Functions
	TypeName ("velocityGroup")
	velocityGroup (const dictionary &diameterProperties, const phaseModel &phase)
virtual	~velocityGroup ()
const word &	popBalName () const
const volScalarField &	f () const
const dimensionedScalar &	formFactor () const
const PtrList< sizeGroup > &	sizeGroups () const
const tmp< fv::convectionScheme< scalar > > &	mvConvection () const
const volScalarField &	dmdt () const
volScalarField &	dmdtRef ()
void	preSolve ()
void	postSolve ()
virtual bool	read (const dictionary &diameterProperties)
virtual tmp< volScalarField >	d () const
Public Member Functions inherited from diameterModel
	TypeName ("diameterModel")
	declareRunTimeSelectionTable (autoPtr, diameterModel, dictionary,(const dictionary &dict, const phaseModel &phase),(dict, phase))
	diameterModel (const dictionary &dict, const phaseModel &phase)
virtual	~diameterModel ()=default
	TypeName ("diameterModel")
	declareRunTimeSelectionTable (autoPtr, diameterModel, dictionary,(const dictionary &dict, const phaseModel &phase),(dict, phase))
	diameterModel (const dictionary &dict, const phaseModel &phase)
virtual	~diameterModel ()=default
const dictionary &	diameterProperties () const
const phaseModel &	phase () const
virtual void	correct ()
	TypeName ("diameterModel")
	declareRunTimeSelectionTable (autoPtr, diameterModel, dictionary,(const dictionary &dict, const phaseModel &phase),(dict, phase))
	diameterModel (const dictionary &dict, const phaseModel &phase)
virtual	~diameterModel ()=default
const dictionary &	diameterProperties () const
const phaseModel &	phase () const
virtual void	correct ()

Additional Inherited Members
Static Public Member Functions inherited from diameterModel
static autoPtr< diameterModel >	New (const dictionary &dict, const phaseModel &phase)
static autoPtr< diameterModel >	New (const dictionary &diameterProperties, const phaseModel &phase)
static autoPtr< diameterModel >	New (const dictionary &dict, const phaseModel &phase)
Protected Attributes inherited from diameterModel
const dictionary &	dict_
const phaseModel &	phase_
dictionary	diameterProperties_

Detailed Description

This diameterModel is intended for use with a populationBalanceModel in order to simulate polydispersed bubbly or particulate flows. It can hold any number of sizeGroups from which the Sauter mean diameter is calculated. It can also be used as a diameterModel without a populationBalance and would then behave like a constantDiameter model. In this case, some arbitrary name must be entered for the populationBalance keyword.

Usage

Property	Description
populationBalance	Name of the corresponding populationBalance
formFactor	Form factor for converting diameter into volume
sizeGroups	List of sizeGroups

Example

    diameterModel   velocityGroup;
    velocityGroupCoeffs
    {
        populationBalance    bubbles;

        formFactor      0.5235987756;

        sizeGroups
        (
            f0{d  1.00e-3; value 0;}
            f1{d  1.08e-3; value 0;}
            f2{d  1.16e-3; value 0.25;}
            f3{d  1.25e-3; value 0.5;}
            f4{d  1.36e-3; value 0.25;}
            f5{d  1.46e-3; value 0;}
            ...
        );
    }

See also

Foam::diameterModels::sizeGroup Foam::diameterModels::populationBalanceModel

Source files

• velocityGroup.H
• velocityGroup.C

Definition at line 103 of file velocityGroup.H.

Constructor & Destructor Documentation

velocityGroup()

velocityGroup	(	const dictionary &	diameterProperties,
		const phaseModel &	phase
	)

Definition at line 140 of file velocityGroup.C.

References Foam::constant::electromagnetic::e, Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::mag(), Foam::max(), Foam::min(), phaseModel::name(), and Foam::nl.

Here is the call graph for this function:

~velocityGroup()

~velocityGroup ( )

virtual

Definition at line 270 of file velocityGroup.C.

Member Function Documentation

TypeName()

TypeName

(

"velocityGroup"

)

popBalName()

const Foam::word & popBalName ( ) const

inline

Definition at line 24 of file velocityGroupI.H.

f()

const Foam::volScalarField & f ( ) const

inline

Definition at line 31 of file velocityGroupI.H.

formFactor()

const Foam::dimensionedScalar & formFactor ( ) const

inline

Definition at line 38 of file velocityGroupI.H.

Referenced by sizeDistribution::write().

Here is the caller graph for this function:

sizeGroups()

const Foam::PtrList< Foam::diameterModels::sizeGroup > & sizeGroups ( ) const

inline

Definition at line 45 of file velocityGroupI.H.

Referenced by phaseChange::addToDriftRate(), constantNucleation::correct(), wallBoiling::correct(), and phaseChange::correct().

Here is the caller graph for this function:

mvConvection()

const Foam::tmp< Foam::fv::convectionScheme< Foam::scalar > > & mvConvection ( ) const

inline

Definition at line 52 of file velocityGroupI.H.

Referenced by populationBalanceModel::solve().

Here is the caller graph for this function:

dmdt()

const Foam::volScalarField & dmdt ( ) const

inline

Definition at line 59 of file velocityGroupI.H.

Referenced by populationBalanceModel::solve().

Here is the caller graph for this function:

dmdtRef()

Foam::volScalarField & dmdtRef ( )

inline

Definition at line 65 of file velocityGroupI.H.

preSolve()

void preSolve

(

)

Definition at line 277 of file velocityGroup.C.

postSolve()

void postSolve

(

)

Definition at line 283 of file velocityGroup.C.

References Foam::endl(), Foam::Info, Foam::max(), Foam::min(), and phaseModel::name().

Here is the call graph for this function:

read()

bool read ( const dictionary &  diameterProperties )

virtual

Implements diameterModel.

Definition at line 316 of file velocityGroup.C.

References diameterModel::read().

Here is the call graph for this function:

d()

Foam::tmp< Foam::volScalarField > d ( ) const

virtual

Implements diameterModel.

Definition at line 325 of file velocityGroup.C.

---

The documentation for this class was generated from the following files:

• src/phaseSystemModels/reactingEuler/multiphaseSystem/diameterModels/velocityGroup/velocityGroup.H
• src/phaseSystemModels/reactingEuler/multiphaseSystem/diameterModels/velocityGroup/velocityGroup.C
• src/phaseSystemModels/reactingEuler/multiphaseSystem/diameterModels/velocityGroup/velocityGroupI.H
