Model of Lehr et al. (2002). The breakup rate is calculated by. More...

Inheritance diagram for LehrMilliesMewes:

Collaboration diagram for LehrMilliesMewes:

Public Member Functions
	TypeName ("LehrMilliesMewes")

	LehrMilliesMewes (const populationBalanceModel &popBal, const dictionary &dict)

virtual	~LehrMilliesMewes ()=default

virtual void	addToBinaryBreakupRate (volScalarField &binaryBreakupRate, const label i, const label j)

Public Member Functions inherited from binaryBreakupModel
	TypeName ("binaryBreakupModel")

	declareRunTimeSelectionTable (autoPtr, binaryBreakupModel, dictionary,(const populationBalanceModel &popBal, const dictionary &dict),(popBal, dict))

	binaryBreakupModel (const populationBalanceModel &popBal, const dictionary &dict)

autoPtr< binaryBreakupModel >	clone () const

virtual	~binaryBreakupModel ()=default

virtual void	correct ()

Additional Inherited Members
Static Public Member Functions inherited from binaryBreakupModel
static autoPtr< binaryBreakupModel >	New (const word &type, const populationBalanceModel &popBal, const dictionary &dict)

Protected Attributes inherited from binaryBreakupModel
const populationBalanceModel &	popBal_

Detailed Description

Model of Lehr et al. (2002). The breakup rate is calculated by.

$0.5 d_j^{*^{5/3}} \mathrm{exp}\left(-\frac{\sqrt{2}}{d_j^{*^{3}}}\right) \frac{6}{\pi^{3/2}d_i^{*^{3}}} \mathrm{exp} \left( - \frac{9}{4}\left[\mathrm{ln}\left(2^{2/5} d_i^{*}\right)\right]^{2} \right) \left( 1 + \mathrm{erf} \left[ \frac{3}{2}\mathrm{ln} \left(2^{1/15} d_j^{*}\right) \right] \right)^{-1} \frac{1}{L^{3}T}$

with the time scale

$T = \left(\frac{\sigma}{\rho_c}\right)^{2/5} \frac{1}{\epsilon_c^{3/5}}$

the dimensionless diameter

$d^{*} = \frac{d}{L}$

and the length scale

$L = \left(\frac{\sigma}{\rho_c}\right)^{3/5} \frac{1}{\epsilon_c^{2/5}}$

$\rho_c$	=	Density of continuous phase [kg/m3]
$\sigma$	=	Surface tension [N/m]
$\epsilon_c$	=	Continuous phase turbulent dissipation rate [m2/s3]
	=	Diameter of daughter bubble i [m]
	=	Diameter of mother bubble j [m]

References:

        Lehr, F., Millies, M., & Mewes, D. (2002).
        Bubble‐size distributions and flow fields in bubble columns.
        AIChE Journal, 48(11), 2426-2443.
        Eq. 12-16, p. 2429-2430.

Source files

Definition at line 121 of file LehrMilliesMewes.H.

Constructor & Destructor Documentation

◆ LehrMilliesMewes()

LehrMilliesMewes	(	const populationBalanceModel &	popBal,
		const dictionary &	dict
	)

Definition at line 50 of file LehrMilliesMewes.C.

◆ ~LehrMilliesMewes()

virtual ~LehrMilliesMewes ( )

virtualdefault

Member Function Documentation

◆ TypeName()

TypeName ( "LehrMilliesMewes" )

◆ addToBinaryBreakupRate()

void addToBinaryBreakupRate	(	volScalarField &	binaryBreakupRate,
		const label	i,
		const label	j
	)

virtual

Implements binaryBreakupModel.

Definition at line 63 of file LehrMilliesMewes.C.

References sizeGroup::d(), Foam::dimLength, Foam::erf(), Foam::exp(), L(), Foam::log(), Foam::max(), sizeGroup::phase(), Foam::constant::mathematical::pi(), Foam::pow(), Foam::pow3(), phaseModel::rho(), Foam::sqr(), Foam::sqrt(), and T.

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/phaseSystemModels/reactingEuler/multiphaseSystem/populationBalanceModel/binaryBreakupModels/LehrMilliesMewes/LehrMilliesMewes.H
src/phaseSystemModels/reactingEuler/multiphaseSystem/populationBalanceModel/binaryBreakupModels/LehrMilliesMewes/LehrMilliesMewes.C
