singleProcessorFaceSets Class Reference

Constraint to keep all cells connected to face or point of faceSet on a single processor. More...

Inheritance diagram for singleProcessorFaceSets:

Collaboration diagram for singleProcessorFaceSets:

Public Member Functions
	TypeName ("singleProcessorFaceSets")
	singleProcessorFaceSets (const dictionary &dict)
	singleProcessorFaceSets (const List< Tuple2< word, label >> &setNameAndProcs)
	singleProcessorFaceSets (Istream &is)
virtual	~singleProcessorFaceSets ()=default
virtual void	add (const polyMesh &mesh, boolList &blockedFace, PtrList< labelList > &specifiedProcessorFaces, labelList &specifiedProcessor, List< labelPair > &explicitConnections) const
virtual void	apply (const polyMesh &mesh, const boolList &blockedFace, const PtrList< labelList > &specifiedProcessorFaces, const labelList &specifiedProcessor, const List< labelPair > &explicitConnections, labelList &decomposition) const
Public Member Functions inherited from decompositionConstraint
	TypeName ("decompositionConstraint")
	declareRunTimeSelectionTable (autoPtr, decompositionConstraint, dictionary,(const dictionary &dict),(dict))
	decompositionConstraint (const dictionary &constraintDict)
	decompositionConstraint (const dictionary &constraintDict, const word &modelType)
virtual	~decompositionConstraint ()=default

Additional Inherited Members
Static Public Member Functions inherited from decompositionConstraint
static autoPtr< decompositionConstraint >	New (const dictionary &constraintDict)
static autoPtr< decompositionConstraint >	New (const dictionary &constraintDict, const word &modelType)
Protected Member Functions inherited from decompositionConstraint
void	getMinBoundaryValue (const polyMesh &mesh, const labelList &decomposition, labelList &destProc) const
	decompositionConstraint (const decompositionConstraint &)=delete
void	operator= (const decompositionConstraint &)=delete
Protected Attributes inherited from decompositionConstraint
dictionary	coeffDict_

Detailed Description

Constraint to keep all cells connected to face or point of faceSet on a single processor.

Dictionary parameters

Property	Description	Required	Default
type	singleProcessorFaceSets	yes
sets	List of sets and processers	yes

Example,

    constraints
    {
        procs
        {
            type    singleProcessorFaceSets;
            sets
            (
                (faceSet1   0)
                (faceSet5   12)
                (faceSet25 510)
            );
        }
    }

Source files

• singleProcessorFaceSetsConstraint.H
• singleProcessorFaceSetsConstraint.C

Definition at line 90 of file singleProcessorFaceSetsConstraint.H.

Constructor & Destructor Documentation

singleProcessorFaceSets() [1/3]

singleProcessorFaceSets ( const dictionary &  dict )

explicit

Definition at line 61 of file singleProcessorFaceSetsConstraint.C.

singleProcessorFaceSets() [2/3]

singleProcessorFaceSets ( const List< Tuple2< word, label >> &  setNameAndProcs )

explicit

Definition at line 83 of file singleProcessorFaceSetsConstraint.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), Foam::Info, and Foam::type().

Here is the call graph for this function:

singleProcessorFaceSets() [3/3]

singleProcessorFaceSets ( Istream &  is )

explicit

Definition at line 102 of file singleProcessorFaceSetsConstraint.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), Foam::Info, and Foam::type().

Here is the call graph for this function:

~singleProcessorFaceSets()

virtual ~singleProcessorFaceSets ( )

virtualdefault

Member Function Documentation

TypeName()

TypeName

(

"singleProcessorFaceSets"

)

add()

void add ( const polyMesh &  mesh, boolList &  blockedFace, PtrList< labelList > &  specifiedProcessorFaces, labelList &  specifiedProcessor, List< labelPair > &  explicitConnections  ) const

virtual

Implements decompositionConstraint.

Definition at line 122 of file singleProcessorFaceSetsConstraint.C.

References PtrList::append(), List::append(), Foam::expressions::patchExpr::debug, Foam::endl(), f(), forAll, Foam::Info, mesh, pFaces, Foam::reduce(), List::resize(), syncTools::syncFaceList(), syncTools::syncPointList(), Foam::type(), and Foam::Zero.

Here is the call graph for this function:

apply()

void apply ( const polyMesh &  mesh, const boolList &  blockedFace, const PtrList< labelList > &  specifiedProcessorFaces, const labelList &  specifiedProcessor, const List< labelPair > &  explicitConnections, labelList &  decomposition  ) const

virtual

Reimplemented from decompositionConstraint.

Definition at line 245 of file singleProcessorFaceSetsConstraint.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), f(), forAll, Foam::Info, mesh, pFaces, Foam::reduce(), Foam::BitOps::set(), syncTools::syncPointList(), and Foam::type().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/parallel/decompose/decompositionMethods/decompositionConstraints/singleProcessorFaceSets/singleProcessorFaceSetsConstraint.H
• src/parallel/decompose/decompositionMethods/decompositionConstraints/singleProcessorFaceSets/singleProcessorFaceSetsConstraint.C
