preservePatches Class Reference

Constraint to keep owner and neighbour of (cyclic) patch on same processor. More...

Inheritance diagram for preservePatches:

Collaboration diagram for preservePatches:

Public Member Functions
	TypeName ("preservePatches")
	preservePatches (const dictionary &dict)
	preservePatches (const UList< wordRe > &patches)
virtual	~preservePatches ()=default
virtual void	add (const polyMesh &mesh, boolList &blockedFace, PtrList< labelList > &specifiedProcessorFaces, labelList &specifiedProcessor, List< labelPair > &explicitConnections) const
virtual void	apply (const polyMesh &mesh, const boolList &blockedFace, const PtrList< labelList > &specifiedProcessorFaces, const labelList &specifiedProcessor, const List< labelPair > &explicitConnections, labelList &decomposition) const
Public Member Functions inherited from decompositionConstraint
	TypeName ("decompositionConstraint")
	declareRunTimeSelectionTable (autoPtr, decompositionConstraint, dictionary,(const dictionary &dict),(dict))
	decompositionConstraint (const dictionary &constraintDict)
	decompositionConstraint (const dictionary &constraintDict, const word &modelType)
virtual	~decompositionConstraint ()=default

Additional Inherited Members
Static Public Member Functions inherited from decompositionConstraint
static autoPtr< decompositionConstraint >	New (const dictionary &constraintDict)
static autoPtr< decompositionConstraint >	New (const dictionary &constraintDict, const word &modelType)
Protected Member Functions inherited from decompositionConstraint
void	getMinBoundaryValue (const polyMesh &mesh, const labelList &decomposition, labelList &destProc) const
	decompositionConstraint (const decompositionConstraint &)=delete
void	operator= (const decompositionConstraint &)=delete
Protected Attributes inherited from decompositionConstraint
dictionary	coeffDict_

Detailed Description

Constraint to keep owner and neighbour of (cyclic) patch on same processor.

Dictionary parameters

Property	Description	Required	Default
type	preservePatches	yes
patches	List of patch names or regexs	yes

Source files

• preservePatchesConstraint.H
• preservePatchesConstraint.C

Definition at line 74 of file preservePatchesConstraint.H.

Constructor & Destructor Documentation

preservePatches() [1/2]

preservePatches ( const dictionary &  dict )

explicit

Definition at line 47 of file preservePatchesConstraint.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), and Foam::Info.

Here is the call graph for this function:

preservePatches() [2/2]

preservePatches ( const UList< wordRe > &  patches )

explicit

Definition at line 66 of file preservePatchesConstraint.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), and Foam::Info.

Here is the call graph for this function:

~preservePatches()

virtual ~preservePatches ( )

virtualdefault

Member Function Documentation

TypeName()

TypeName

(

"preservePatches"

)

add()

void add ( const polyMesh &  mesh, boolList &  blockedFace, PtrList< labelList > &  specifiedProcessorFaces, labelList &  specifiedProcessor, List< labelPair > &  explicitConnections  ) const

virtual

Implements decompositionConstraint.

Definition at line 87 of file preservePatchesConstraint.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), forAll, Foam::Info, mesh, polyBoundaryMesh::patchSet(), reduce(), List::resize(), and polyPatch::start().

Here is the call graph for this function:

apply()

void apply ( const polyMesh &  mesh, const boolList &  blockedFace, const PtrList< labelList > &  specifiedProcessorFaces, const labelList &  specifiedProcessor, const List< labelPair > &  explicitConnections, labelList &  decomposition  ) const

virtual

Reimplemented from decompositionConstraint.

Definition at line 130 of file preservePatchesConstraint.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), polyPatch::faceCells(), forAll, Foam::Info, mesh, polyPatch::offset(), polyBoundaryMesh::patchSet(), and reduce().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/parallel/decompose/decompositionMethods/decompositionConstraints/preservePatches/preservePatchesConstraint.H
• src/parallel/decompose/decompositionMethods/decompositionConstraints/preservePatches/preservePatchesConstraint.C
