preserveFaceZones Class Reference

Constraint to keep/move owner and neighbour of faceZone onto same processor. More...

Inheritance diagram for preserveFaceZones:

Collaboration diagram for preserveFaceZones:

Public Member Functions
	TypeName ("preserveFaceZones")
	preserveFaceZones (const dictionary &dict)
	preserveFaceZones (const UList< wordRe > &zones)
virtual	~preserveFaceZones ()=default
virtual void	add (const polyMesh &mesh, boolList &blockedFace, PtrList< labelList > &specifiedProcessorFaces, labelList &specifiedProcessor, List< labelPair > &explicitConnections) const
virtual void	apply (const polyMesh &mesh, const boolList &blockedFace, const PtrList< labelList > &specifiedProcessorFaces, const labelList &specifiedProcessor, const List< labelPair > &explicitConnections, labelList &decomposition) const
Public Member Functions inherited from decompositionConstraint
	TypeName ("decompositionConstraint")
	declareRunTimeSelectionTable (autoPtr, decompositionConstraint, dictionary,(const dictionary &dict),(dict))
	decompositionConstraint (const dictionary &constraintDict)
	decompositionConstraint (const dictionary &constraintDict, const word &modelType)
virtual	~decompositionConstraint ()=default

Additional Inherited Members
Static Public Member Functions inherited from decompositionConstraint
static autoPtr< decompositionConstraint >	New (const dictionary &constraintDict)
static autoPtr< decompositionConstraint >	New (const dictionary &constraintDict, const word &modelType)
Protected Member Functions inherited from decompositionConstraint
void	getMinBoundaryValue (const polyMesh &mesh, const labelList &decomposition, labelList &destProc) const
	decompositionConstraint (const decompositionConstraint &)=delete
void	operator= (const decompositionConstraint &)=delete
Protected Attributes inherited from decompositionConstraint
dictionary	coeffDict_

Detailed Description

Constraint to keep/move owner and neighbour of faceZone onto same processor.

Dictionary parameters

Property	Description	Required	Default
type	preserveFaceZones	yes
zones	List of face zone names or regexs	yes

Source files

• preserveFaceZonesConstraint.H
• preserveFaceZonesConstraint.C

Definition at line 72 of file preserveFaceZonesConstraint.H.

Constructor & Destructor Documentation

preserveFaceZones() [1/2]

preserveFaceZones ( const dictionary &  dict )

explicit

Definition at line 47 of file preserveFaceZonesConstraint.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), and Foam::Info.

Here is the call graph for this function:

preserveFaceZones() [2/2]

preserveFaceZones ( const UList< wordRe > &  zones )

explicit

Definition at line 64 of file preserveFaceZonesConstraint.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), and Foam::Info.

Here is the call graph for this function:

~preserveFaceZones()

virtual ~preserveFaceZones ( )

virtualdefault

Member Function Documentation

TypeName()

TypeName

(

"preserveFaceZones"

)

add()

void add ( const polyMesh &  mesh, boolList &  blockedFace, PtrList< labelList > &  specifiedProcessorFaces, labelList &  specifiedProcessor, List< labelPair > &  explicitConnections  ) const

virtual

Implements decompositionConstraint.

Definition at line 83 of file preserveFaceZonesConstraint.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), Foam::Info, mesh, ZoneMesh::names(), reduce(), List::setSize(), and zoneIDs.

Here is the call graph for this function:

apply()

void apply ( const polyMesh &  mesh, const boolList &  blockedFace, const PtrList< labelList > &  specifiedProcessorFaces, const labelList &  specifiedProcessor, const List< labelPair > &  explicitConnections, labelList &  decomposition  ) const

virtual

Reimplemented from decompositionConstraint.

Definition at line 124 of file preserveFaceZonesConstraint.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), Foam::Info, mesh, ZoneMesh::names(), reduce(), and zoneIDs.

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/parallel/decompose/decompositionMethods/decompositionConstraints/preserveFaceZones/preserveFaceZonesConstraint.H
• src/parallel/decompose/decompositionMethods/decompositionConstraints/preserveFaceZones/preserveFaceZonesConstraint.C
