cylindricalInletVelocityFvPatchVectorField Class Reference

This boundary condition describes an inlet vector boundary condition in cylindrical coordinates given a central axis, central point, rpm, axial and radial velocity. More...

Inheritance diagram for cylindricalInletVelocityFvPatchVectorField:

Collaboration diagram for cylindricalInletVelocityFvPatchVectorField:

Public Member Functions
	TypeName ("cylindricalInletVelocity")
	cylindricalInletVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &)
	cylindricalInletVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	cylindricalInletVelocityFvPatchVectorField (const cylindricalInletVelocityFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)
	cylindricalInletVelocityFvPatchVectorField (const cylindricalInletVelocityFvPatchVectorField &)
virtual tmp< fvPatchVectorField >	clone () const
	cylindricalInletVelocityFvPatchVectorField (const cylindricalInletVelocityFvPatchVectorField &, const DimensionedField< vector, volMesh > &)
virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Detailed Description

This boundary condition describes an inlet vector boundary condition in cylindrical coordinates given a central axis, central point, rpm, axial and radial velocity.

Usage

Property	Description	Required	Default value
axis	axis of rotation	yes
origin	origin of rotation	yes
axialVelocity	axial velocity profile [m/s]	yes
radialVelocity	radial velocity profile [m/s]	yes
rpm	rotational speed (revolutions per minute)	yes

Example of the boundary condition specification:

    <patchName>
    {
        type            cylindricalInletVelocity;
        axis            (0 0 1);
        origin          (0 0 0);
        axialVelocity   constant 30;
        radialVelocity  constant -10;
        rpm             constant 100;
    }

Note

The axialVelocity, radialVelocity and rpm entries are Function1 types, able to describe time varying functions. The example above gives the usage for supplying constant values.

See also

Foam::fixedValueFvPatchField Foam::Function1Types

Source files

• cylindricalInletVelocityFvPatchVectorField.H
• cylindricalInletVelocityFvPatchVectorField.C

Definition at line 113 of file cylindricalInletVelocityFvPatchVectorField.H.

Constructor & Destructor Documentation

cylindricalInletVelocityFvPatchVectorField() [1/5]

cylindricalInletVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 33 of file cylindricalInletVelocityFvPatchVectorField.C.

Referenced by cylindricalInletVelocityFvPatchVectorField::clone().

Here is the caller graph for this function:

cylindricalInletVelocityFvPatchVectorField() [2/5]

cylindricalInletVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 67 of file cylindricalInletVelocityFvPatchVectorField.C.

cylindricalInletVelocityFvPatchVectorField() [3/5]

cylindricalInletVelocityFvPatchVectorField	(	const cylindricalInletVelocityFvPatchVectorField &	ptf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 49 of file cylindricalInletVelocityFvPatchVectorField.C.

cylindricalInletVelocityFvPatchVectorField() [4/5]

cylindricalInletVelocityFvPatchVectorField

(

const cylindricalInletVelocityFvPatchVectorField &

ptf

)

Definition at line 87 of file cylindricalInletVelocityFvPatchVectorField.C.

cylindricalInletVelocityFvPatchVectorField() [5/5]

cylindricalInletVelocityFvPatchVectorField	(	const cylindricalInletVelocityFvPatchVectorField &	ptf,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 102 of file cylindricalInletVelocityFvPatchVectorField.C.

Member Function Documentation

TypeName()

TypeName

(

"cylindricalInletVelocity"

)

clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const

inlinevirtual

Definition at line 176 of file cylindricalInletVelocityFvPatchVectorField.H.

References cylindricalInletVelocityFvPatchVectorField::cylindricalInletVelocityFvPatchVectorField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF ) const

inlinevirtual

Definition at line 193 of file cylindricalInletVelocityFvPatchVectorField.H.

References cylindricalInletVelocityFvPatchVectorField::cylindricalInletVelocityFvPatchVectorField().

Here is the call graph for this function:

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 118 of file cylindricalInletVelocityFvPatchVectorField.C.

References Foam::mag(), Foam::operator==(), Foam::foamVersion::patch, Foam::rpmToRads(), and fvPatchField< Type >::updateCoeffs().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 146 of file cylindricalInletVelocityFvPatchVectorField.C.

References os(), fvPatchField::write(), and Ostream::writeEntry().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fields/fvPatchFields/derived/cylindricalInletVelocity/cylindricalInletVelocityFvPatchVectorField.H
• src/finiteVolume/fields/fvPatchFields/derived/cylindricalInletVelocity/cylindricalInletVelocityFvPatchVectorField.C
