cyclicACMIGAMGInterfaceField Class Reference

GAMG agglomerated cyclic interface for Arbitrarily Coupled Mesh Interface (ACMI) fields. More...

Inheritance diagram for cyclicACMIGAMGInterfaceField:

Collaboration diagram for cyclicACMIGAMGInterfaceField:

Public Member Functions
	TypeName ("cyclicACMI")
	cyclicACMIGAMGInterfaceField (const GAMGInterface &GAMGCp, const lduInterfaceField &fineInterfaceField)
	cyclicACMIGAMGInterfaceField (const GAMGInterface &GAMGCp, const bool doTransform, const int rank)
virtual	~cyclicACMIGAMGInterfaceField ()
label	size () const
virtual void	updateInterfaceMatrix (solveScalarField &result, const bool add, const lduAddressing &lduAddr, const label patchId, const solveScalarField &psiInternal, const scalarField &coeffs, const direction cmpt, const Pstream::commsTypes commsType) const
virtual bool	doTransform () const
virtual const tensorField &	forwardT () const
virtual const tensorField &	reverseT () const
virtual int	rank () const
Public Member Functions inherited from GAMGInterfaceField
	TypeName ("GAMGInterfaceField")
	declareRunTimeSelectionTable (autoPtr, GAMGInterfaceField, lduInterfaceField,(const GAMGInterface &GAMGCp, const lduInterfaceField &fineInterface),(GAMGCp, fineInterface))
	declareRunTimeSelectionTable (autoPtr, GAMGInterfaceField, lduInterface,(const GAMGInterface &GAMGCp, const bool doTransform, const int rank),(GAMGCp, doTransform, rank))
	GAMGInterfaceField (const GAMGInterface &GAMGCp, const lduInterfaceField &)
	GAMGInterfaceField (const GAMGInterface &GAMGCp, const bool doTransform, const int rank)
const GAMGInterface &	interface () const
Public Member Functions inherited from lduInterfaceField
	TypeName ("lduInterfaceField")
	lduInterfaceField (const lduInterface &patch)
virtual	~lduInterfaceField ()=default
const lduInterface &	interface () const
virtual const word &	interfaceFieldType () const
bool	updatedMatrix () const
bool &	updatedMatrix ()
virtual bool	ready () const
virtual void	initInterfaceMatrixUpdate (solveScalarField &result, const bool add, const lduAddressing &, const label interfacei, const solveScalarField &psiInternal, const scalarField &coeffs, const direction cmpt, const Pstream::commsTypes commsType) const
template<class Type >
void	addToInternalField (Field< Type > &result, const bool add, const labelUList &faceCells, const scalarField &coeffs, const Field< Type > &vals) const
Public Member Functions inherited from cyclicACMILduInterfaceField
	TypeName ("cyclicACMILduInterfaceField")
	cyclicACMILduInterfaceField ()
virtual	~cyclicACMILduInterfaceField ()
template<class Type >
void	transformCoupleField (Field< Type > &f) const
void	transformCoupleField (solveScalarField &psiInternal, const direction cmpt) const
Public Member Functions inherited from cyclicAMILduInterfaceField
	TypeName ("cyclicAMILduInterfaceField")
	cyclicAMILduInterfaceField ()
virtual	~cyclicAMILduInterfaceField ()
template<class Type >
void	transformCoupleField (Field< Type > &f) const
void	transformCoupleField (solveScalarField &psiInternal, const direction cmpt) const

Additional Inherited Members
Static Public Member Functions inherited from GAMGInterfaceField
static autoPtr< GAMGInterfaceField >	New (const GAMGInterface &GAMGCp, const lduInterfaceField &fineInterface)
static autoPtr< GAMGInterfaceField >	New (const GAMGInterface &GAMGCp, const bool doTransform, const int rank)

Detailed Description

GAMG agglomerated cyclic interface for Arbitrarily Coupled Mesh Interface (ACMI) fields.

Source files

• cyclicACMIGAMGInterfaceField.H
• cyclicACMIGAMGInterfaceField.C

Definition at line 50 of file cyclicACMIGAMGInterfaceField.H.

Constructor & Destructor Documentation

cyclicACMIGAMGInterfaceField() [1/2]

cyclicACMIGAMGInterfaceField	(	const GAMGInterface &	GAMGCp,
		const lduInterfaceField &	fineInterfaceField
	)

Definition at line 49 of file cyclicACMIGAMGInterfaceField.C.

References p.

cyclicACMIGAMGInterfaceField() [2/2]

cyclicACMIGAMGInterfaceField	(	const GAMGInterface &	GAMGCp,
		const bool	doTransform,
		const int	rank
	)

Definition at line 68 of file cyclicACMIGAMGInterfaceField.C.

~cyclicACMIGAMGInterfaceField()

~cyclicACMIGAMGInterfaceField ( )

virtual

Definition at line 83 of file cyclicACMIGAMGInterfaceField.C.

Member Function Documentation

TypeName()

TypeName

(

"cyclicACMI"

)

size()

label size ( ) const

inline

Definition at line 112 of file cyclicACMIGAMGInterfaceField.H.

References GAMGInterface::size().

Here is the call graph for this function:

updateInterfaceMatrix()

void updateInterfaceMatrix ( solveScalarField &  result, const bool  add, const lduAddressing &  lduAddr, const label  patchId, const solveScalarField &  psiInternal, const scalarField &  coeffs, const direction  cmpt, const Pstream::commsTypes  commsType  ) const

virtual

Implements lduInterfaceField.

Definition at line 90 of file cyclicACMIGAMGInterfaceField.C.

References Foam::add(), lduAddressing::patchAddr(), and patchId().

Here is the call graph for this function:

doTransform()

virtual bool doTransform ( ) const

inlinevirtual

Implements cyclicAMILduInterfaceField.

Definition at line 137 of file cyclicACMIGAMGInterfaceField.H.

forwardT()

virtual const tensorField& forwardT ( ) const

inlinevirtual

Implements cyclicAMILduInterfaceField.

Definition at line 143 of file cyclicACMIGAMGInterfaceField.H.

References cyclicACMIGAMGInterface::forwardT().

Here is the call graph for this function:

reverseT()

virtual const tensorField& reverseT ( ) const

inlinevirtual

Implements cyclicAMILduInterfaceField.

Definition at line 149 of file cyclicACMIGAMGInterfaceField.H.

References cyclicACMIGAMGInterface::reverseT().

Here is the call graph for this function:

rank()

virtual int rank ( ) const

inlinevirtual

Implements cyclicAMILduInterfaceField.

Definition at line 155 of file cyclicACMIGAMGInterfaceField.H.

---

The documentation for this class was generated from the following files:

• src/meshTools/AMIInterpolation/GAMG/interfaceFields/cyclicACMIGAMGInterfaceField/cyclicACMIGAMGInterfaceField.H
• src/meshTools/AMIInterpolation/GAMG/interfaceFields/cyclicACMIGAMGInterfaceField/cyclicACMIGAMGInterfaceField.C
