This boundary condition enforces a cyclic condition between a pair of boundaries, whereby communication between the patches is performed using an arbitrarily coupled mesh interface (ACMI) interpolation. More...

Inheritance diagram for cyclicACMIFvPatchField< Type >:

[legend]

Collaboration diagram for cyclicACMIFvPatchField< Type >:

[legend]

Public Member Functions
	TypeName (cyclicACMIFvPatch::typeName_())

	cyclicACMIFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

	cyclicACMIFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

	cyclicACMIFvPatchField (const cyclicACMIFvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

	cyclicACMIFvPatchField (const cyclicACMIFvPatchField< Type > &)

virtual tmp< fvPatchField< Type > >	clone () const

	cyclicACMIFvPatchField (const cyclicACMIFvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< fvPatchField< Type > >	clone (const DimensionedField< Type, volMesh > &iF) const

const cyclicACMIFvPatch &	cyclicACMIPatch () const

virtual bool	coupled () const

virtual bool	fixesValue () const

virtual tmp< Field< Type > >	patchNeighbourField () const

const cyclicACMIFvPatchField< Type > &	neighbourPatchField () const

const fvPatchField< Type > &	nonOverlapPatchField () const

virtual void	updateInterfaceMatrix (solveScalarField &result, const bool add, const lduAddressing &lduAddr, const label patchId, const solveScalarField &psiInternal, const scalarField &coeffs, const direction cmpt, const Pstream::commsTypes commsType) const

virtual void	updateInterfaceMatrix (Field< Type > &, const bool add, const lduAddressing &lduAddr, const label patchId, const Field< Type > &, const scalarField &, const Pstream::commsTypes commsType) const

virtual void	manipulateMatrix (fvMatrix< Type > &matrix)

virtual void	manipulateMatrix (fvMatrix< Type > &m, const label iMatrix, const direction cmpt)

virtual void	updateCoeffs ()

virtual bool	doTransform () const

virtual const tensorField &	forwardT () const

virtual const tensorField &	reverseT () const

virtual int	rank () const

virtual void	write (Ostream &os) const

Public Member Functions inherited from cyclicACMILduInterfaceField
	TypeName ("cyclicACMILduInterfaceField")

	cyclicACMILduInterfaceField ()

virtual	~cyclicACMILduInterfaceField ()

template<class Type >
void	transformCoupleField (Field< Type > &f) const

void	transformCoupleField (solveScalarField &psiInternal, const direction cmpt) const

Public Member Functions inherited from cyclicAMILduInterfaceField
	TypeName ("cyclicAMILduInterfaceField")

	cyclicAMILduInterfaceField ()

virtual	~cyclicAMILduInterfaceField ()

template<class Type >
void	transformCoupleField (Field< Type > &f) const

void	transformCoupleField (solveScalarField &psiInternal, const direction cmpt) const

Public Member Functions inherited from coupledFvPatchField< Type >
	TypeName (coupledFvPatch::typeName_())

	coupledFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

	coupledFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Field< Type > &)

	coupledFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &, const bool valueRequired=true)

	coupledFvPatchField (const coupledFvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

	coupledFvPatchField (const coupledFvPatchField< Type > &)

	coupledFvPatchField (const coupledFvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< Field< Type > >	snGrad (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > >	snGrad () const

virtual void	initEvaluate (const Pstream::commsTypes commsType)

virtual void	evaluate (const Pstream::commsTypes commsType)

virtual tmp< Field< Type > >	valueInternalCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< Type > >	valueBoundaryCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< Type > >	gradientInternalCoeffs (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > >	gradientInternalCoeffs () const

virtual tmp< Field< Type > >	gradientBoundaryCoeffs (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > >	gradientBoundaryCoeffs () const

Public Member Functions inherited from LduInterfaceField< Type >
	TypeName ("LduInterfaceField")

	LduInterfaceField (const lduInterface &patch)

virtual	~LduInterfaceField ()=default

virtual void	initInterfaceMatrixUpdate (Field< Type > &, const bool add, const lduAddressing &, const label interfacei, const Field< Type > &, const scalarField &, const Pstream::commsTypes commsType) const

virtual void	initInterfaceMatrixUpdate (solveScalarField &result, const bool add, const lduAddressing &, const label interfacei, const solveScalarField &psiInternal, const scalarField &coeffs, const direction cmpt, const Pstream::commsTypes commsType) const

virtual void	updateInterfaceMatrix (solveScalarField &result, const bool add, const lduAddressing &, const label interfacei, const solveScalarField &psiInternal, const scalarField &coeffs, const direction cmpt, const Pstream::commsTypes commsType) const=0

Public Member Functions inherited from lduInterfaceField
	TypeName ("lduInterfaceField")

	lduInterfaceField (const lduInterface &patch)

virtual	~lduInterfaceField ()=default

const lduInterface &	interface () const

virtual const word &	interfaceFieldType () const

bool	updatedMatrix () const

bool &	updatedMatrix ()

virtual bool	ready () const

virtual void	initInterfaceMatrixUpdate (solveScalarField &result, const bool add, const lduAddressing &, const label interfacei, const solveScalarField &psiInternal, const scalarField &coeffs, const direction cmpt, const Pstream::commsTypes commsType) const

template<class Type >
void	addToInternalField (Field< Type > &result, const bool add, const labelUList &faceCells, const scalarField &coeffs, const Field< Type > &vals) const

Public Member Functions inherited from fvPatchField< Type >
	TypeName ("fvPatchField")

	declareRunTimeSelectionTable (tmp, fvPatchField, patch,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF),(p, iF))

	declareRunTimeSelectionTable (tmp, fvPatchField, patchMapper,(const fvPatchField< Type > &ptf, const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const fvPatchFieldMapper &m),(dynamic_cast< const fvPatchFieldType & >(ptf), p, iF, m))

	declareRunTimeSelectionTable (tmp, fvPatchField, dictionary,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const dictionary &dict),(p, iF, dict))

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Type &value)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const word &patchType)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Field< Type > &)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &, const bool valueRequired=true)

	fvPatchField (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

	fvPatchField (const fvPatchField< Type > &)

	fvPatchField (const fvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< fvPatchField< Type > >	clone () const

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatch &p)

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &pf)

virtual	~fvPatchField ()=default

bool	useImplicit () const noexcept

bool	useImplicit (bool on) noexcept

virtual bool	fixesValue () const

virtual bool	assignable () const

virtual bool	coupled () const

const objectRegistry &	db () const

const fvPatch &	patch () const

const DimensionedField< Type, volMesh > &	internalField () const

const Field< Type > &	primitiveField () const

const word &	patchType () const

word &	patchType ()

bool	updated () const

bool	manipulatedMatrix () const

virtual void	autoMap (const fvPatchFieldMapper &)

virtual void	rmap (const fvPatchField< Type > &, const labelList &)

virtual tmp< Field< Type > >	snGrad () const

virtual void	updateWeightedCoeffs (const scalarField &weights)

virtual tmp< Field< Type > >	patchInternalField () const

virtual void	patchInternalField (Field< Type > &) const

virtual tmp< Field< Type > >	patchNeighbourField () const

virtual tmp< Field< Type > >	valueInternalCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > >	valueBoundaryCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > >	gradientInternalCoeffs () const

virtual tmp< Field< Type > >	gradientBoundaryCoeffs () const

virtual void	manipulateMatrix (fvMatrix< Type > &matrix, const scalarField &weights)

void	check (const fvPatchField< Type > &) const

virtual void	operator= (const UList< Type > &)

virtual void	operator= (const fvPatchField< Type > &)

virtual void	operator= (const Type &)

virtual void	operator+= (const fvPatchField< Type > &)

virtual void	operator+= (const Field< Type > &)

virtual void	operator+= (const Type &)

virtual void	operator-= (const fvPatchField< Type > &)

virtual void	operator-= (const Field< Type > &)

virtual void	operator-= (const Type &)

virtual void	operator*= (const fvPatchField< scalar > &)

virtual void	operator*= (const Field< scalar > &)

virtual void	operator*= (const scalar)

virtual void	operator/= (const fvPatchField< scalar > &)

virtual void	operator/= (const Field< scalar > &)

virtual void	operator/= (const scalar)

virtual void	operator== (const fvPatchField< Type > &)

virtual void	operator== (const Field< Type > &)

virtual void	operator== (const Type &)

Additional Inherited Members
Public Types inherited from fvPatchField< Type >
typedef fvPatch	Patch

typedef calculatedFvPatchField< Type >	Calculated

Static Public Member Functions inherited from fvPatchField< Type >
static tmp< fvPatchField< Type > >	New (const word &, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > >	New (const word &, const word &actualPatchType, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > >	New (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

static tmp< fvPatchField< Type > >	New (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatch &)

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &)

static const word &	calculatedType ()

Static Public Attributes inherited from fvPatchField< Type >
static int	disallowGenericFvPatchField

Detailed Description

template<class Type>
class Foam::cyclicACMIFvPatchField< Type >

This boundary condition enforces a cyclic condition between a pair of boundaries, whereby communication between the patches is performed using an arbitrarily coupled mesh interface (ACMI) interpolation.

Usage

Example of the boundary condition specification:

<patchName>
{
    type            cyclicACMI;
}

See also: Foam::AMIInterpolation

Source files

Definition at line 67 of file cyclicACMIFvPatchField.H.

Constructor & Destructor Documentation

◆ cyclicACMIFvPatchField() [1/5]

cyclicACMIFvPatchField	(	const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF
	)

Definition at line 30 of file cyclicACMIFvPatchField.C.

◆ cyclicACMIFvPatchField() [2/5]

cyclicACMIFvPatchField	(	const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 43 of file cyclicACMIFvPatchField.C.

References dict, Foam::stringOps::evaluate(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, fld, Foam::nl, and p.

Here is the call graph for this function:

◆ cyclicACMIFvPatchField() [3/5]

cyclicACMIFvPatchField	(	const cyclicACMIFvPatchField< Type > &	ptf,
		const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 94 of file cyclicACMIFvPatchField.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, p, and Foam::foamVersion::patch.

Here is the call graph for this function:

◆ cyclicACMIFvPatchField() [4/5]

cyclicACMIFvPatchField ( const cyclicACMIFvPatchField< Type > & ptf )

Definition at line 120 of file cyclicACMIFvPatchField.C.

◆ cyclicACMIFvPatchField() [5/5]

cyclicACMIFvPatchField	(	const cyclicACMIFvPatchField< Type > &	ptf,
		const DimensionedField< Type, volMesh > &	iF
	)

Definition at line 132 of file cyclicACMIFvPatchField.C.

Member Function Documentation

◆ TypeName()

TypeName ( cyclicACMIFvPatch::typeName_() )

◆ clone() [1/2]

virtual tmp<fvPatchField<Type> > clone ( ) const

inlinevirtual

Implements coupledFvPatchField< Type >.

Definition at line 133 of file cyclicACMIFvPatchField.H.

◆ clone() [2/2]

virtual tmp<fvPatchField<Type> > clone ( const DimensionedField< Type, volMesh > & iF ) const

inlinevirtual

Implements coupledFvPatchField< Type >.

Definition at line 150 of file cyclicACMIFvPatchField.H.

◆ cyclicACMIPatch()

const cyclicACMIFvPatch& cyclicACMIPatch ( ) const

inline

Definition at line 166 of file cyclicACMIFvPatchField.H.

◆ coupled()

bool coupled

virtual

Reimplemented from coupledFvPatchField< Type >.

Definition at line 146 of file cyclicACMIFvPatchField.C.

◆ fixesValue()

virtual bool fixesValue ( ) const

inlinevirtual

Definition at line 181 of file cyclicACMIFvPatchField.H.

References cyclicACMIFvPatch::cyclicACMIPatch(), Foam::constant::electromagnetic::e, fvPatchField::fixesValue(), Foam::gMax(), cyclicACMIPolyPatch::mask(), and cyclicACMIFvPatchField< Type >::nonOverlapPatchField().

Here is the call graph for this function:

◆ patchNeighbourField()

Foam::tmp< Foam::Field< Type > > patchNeighbourField

virtual

Implements coupledFvPatchField< Type >.

Definition at line 154 of file cyclicACMIFvPatchField.C.

References coupledFvPatch::faceCells(), cyclicACMIFvPatch::neighbPatch(), tmp::ref(), and Foam::transform().

Here is the call graph for this function:

◆ neighbourPatchField()

const Foam::cyclicACMIFvPatchField< Type > & neighbourPatchField

Definition at line 188 of file cyclicACMIFvPatchField.C.

References fld.

◆ nonOverlapPatchField()

const Foam::fvPatchField< Type > & nonOverlapPatchField

Definition at line 205 of file cyclicACMIFvPatchField.C.

References fld.

Referenced by cyclicACMIFvPatchField< Type >::fixesValue().

Here is the caller graph for this function:

◆ updateInterfaceMatrix() [1/2]

void updateInterfaceMatrix	(	solveScalarField &	result,
		const bool	add,
		const lduAddressing &	lduAddr,
		const label	patchId,
		const solveScalarField &	psiInternal,
		const scalarField &	coeffs,
		const direction	cmpt,
		const Pstream::commsTypes	commsType
	)		const

virtual

Implements coupledFvPatchField< Type >.

Definition at line 220 of file cyclicACMIFvPatchField.C.

References Foam::add(), lduAddressing::patchAddr(), and patchId().

Here is the call graph for this function:

◆ updateInterfaceMatrix() [2/2]

void updateInterfaceMatrix	(	Field< Type > &	result,
		const bool	add,
		const lduAddressing &	lduAddr,
		const label	patchId,
		const Field< Type > &	psiInternal,
		const scalarField &	coeffs,
		const Pstream::commsTypes	commsType
	)		const

virtual

Implements coupledFvPatchField< Type >.

Definition at line 257 of file cyclicACMIFvPatchField.C.

References Foam::add(), lduAddressing::patchAddr(), and patchId().

Here is the call graph for this function:

◆ manipulateMatrix() [1/2]

void manipulateMatrix ( fvMatrix< Type > & matrix )

virtual

Reimplemented from fvPatchField< Type >.

Definition at line 287 of file cyclicACMIFvPatchField.C.

◆ manipulateMatrix() [2/2]

void manipulateMatrix	(	fvMatrix< Type > &	m,
		const label	iMatrix,
		const direction	cmpt
	)

virtual

Reimplemented from fvPatchField< Type >.

Definition at line 303 of file cyclicACMIFvPatchField.C.

References fvMatrix::boundaryCoeffs(), lduPrimitiveMeshAssembly::faceBoundMap(), Foam::faceMap(), forAll, fvMatrix::internalCoeffs(), fvMatrix::lduMeshAssembly(), Foam::foamVersion::patch, lduPrimitiveMeshAssembly::patchLocalToGlobalMap(), fvMatrix::psi(), and tmp::ref().

Here is the call graph for this function:

◆ updateCoeffs()

void updateCoeffs

virtual

Reimplemented from fvPatchField< Type >.

Definition at line 437 of file cyclicACMIFvPatchField.C.

◆ doTransform()

virtual bool doTransform ( ) const

inlinevirtual

Implements cyclicAMILduInterfaceField.

Definition at line 251 of file cyclicACMIFvPatchField.H.

References cyclicACMIFvPatch::parallel().

Here is the call graph for this function:

◆ forwardT()

virtual const tensorField& forwardT ( ) const

inlinevirtual

Implements cyclicAMILduInterfaceField.

Definition at line 258 of file cyclicACMIFvPatchField.H.

References cyclicACMIFvPatch::forwardT().

Here is the call graph for this function:

◆ reverseT()

virtual const tensorField& reverseT ( ) const

inlinevirtual

Implements cyclicAMILduInterfaceField.

Definition at line 264 of file cyclicACMIFvPatchField.H.

References cyclicACMIFvPatch::reverseT().

Here is the call graph for this function:

◆ rank()

virtual int rank ( ) const

inlinevirtual

Implements cyclicAMILduInterfaceField.

Definition at line 270 of file cyclicACMIFvPatchField.H.

◆ write()

void write ( Ostream & os ) const

virtual

Reimplemented from coupledFvPatchField< Type >.

Definition at line 452 of file cyclicACMIFvPatchField.C.

References os(), and Foam::vtk::write().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/finiteVolume/fields/fvPatchFields/constraint/cyclicACMI/cyclicACMIFvPatchField.H
src/finiteVolume/fields/fvPatchFields/constraint/cyclicACMI/cyclicACMIFvPatchField.C

Public Member Functions

Additional Inherited Members

Detailed Description

template<class Type> class Foam::cyclicACMIFvPatchField< Type >

Constructor & Destructor Documentation

◆ cyclicACMIFvPatchField() [1/5]

◆ cyclicACMIFvPatchField() [2/5]

◆ cyclicACMIFvPatchField() [3/5]

◆ cyclicACMIFvPatchField() [4/5]

◆ cyclicACMIFvPatchField() [5/5]

Member Function Documentation

◆ TypeName()

◆ clone() [1/2]

◆ clone() [2/2]

◆ cyclicACMIPatch()

◆ coupled()

◆ fixesValue()

◆ patchNeighbourField()

◆ neighbourPatchField()

◆ nonOverlapPatchField()

◆ updateInterfaceMatrix() [1/2]

◆ updateInterfaceMatrix() [2/2]

◆ manipulateMatrix() [1/2]

◆ manipulateMatrix() [2/2]

◆ updateCoeffs()

◆ doTransform()

◆ forwardT()

◆ reverseT()

◆ rank()

◆ write()

template<class Type>
class Foam::cyclicACMIFvPatchField< Type >
