cuttingSurfaceBase Class Reference

Base for creating a MeshedSurface by performing some type of cell cutting/intersection. More...

Inheritance diagram for cuttingSurfaceBase:

Collaboration diagram for cuttingSurfaceBase:

Public Member Functions
	cuttingSurfaceBase ()=default
virtual	~cuttingSurfaceBase ()=default
const labelList &	meshCells () const
labelList &	meshCells ()
bool	cut () const
void	operator= (const cuttingSurfaceBase &rhs)
Public Member Functions inherited from MeshedSurface
	ClassName ("MeshedSurface")
	MeshedSurface ()
	MeshedSurface (const MeshedSurface &surf)
	MeshedSurface (const UnsortedMeshedSurface< Face > &surf)
	MeshedSurface (MeshedSurface &&surf)
	MeshedSurface (UnsortedMeshedSurface< Face > &&surf)
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const UList< surfZone > &zoneLst)
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const UList< surfZone > &zoneLst)
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const labelUList &zoneSizes=labelUList(), const UList< word > &zoneNames=UList< word >())
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const labelUList &zoneSizes=labelUList(), const UList< word > &zoneNames=UList< word >())
	MeshedSurface (const polyBoundaryMesh &bMesh, const bool globalPoints=false)
	MeshedSurface (const surfMesh &mesh)
	MeshedSurface (const fileName &name)
	MeshedSurface (const fileName &name, const word &fileType)
	MeshedSurface (Istream &is)
	MeshedSurface (const Time &runTime)
	MeshedSurface (const Time &runTime, const word &surfName)
	MeshedSurface (const IOobject &io, const dictionary &dict, const bool isGlobal=true)
	declareRunTimeSelectionTable (autoPtr, MeshedSurface, fileExtension,(const fileName &name),(name))
virtual	~MeshedSurface ()
	declareMemberFunctionSelectionTable (void, UnsortedMeshedSurface, write, fileExtension,(const fileName &name, const MeshedSurface< Face > &surf, IOstreamOption streamOpt, const dictionary &options),(name, surf, streamOpt, options))
label	size () const
const List< Face > &	surfFaces () const
const labelList &	faceIds () const
const surfZoneList &	surfZones () const
const vectorField &	Sf () const
const scalarField &	magSf () const
const vectorField &	Cf () const
virtual void	clear ()
virtual void	addZones (const UList< surfZone > &, const bool cullEmpty=false)
virtual void	addZones (const labelUList &sizes, const UList< word > &names, const bool cullEmpty=false)
virtual void	addZones (const labelUList &sizes, const bool cullEmpty=false)
bool	addZonesToFaces ()
virtual void	removeZones ()
virtual void	movePoints (const pointField &newPoints)
virtual void	scalePoints (const scalar scaleFactor)
virtual void	cleanup (const bool verbose)
virtual void	compactPoints (labelList &pointMap=const_cast< labelList & >(labelList::null()))
virtual bool	stitchFaces (const scalar tol=SMALL, const bool verbose=false)
virtual bool	checkFaces (const bool verbose=false)
virtual label	nTriangles () const
virtual label	nTriangles (labelList &faceMap) const
virtual label	triangulate ()
virtual label	triangulate (labelList &faceMap)
template<class BoolListType >
void	subsetMeshMap (const BoolListType &include, labelList &pointMap, labelList &faceMap) const
MeshedSurface	subsetMesh (const UList< bool > &include, labelList &pointMap, labelList &faceMap) const
MeshedSurface	subsetMesh (const bitSet &include, labelList &pointMap, labelList &faceMap) const
MeshedSurface	subsetMesh (const UList< bool > &include) const
MeshedSurface	subsetMesh (const bitSet &include) const
MeshedSurface	subsetMesh (const wordRes &includeNames, const wordRes &excludeNames=wordRes()) const
void	swap (MeshedSurface< Face > &surf)
void	transfer (pointField &pointLst, List< Face > &faceLst)
void	transfer (MeshedSurface< Face > &surf)
void	transfer (UnsortedMeshedSurface< Face > &surf)
autoPtr< MeshedSurface< Face > >	releaseGeom ()
void	swapFaces (List< Face > &faces)
void	swapPoints (pointField &points)
bool	read (const fileName &name, const word &fileType)
virtual bool	read (const fileName &name)
void	writeStats (Ostream &os) const
virtual void	write (const fileName &name, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null) const
virtual void	write (const fileName &name, const word &fileType, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null) const
void	write (const Time &runTime, const word &surfName=word::null) const
void	operator= (const MeshedSurface< Face > &surf)
void	operator= (MeshedSurface< Face > &&surf)
	operator MeshedSurfaceProxy< Face > () const
template<class Face >
	MeshedSurface ()
template<class Face >
	MeshedSurface (const MeshedSurface< Face > &surf)
template<class Face >
	MeshedSurface (const UnsortedMeshedSurface< Face > &surf)
template<class Face >
	MeshedSurface (MeshedSurface< Face > &&surf)
template<class Face >
	MeshedSurface (UnsortedMeshedSurface< Face > &&surf)
template<class Face >
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const UList< surfZone > &zoneLst)
template<class Face >
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const UList< surfZone > &zoneLst)
template<class Face >
	MeshedSurface (const pointField &pointLst, const UList< Face > &faceLst, const labelUList &zoneSizes, const UList< word > &zoneNames)
template<class Face >
	MeshedSurface (pointField &&pointLst, List< Face > &&faceLst, const labelUList &zoneSizes, const UList< word > &zoneNames)
template<class Face >
	MeshedSurface (const surfMesh &mesh)
template<class Face >
	MeshedSurface (const polyBoundaryMesh &bMesh, const bool useGlobalPoints)
template<class Face >
	MeshedSurface (const fileName &name, const word &fileType)
template<class Face >
	MeshedSurface (const fileName &name)
template<class Face >
	MeshedSurface (Istream &is)
template<class Face >
	MeshedSurface (const Time &runTime)
template<class Face >
	MeshedSurface (const Time &runTime, const word &surfName)
template<class Face >
	MeshedSurface (const IOobject &io, const dictionary &dict, const bool isGlobal)
bool	addZonesToFaces ()
bool	addZonesToFaces ()

Static Public Attributes
static int	debug

Protected Types
typedef meshedSurface	Mesh

Protected Member Functions
template<class EdgeOrientIntersect , class EdgeAlphaIntersect >
void	walkCellCuts (const primitiveMesh &mesh, const bitSet &cellCuts, const EdgeOrientIntersect &edgeOrientIntersect, const EdgeAlphaIntersect &edgeAlphaIntersect, const bool triangulate, label nFaceCuts=0)
virtual void	performCut (const primitiveMesh &mesh, const bool triangulate, const labelUList &cellIdLabels)
virtual void	performCut (const primitiveMesh &mesh, const bool triangulate, const bitSet &cellSelectionMask=bitSet())
virtual void	performCut (const primitiveMesh &mesh, const bool triangulate, bitSet &&cellSelectionMask)=0
virtual void	remapFaces (const labelUList &faceMap)
Protected Member Functions inherited from MeshedSurface
void	transcribe (MeshedSurface< face > &surf)
void	checkZones (const bool verbose=true)
pointField &	storedPoints ()
List< Face > &	storedFaces ()
labelList &	storedFaceIds ()
surfZoneList &	storedZones ()
void	sortFacesAndStore (DynamicList< Face > &unsortedFaces, DynamicList< label > &zoneIds, DynamicList< label > &elemIds, bool sorted)
void	transcribe (MeshedSurface< face > &surf)
void	transcribe (MeshedSurface< face > &surf)
void	transcribe (MeshedSurface< face > &surf)

Static Protected Member Functions
static void	checkOverlap (const word callerName, const boundBox &meshBounds, const boundBox &userBounds)
static bitSet	cellSelection (const polyMesh &mesh, const boundBox &userBounds, const wordRes &zoneNames, boundBox &meshBounds)
static bitSet	cellSelection (const polyMesh &mesh, const boundBox &userBounds, const wordRes &zoneNames, const word callerName, const bool warn)

Protected Attributes
labelList	meshCells_

Additional Inherited Members
Public Types inherited from MeshedSurface
typedef Face	face_type
typedef point	point_type
Static Public Member Functions inherited from MeshedSurface
static wordHashSet	readTypes ()
static wordHashSet	writeTypes ()
static bool	canReadType (const word &fileType, bool verbose=false)
static bool	canWriteType (const word &fileType, bool verbose=false)
static bool	canRead (const fileName &name, bool verbose=false)
static autoPtr< MeshedSurface >	New (const fileName &name, const word &fileType, bool mandatory=true)
static autoPtr< MeshedSurface >	New (const fileName &name)
static void	write (const fileName &name, const MeshedSurface< Face > &surf, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null)
static void	write (const fileName &name, const word &fileType, const MeshedSurface< Face > &surf, IOstreamOption streamOpt=IOstreamOption(), const dictionary &options=dictionary::null)

Detailed Description

Base for creating a MeshedSurface by performing some type of cell cutting/intersection.

No attempt at resolving degenerate cases. Since the cut faces can be quite ugly, they will often be triangulated.

Source files

• cuttingSurfaceBase.H
• cuttingSurfaceBase.C

Definition at line 56 of file cuttingSurfaceBase.H.

Member Typedef Documentation

Mesh

typedef meshedSurface Mesh

protected

Definition at line 63 of file cuttingSurfaceBase.H.

Constructor & Destructor Documentation

cuttingSurfaceBase()

cuttingSurfaceBase ( )

default

~cuttingSurfaceBase()

virtual ~cuttingSurfaceBase ( )

virtualdefault

Member Function Documentation

walkCellCuts()

void walkCellCuts ( const primitiveMesh &  mesh, const bitSet &  cellCuts, const EdgeOrientIntersect &  edgeOrientIntersect, const EdgeAlphaIntersect &  edgeAlphaIntersect, const bool  triangulate, label  nFaceCuts = 0  )

protected

Definition at line 29 of file cuttingSurfaceBaseTemplates.C.

References Foam::constant::atomic::alpha, DynamicList::append(), HashTable< T, edge, Hash< edge > >::begin(), cells, DynamicList::clear(), HashTable::clear(), HashTable< T, edge, Hash< edge > >::clear(), DebugInfo, Foam::constant::electromagnetic::e, Foam::endl(), HashTable< T, edge, Hash< edge > >::erase(), f(), Foam::flatOutput(), forAll, forAllIters, HashTable::found(), HashSet::insert(), HashTable< T, edge, Hash< edge > >::insert(), HashTable::insert(), HashTable::lookup(), mesh, Foam::nl, p0, points, DynamicList::resize(), HashTable< T, edge, Hash< edge > >::size(), Foam::HashTableOps::values(), edge::vec(), and WarningInFunction.

Here is the call graph for this function:

performCut() [1/3]

void performCut ( const primitiveMesh &  mesh, const bool  triangulate, const labelUList &  cellIdLabels  )

protectedvirtual

Definition at line 47 of file cuttingSurfaceBase.C.

References mesh, Foam::notNull(), PackedList::resize(), and bitSet::set().

Here is the call graph for this function:

performCut() [2/3]

void performCut ( const primitiveMesh &  mesh, const bool  triangulate, const bitSet &  cellSelectionMask = bitSet()  )

protectedvirtual

Definition at line 34 of file cuttingSurfaceBase.C.

References mesh.

performCut() [3/3]

virtual void performCut ( const primitiveMesh &  mesh, const bool  triangulate, bitSet &&  cellSelectionMask  )

protectedpure virtual

Implemented in cuttingPlane, and cuttingSurface.

remapFaces()

void remapFaces ( const labelUList &  faceMap )

protectedvirtual

Reimplemented from MeshedSurface.

Definition at line 66 of file cuttingSurfaceBase.C.

References Foam::faceMap(), forAll, cuttingSurfaceBase::meshCells_, MeshedSurface::remapFaces(), and List::transfer().

Here is the call graph for this function:

checkOverlap()

void checkOverlap ( const word  callerName, const boundBox &  meshBounds, const boundBox &  userBounds  )

staticprotected

Definition at line 27 of file cuttingSurfaceBaseSelection.C.

References Foam::endl(), Foam::nl, boundBox::overlaps(), boundBox::valid(), and WarningInFunction.

Here is the call graph for this function:

cellSelection() [1/2]

Foam::bitSet cellSelection ( const polyMesh &  mesh, const boundBox &  userBounds, const wordRes &  zoneNames, boundBox &  meshBounds  )

staticprotected

Definition at line 46 of file cuttingSurfaceBaseSelection.C.

References boundBox::add(), C, boundBox::clear(), boundBox::contains(), boundBox::empty(), mesh, boundBox::reduce(), PackedList::resize(), Foam::returnReduce(), and bitSet::set().

Here is the call graph for this function:

cellSelection() [2/2]

Foam::bitSet cellSelection ( const polyMesh &  mesh, const boundBox &  userBounds, const wordRes &  zoneNames, const word  callerName, const bool  warn  )

staticprotected

Definition at line 143 of file cuttingSurfaceBaseSelection.C.

References mesh.

meshCells() [1/2]

const labelList& meshCells ( ) const

inline

Definition at line 193 of file cuttingSurfaceBase.H.

References cuttingSurfaceBase::meshCells_.

Referenced by cuttingPlane::operator=(), and cuttingSurfaceBase::operator=().

Here is the caller graph for this function:

meshCells() [2/2]

labelList& meshCells ( )

inline

Definition at line 199 of file cuttingSurfaceBase.H.

References cuttingSurfaceBase::meshCells_.

cut()

bool cut ( ) const

inline

Definition at line 205 of file cuttingSurfaceBase.H.

References cuttingSurfaceBase::meshCells_.

operator=()

void operator=

(

const cuttingSurfaceBase &

rhs

)

Definition at line 84 of file cuttingSurfaceBase.C.

References cuttingSurfaceBase::meshCells().

Here is the call graph for this function:

Member Data Documentation

meshCells_

labelList meshCells_

protected

Definition at line 69 of file cuttingSurfaceBase.H.

Referenced by cuttingSurfaceBase::cut(), cuttingSurfaceBase::meshCells(), and cuttingSurfaceBase::remapFaces().

debug

int debug

static

Definition at line 177 of file cuttingSurfaceBase.H.

---

The documentation for this class was generated from the following files:

• src/sampling/surface/cutting/cuttingSurfaceBase.H
• src/sampling/surface/cutting/cuttingSurfaceBase.C
• src/sampling/surface/cutting/cuttingSurfaceBaseSelection.C
• src/sampling/surface/cutting/cuttingSurfaceBaseTemplates.C
