cutFaceIso Class Reference

Class for cutting a face, faceI, of an fvMesh, mesh_, at its intersection with an isosurface defined by the mesh point values f_ and the isovalue, cutValue. More...

Inheritance diagram for cutFaceIso:

Collaboration diagram for cutFaceIso:

Public Member Functions
	cutFaceIso (const fvMesh &mesh, scalarField &f)
label	calcSubFace (const label faceI, const scalar cutValue)
const point &	subFaceCentre () const noexcept
const vector &	subFaceArea () const noexcept
const DynamicList< point > &	subFacePoints () const noexcept
const DynamicList< point > &	surfacePoints () const noexcept
void	clearStorage ()
Public Member Functions inherited from cutFace
	cutFace (const fvMesh &mesh)

Additional Inherited Members
Static Public Attributes inherited from cutFace
static int	debug = 0
Protected Member Functions inherited from cutFace
void	calcSubFace (const label faceI, const scalarList &pointStatus, label firstFullySubmergedPoint, DynamicList< point > &subFacePoints, DynamicList< point > &surfacePoints, label &faceStatus, vector &subFaceCentre, vector &subFaceArea)
void	calcSubFace (const label faceI, const scalarList &pointStatus, const scalarList &weights, label firstFullySubmergedPoint, DynamicList< point > &subFacePoints, DynamicList< point > &surfacePoints, label &faceStatus, vector &subFaceCentre, vector &subFaceArea)
void	calcSubFaceCentreAndArea (DynamicList< point > &subFacePoints, vector &subFaceCentre, vector &subFaceArea)
void	calcSubFace (const face &f, const pointField &points, const scalarList &pointStatus, label firstFullySubmergedPoint, DynamicList< point > &subFacePoints, DynamicList< point > &surfacePoints, label &faceStatus, vector &subFaceCentre, vector &subFaceArea)

Detailed Description

Class for cutting a face, faceI, of an fvMesh, mesh_, at its intersection with an isosurface defined by the mesh point values f_ and the isovalue, cutValue.

Reference:

    Roenby, J., Bredmose, H. and Jasak, H. (2016).
    A computational method for sharp interface advection
    Royal Society Open Science, 3
    doi 10.1098/rsos.160405

Original code supplied by Johan Roenby, DHI (2016)

Source files

• cutFaceIso.H
• cutFaceIso.C

Definition at line 64 of file cutFaceIso.H.

Constructor & Destructor Documentation

cutFaceIso()

cutFaceIso	(	const fvMesh &	mesh,
		scalarField &	f
	)

Definition at line 27 of file cutFaceIso.C.

References cutFaceIso::clearStorage().

Here is the call graph for this function:

Member Function Documentation

calcSubFace()

Foam::label calcSubFace	(	const label	faceI,
		const scalar	cutValue
	)

Definition at line 47 of file cutFaceIso.C.

References cutFace::calcSubFace(), f(), forAll, Foam::mag(), and Foam::Zero.

Here is the call graph for this function:

subFaceCentre()

const point& subFaceCentre ( ) const

inlinenoexcept

Definition at line 122 of file cutFaceIso.H.

subFaceArea()

const vector& subFaceArea ( ) const

inlinenoexcept

Definition at line 128 of file cutFaceIso.H.

subFacePoints()

const DynamicList<point>& subFacePoints ( ) const

inlinenoexcept

Definition at line 134 of file cutFaceIso.H.

surfacePoints()

const DynamicList<point>& surfacePoints ( ) const

inlinenoexcept

Definition at line 140 of file cutFaceIso.H.

clearStorage()

void clearStorage

(

)

Definition at line 107 of file cutFaceIso.C.

References Foam::Zero.

Referenced by cutFaceIso::cutFaceIso().

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• src/transportModels/geometricVoF/cellCuts/cutFace/cutFaceIso.H
• src/transportModels/geometricVoF/cellCuts/cutFace/cutFaceIso.C
