Calculates the face fluxes. More...

Inheritance diagram for cutFaceAdvect:

Collaboration diagram for cutFaceAdvect:

Public Member Functions
	cutFaceAdvect (const fvMesh &mesh, const volScalarField &alpha1)

label	calcSubFace (const label faceI, const vector &normal, const vector &base)

label	calcSubFace (const face &f, const pointField &points, const scalarField &val, const scalar cutValue)

label	calcSubFace (const label faceI, const label sign, const scalar cutValue)

scalar	timeIntegratedFaceFlux (const label faceI, const vector &x0, const vector &n0, const scalar Un0, const scalar dt, const scalar phi, const scalar magSf)

scalar	timeIntegratedFaceFlux (const label faceI, const scalarField &times, const scalar Un0, const scalar dt, const scalar phi, const scalar magSf)

scalar	timeIntegratedArea (const label faceI, const scalar dt, const scalar magSf, const scalar Un0)

scalar	timeIntegratedArea (const pointField &fPts, const scalarField &pTimes, const scalar dt, const scalar magSf, const scalar Un0)

void	quadAreaCoeffs (const DynamicPointList &pf0, const DynamicPointList &pf1, scalar &quadArea, scalar &intQuadArea) const

void	cutPoints (const label faceI, const scalar f0, DynamicList< point > &cutPoints)

void	cutPoints (const pointField &pts, const scalarField &f, const scalar f0, DynamicList< point > &cutPoints)

const point &	subFaceCentre () const noexcept

const vector &	subFaceArea () const noexcept

const DynamicList< point > &	subFacePoints () const noexcept

const DynamicList< point > &	surfacePoints () const noexcept

void	clearStorage ()

Public Member Functions inherited from cutFace
	cutFace (const fvMesh &mesh)

Additional Inherited Members
Static Public Attributes inherited from cutFace
static int	debug = 0

Protected Member Functions inherited from cutFace
void	calcSubFace (const label faceI, const scalarList &pointStatus, label firstFullySubmergedPoint, DynamicList< point > &subFacePoints, DynamicList< point > &surfacePoints, label &faceStatus, vector &subFaceCentre, vector &subFaceArea)

void	calcSubFace (const label faceI, const scalarList &pointStatus, const scalarList &weights, label firstFullySubmergedPoint, DynamicList< point > &subFacePoints, DynamicList< point > &surfacePoints, label &faceStatus, vector &subFaceCentre, vector &subFaceArea)

void	calcSubFaceCentreAndArea (DynamicList< point > &subFacePoints, vector &subFaceCentre, vector &subFaceArea)

void	calcSubFace (const face &f, const pointField &points, const scalarList &pointStatus, label firstFullySubmergedPoint, DynamicList< point > &subFacePoints, DynamicList< point > &surfacePoints, label &faceStatus, vector &subFaceCentre, vector &subFaceArea)

Detailed Description

Calculates the face fluxes.

Reference:

    Roenby, J., Bredmose, H. and Jasak, H. (2016).
    A computational method for sharp interface advection
    Royal Society Open Science, 3
    doi 10.1098/rsos.160405

Original code supplied by Johan Roenby, DHI (2016)

Source files

Definition at line 62 of file cutFaceAdvect.H.

Constructor & Destructor Documentation

◆ cutFaceAdvect()

cutFaceAdvect	(	const fvMesh &	mesh,
		const volScalarField &	alpha1
	)

Definition at line 29 of file cutFaceAdvect.C.

Member Function Documentation

◆ calcSubFace() [1/3]

Foam::label calcSubFace	(	const label	faceI,
		const vector &	normal,
		const vector &	base
	)

Definition at line 53 of file cutFaceAdvect.C.

References f(), forAll, Foam::mag(), and Foam::Zero.

Here is the call graph for this function:

◆ calcSubFace() [2/3]

Foam::label calcSubFace	(	const face &	f,
		const pointField &	points,
		const scalarField &	val,
		const scalar	cutValue
	)

Definition at line 117 of file cutFaceAdvect.C.

References f(), forAll, Foam::mag(), points, and Foam::Zero.

Here is the call graph for this function:

◆ calcSubFace() [3/3]

Foam::label calcSubFace	(	const label	faceI,
		const label	sign,
		const scalar	cutValue
	)

Definition at line 570 of file cutFaceAdvect.C.

References cutFace::calcSubFace(), f(), forAll, Foam::mag(), Foam::sign(), and Foam::Zero.

Here is the call graph for this function:

◆ timeIntegratedFaceFlux() [1/2]

Foam::scalar timeIntegratedFaceFlux	(	const label	faceI,
		const vector &	x0,
		const vector &	n0,
		const scalar	Un0,
		const scalar	dt,
		const scalar	phi,
		const scalar	magSf
	)

Definition at line 181 of file cutFaceAdvect.C.

References Foam::expressions::patchExpr::debug, Foam::constant::electromagnetic::e, Foam::endl(), f(), forAll, Foam::mag(), nPoints, phi, Foam::constant::mathematical::pi(), Foam::sign(), and WarningInFunction.

Here is the call graph for this function:

◆ timeIntegratedFaceFlux() [2/2]

Foam::scalar timeIntegratedFaceFlux	(	const label	faceI,
		const scalarField &	times,
		const scalar	Un0,
		const scalar	dt,
		const scalar	phi,
		const scalar	magSf
	)
