cutCellPLIC Class Reference

Class for cutting a cell, cellI, of an fvMesh, mesh_, at its intersection with an surface defined by a normal and cutValue_ (defined as distance to the cell centre). More...

Inheritance diagram for cutCellPLIC:

Collaboration diagram for cutCellPLIC:

Public Member Functions
	cutCellPLIC (const fvMesh &mesh)
label	calcSubCell (const label celli, const scalar cutValue, const vector &normal)
const point &	subCellCentre () const noexcept
scalar	subCellVolume () const noexcept
const DynamicList< point > &	facePoints ()
const point &	faceCentre () const noexcept
const vector &	faceArea () const noexcept
label	cellStatus () const noexcept
scalar	VolumeOfFluid () const noexcept
scalar	cutValue () const noexcept
void	clearStorage ()
Public Member Functions inherited from cutCell
	cutCell (const fvMesh &mesh)

Additional Inherited Members
Static Public Attributes inherited from cutCell
static int	debug = 0
Static Protected Member Functions inherited from cutCell
static void	calcCellData (const DynamicList< point > &cutFaceCentres, const DynamicList< vector > &cutFaceAreas, vector &subCellCentre, scalar &subCellVolume)
static void	calcGeomDataCutFace (const DynamicList< DynamicList< point >> &faceEdges, const vector &subCellCentre, vector &faceArea, vector &faceCentre)
static void	calcIsoFacePointsFromEdges (const vector &faceArea, const vector &faceCentre, const DynamicList< DynamicList< point >> &faceEdges, DynamicList< point > &facePoints)

Detailed Description

Class for cutting a cell, cellI, of an fvMesh, mesh_, at its intersection with an surface defined by a normal and cutValue_ (defined as distance to the cell centre).

Reference:

    Henning Scheufler, Johan Roenby,
    Accurate and efficient surface reconstruction from volume
    fraction data on general meshes,
    Journal of Computational Physics, 2019,
    doi 10.1016/j.jcp.2019.01.009

Original code supplied by Henning Scheufler, DLR (2019)

Source files

• cutCellPLIC.H
• cutCellPLIC.C

Definition at line 67 of file cutCellPLIC.H.

Constructor & Destructor Documentation

cutCellPLIC()

cutCellPLIC ( const fvMesh &  mesh )

explicit

Definition at line 27 of file cutCellPLIC.C.

References cutCellPLIC::clearStorage().

Here is the call graph for this function:

Member Function Documentation

calcSubCell()

Foam::label calcSubCell	(	const label	celli,
		const scalar	cutValue,
		const vector &	normal
	)

Definition at line 53 of file cutCellPLIC.C.

References Foam::average(), Foam::constant::universal::c, Foam::mag(), and Foam::Zero.

Referenced by reconstructionSchemes::surface().

Here is the call graph for this function:

Here is the caller graph for this function:

subCellCentre()

const point& subCellCentre ( ) const

inlinenoexcept

Definition at line 145 of file cutCellPLIC.H.

Referenced by surfaceIteratorPLIC::subCellCentre().

Here is the caller graph for this function:

subCellVolume()

scalar subCellVolume ( ) const

inlinenoexcept

Definition at line 151 of file cutCellPLIC.H.

Referenced by surfaceIteratorPLIC::subCellVolume().

Here is the caller graph for this function:

facePoints()

const Foam::DynamicList< Foam::point > & facePoints

(

)

Definition at line 168 of file cutCellPLIC.C.

Referenced by surfaceIteratorPLIC::facePoints(), and reconstructionSchemes::surface().

Here is the caller graph for this function:

faceCentre()

const point& faceCentre ( ) const

inlinenoexcept

Definition at line 160 of file cutCellPLIC.H.

Referenced by surfaceIteratorPLIC::surfaceCentre().

Here is the caller graph for this function:

faceArea()

const vector& faceArea ( ) const

inlinenoexcept

Definition at line 166 of file cutCellPLIC.H.

Referenced by surfaceIteratorPLIC::surfaceArea().

Here is the caller graph for this function:

cellStatus()

label cellStatus ( ) const

inlinenoexcept

Definition at line 172 of file cutCellPLIC.H.

Referenced by surfaceIteratorPLIC::cellStatus().

Here is the caller graph for this function:

VolumeOfFluid()

scalar VolumeOfFluid ( ) const

inlinenoexcept

Definition at line 178 of file cutCellPLIC.H.

Referenced by surfaceIteratorPLIC::VolumeOfFluid().

Here is the caller graph for this function:

cutValue()

scalar cutValue ( ) const

inlinenoexcept

Definition at line 184 of file cutCellPLIC.H.

Referenced by surfaceIteratorPLIC::cutValue().

Here is the caller graph for this function:

clearStorage()

void clearStorage

(

)

Definition at line 186 of file cutCellPLIC.C.

References Foam::Zero.

Referenced by cutCellPLIC::cutCellPLIC().

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• src/transportModels/geometricVoF/cellCuts/cutCell/cutCellPLIC.H
• src/transportModels/geometricVoF/cellCuts/cutCell/cutCellPLIC.C
